Tektronix Serial Component Waveform Monitor - Model Wfm601e

US $845.00

Sun Valley, California, United States
Jan 29th

Open on mobile:
QR code

Unit has been well taken care of. Serial # B025010. The WFM601E monitor is a self-contained, half-rack wide, waveform/vector monitor for the 270 MB serial component operating environment. It extends the WFM601 platform to provide a more comprehensive evaluation of the digital transport layer and is used in digital production and master control operating centers. It allows observation of the analog characteristics (Eye Pattern and signal level) and digital compatibility (format and range checking) of the serial data stream. WFM601E Features Include: All video features of the WFM601A Eye Pattern view of the incoming data signal Eye Pattern timing cursors with selectable jitter display, including high-pass filtering Eye Pattern voltage cursors to indicate amplitude of the incoming data signal Cable length readout, calibrated in meters Received signal power readout Source signal level meter, independent of cable length Extended format checking and data error detection Display of field check sums for fixed pattern testing The WFM601E's wide bandwidth Eye Pattern display is an amplitude vs. time view of the 270 MB data signal's analog transmission path. It displays peak jitter and amplitude errors and, because it is looking at the actual signal path, provides a useful indication of any reflections due to impedance irregularities. The Eye Pattern is displayed at video sweep rates to provide correlation with the video signal, and a word-correlated mode may be selected by more experienced users to observe pattern-dependent crosstalk. Digital signal amplitude and jitter is measured in accordance with SMPTE-compliant high-pass filtering, assisted by time and voltage cursors.

Condition:

Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...

Brand

Tektronix
