Tektronix Mso2024b Mixed Signal Oscilloscope 1ghz - 1.9ghz, 1gsa/s - 1.9gsa/s

US $3134

Spring, Texas, United States
Jan 29th

Open on mobile:
QR code

Tektronix MSO/DPO2000B Series Oscilloscopes Tektronix MSO/DPO2000B Series Oscilloscopes expand the award-winning MSO/DPO200 Series. This expansion introduces 6 new models and a new price structure. The new series meets the performance, flexibility, and affordability needs of more designers. In addition to 100MHz and 200MHz models, both DPO and MSO oscilloscopes include new 70Mhz models for very basic, low speed signal visualization. All three bandwidth models offer 2-channel and 4-channel versions. MSO/DPO2000B oscilloscopes provide the same feature-rich tools offered with the 2000 series, such as advanced low-speed serial trigger and bus decode, 16 digital channels (MSO), most advanced trigger system, longer memory, and WaveInspector® controls. Tektronix MSO/DPO2000B Oscilloscopes deliver the performance and tools you need to visualize your signals and find answers quickly. It provides bandwidth from 70-200MHz, two to four channels, 1M points of usable record length, 5,000 wfm's waveform capture rate, and a 7-inch display. The MSO/DPO2000B Oscilloscope series features FilterVu™ variable low-pass filter that also allows you to see signal details to the full bandwidth. Serial triggering tools include automated serial triggering, decode, and search for I2C, SPI, CAN, LIN, and RS-232/422/485/UART. KEY PERFORMANCE SPECIFICATIONS Product Information Bandwidth: 200MHz Calculated Rise Time: 2.1ns Display Memory Depth: 1 Mpts External Depth: 134mm External Height: 180mm External Width: 377mm Input Impedance: 1Mohm Input Voltage: 300Vrms Kit Contents: One TPP0200 200MHz Passive Probe Per Channel (10:1), One P6316 16-Channel Logic Probe and Accessory Kit and Accessory Bag, OpenChoice Desktop Software, Calibration Certificate Plug Type: US Product Range: TEKTRONIX - MSO2000B Series SVHC: To Be Advised Sampling Rate: 1GSPS Scope Channels: 4 Analogue, 16 Digital Scope Display Type: WQVGA LCD Color Scope Type: Bench Series: DPO2000, MSO2000 Supply Voltage Max: 240V Supply Voltage Min: 100V Weight: 3.6kg Scope includes 4 TPP0200 CatII Passive Probes with 200MHz of bandwidth, a P6316 16 channel digital probe, and a DPO2EMDB embedded serial triggering and analysis module ($500 value). Additional modules are available including a DPO2CONN, Ethernet and video out connectivity module, and the DPO2COMP computer serial and analysis module.

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	Tektronix
Bandwidth	1GHz - 1.9GHz
Model	MSO2024
Channels	Over 4
MPN	MSO2024B
Sample Rate	1GSa/s - 1.9GSa/s
Type	Digital
