TEKTRONIX AWG70001A GENERATOR *Call (760) 806-6600 to RENT this item* DESCRIPTION As data rates and signal complexity continue to increase across all electronics and RF segments, engineers and researchers need more advanced signal generators to fully stress test designs or to perform cutting-edge research. The AWG7001A Arbitrary Waveform Generator meets this need with its unique combination of 50 GS/s sample rate performance, 16 GS of waveform memory, and 10 bit vertical resolution. This means it produces fast, clean signals that can be routed through a receiver or other device under test for long periods of time for truly comprehensive testing. The Tektronix AWG70001A ARB represents a significant advance for customers who are pushing against today's performance boundaries and need a more powerful way to generate accurate test signals at high sample rates. This next generation of arbitrary waveform generators further extends Tektronix's long track record of leadership and innovation in advanced signal generation technologies. Researchers at Bell Labs, the research organization within Alcatel-Lucent, recently turned to the AWG70000 series to generate signals for advanced research demonstrating 1.5 Terabits per second superchannel transmission over ultra-long-haul optical fiber distances. The sampling rate of 50 GS/s combined with the ability to synchronize two AWGs enabled Bell Labs to generate 30 GBaud signals per optical carrier, with a data rate of 233 Gb/s, more than twice the previous record. The Tektronix AWG70001A gives design engineers and researchers the ability to create, generate or replicate ideal, distorted or "real-life" signals, an essential step in the design and measurement process. By offering easy generation of very complex signals with complete control over signal characteristics, the AWG70000 Series offers an industry best solution for measurement challenges in the following applications: Defense Electronics – The AWG70001A offers bandwidth on demand by generating wide bandwidth signals at baseband, IF and RF frequencies up to 20GHz, with greater than -80 dBc dynamic range. With up to 16 GSamples of waveform memory, it can generate unique signals that are long enough to simulate real world environments, making it the most flexible wideband signal generation product available today. Optical – Researchers developing new and faster optical technologies can use the sample rate and high vertical resolution of the AWG70000 to very high bandwidth signals with good spectral purity. Multiple units can be synchronized together to provide a complete IQ signal generation at these high bandwidth. High-Speed Serial – A number of next generation serial buses have intense signal generation needs. For instance, the AWG70000 offers a two-box solution for HDMI 2.0, supporting four lanes at 6 Gbps per lane. It gives designers the ability to add impairments to waveforms directly, eliminating the dependency on hardware elements to generate the necessary signals. Advanced Research – The AWG70000 Series is ideal for a variety of research applications, giving scientists the ability to create high precision, high-speed non-standard waveforms. With the AWG70001A, engineers and researchers can now generate signals that they previously could not generate. Key features and specifications of the Tek AWG7001A include: Leading edge AWG performance Sample Rates up to 50 GS/s 80 dBc Spurious Free Dynamic Range 10 bits vertical resolution 16 GSample waveform memory Complete solution for wideband RF signal generation in a single box Direct generation of wideband signals with carriers up to 20 GHz, removing the need for external RF conversion Simulate real-world analog effects on high speed digital data streams Model signal impairments up to speeds of 12.5 GBs Generate high precision RF signals Spurious Free Dynamic Range performance better than -80 dBc Create high speed baseband signals for optical transmission with the vertical resolution to handle higher order complex modulation 10 bits of vertical resolution at a sample rate of 50 GS/s Create long waveforms scenarios without building complex sequences Up to 16 GSamples of Waveform Memory plays 320 ms of data at 50 GS/s Synchronize multiple units to achieve a multi-channel high speed AWG system Fully operational without external PC Built-in display and buttons make it possible to quickly select, edit and play waveforms directly from the front panel of the AWG Simulate real-world environments by playing back captured signals Waveforms captured with Oscilloscopes or Real-Time Spectrum Analyzers can be played back, edited or re-sampled on the AWG Smooth transition from simulation to the real-world testing environment Waveform vectors imported from third-party tools such as MATLAB, Excel, and others Configuration Notes: 01 - Waveform record length expansion from 2 GSamples to 16 GSamples 150 - Adds 50 GS/s sampling rate *All of our equipment has been tested. Additional Calibration may be available upon request! ~Items sold with shown accessories, a power cord and manual on CD (when available)~ WARRANTY, PAYMENT, AND SHIPPING TERMS Warranty Info & Return Policy We strive to exceed our customer's expectations and maintain 100% Positive Feedback. Although we do not use eBay's automated Return Policy, all goods or equipment sold by AxiomTest include a 30-Day Warranty which starts the day the equipment is shipped. So contact us immediately if there is a discrepancy with your order or an equipment malfunction so we can issue a repair, replacement, or refund. Returns must be shipped with all original packaging and accessories. We will not accept any items with obvious signs of additional wear and tear or internal component alterations. All of our items will ship with “Warranty Void” tamper resistant stickers. If any stickers have been removed or tampered with your refund will be canceled. Please include your RMA # on the packing slip, way bill, or package. *CUSTOMER RESPONSIBLE FOR ANY AND ALL RETURN SHIPPING COSTS* Payment Options Domestic Buyers - PayPal, Wire Transfer, Money Order, Company, Bank, or Personal Check. International Buyers: PayPal or Wire transfer only. All funds must be in US Dollars. Unsecured funds must clear prior to shipment. Wire Transfers subject to a $25 service fee. Shipping Unless noted otherwise, all shipments are done through FedEx. If you would like to utilize your ownshipping account please notify us PRIOR to checkout. Saturday and Residential delivery may be available at an additional third party charge depending on the shipping method you choose. We offer shipping outside of the United States. However, some international laws prohibit us from shipping certain items to certain countries. Additionally, not all countries are supported by our service provider. You may also elect to use your own carrier, but we'll be responsible for providing the correct documentation and scheduling the pickup. We are not set up to ship via USPS, and we will NOT falsify any import documents for international orders - no exceptions. Please note: In all sales where an item is prohibited to ship internationally to a successful buyer, that buyer will be notified of non-shipment and a full refund will be made. We reserve the right not to ship any item internationally that is controlled by the US Department of Commerce’s laws and regulations and deemed non-shippable to that region of the world or to listed individuals. eBay's International Shipping calculations do not include any additional duties, fees, or VAT that may be associated with importing this item into a foreign country - please bid accordingly Sales Tax California residents will be charged sales tax if no resale or tax exempt form is submitted prior to payment. TRIED, TESTED...ACCEPTED.
