Tektronix Tla7aa4 136 Channel 8ghz 450mhz 2m Logic Analyzer Module Used

US $250.00

Salem, New Hampshire, United States
Jan 29th

Open on mobile:
QR code

Tektronix TLA7AA4 136 Channel 8GHz 450MHz 2M Logic Analyzer Module Used Module - No manual - As is OEMXS # LTSC16 Note: Passes self test. With "CS" Option. Some minor scratches. No manual. Customer is responsible for calibration if needed. SPECIFICATIONS: Today's digital design engineers face daily pressures to speed new products to the marketplace. The TLA7Axx Series logic analyzer modules answer the need with breakthrough solutions for the entire design team, providing the ability to quickly monitor, capture and analyze real-time digital system operation in order to debug, verify, optimize and validate digital systems. Hardware developers, hardware/software integrators and embedded software developers will appreciate the range of capabilities of the TLA7Axx Series logic analyzer modules. Its broad feature set includes capturing and correlating elusive hardware and software faults; providing simultaneous state, high-speed timing, and analog analysis through the same probe; using deep state acquisition to find the cause of complex problems; real-time, non-intrusive software execution tracing that correlates to source code and to hardware events; and non-intrusive connectorless probing. The TLA7Axx Series logic analyzer modules offer Tektronix' breakthrough MagniVu™ technology for providing high-speed sampling (up to 8 GHz) that dramatically changes the way logic analyzers work and enables them to provide startling new measurement capabilities. The TLA7Axx modules offer high-speed state synchronous capture, high-speed timing capture and analog capture through the same set of probes. They capitalize on MagniVu technology to offer up to 125 ps timing on all channels, glitch and setup/hold triggering and display and timestamp that is always on at up to 125 ps resolution. The TLA7Axx also offers new capabilities to capture source synchronous applications. Option: CS: INCREASE TO; 2 MB MEMORY DEPTH @ 450 MHZ STATE SPEED http://www.tek.com/datasheet/tla7up-mainframe-field-upgrade-kits

Condition	Used : An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“Pulled from working LAB. Module with "CS" option. Some minor scratched. No manual.”
