Tektronix Tm 504 W/ Fg 503 3mhz & Fg 504 40mhz Function Generators

US $400.00

  • Mission Viejo, California, United States
  • Mar 29th
Open on mobile:
QR code
TEKTRONIX FG503 FUNCTION GENERATOR.. 1.0 HZ TO 3 MHZ.. (USABLE TO 5 MHZ).. TEKTRONIX FG 504 FUNCTION GENERATOR FOR TM SERIES 40 MHZ! SINE, SQUARE, TRIANGLE WAVEFORMS SWEEP MODE TONS OF FUNCTIONS!!! ======================================================= The FG504 Function generator provides low distortion sine, square, triangle, ramp, and pulse wave forms over the frequencies from 0.001 Hz to 40 MHz in ten decades. A user-definable custom frequency range is also available. The output amplitude is 10mV to 30V peak-to-peak into an open circuit and 5mV to 15V into a 50 ohm load The FG504 may be swept between the START and STOP FREQ. dial settings with a linear or logarithmic sweep. The output may be phased locked, gated, or triggered for a shifted ±80? from the triggering wave form. The symmetry of the output wave-form may also be varied. For slower frequencies, the output may be held at any level by pushing the front panel button labeled HOLD. A voltage controlled frequency (VCF) input controls the output frequency from an external voltage source. The output frequency can be swept above or below the selected frequency, to a maximum of 1000:1, depending on the polarity and amplitude of the VCF input and the selected output frequency. Provision is also made for amplitude modulating the sine wave output from an external source. Requires two bays in a TM500 series power module for operation.
“All Modules and rack have minor blemishes from use. All parts work such as cord and switches.”
Brand Tektronix
MPN FG504
Model FG503, FG504, TM504
Country/Region of Manufacture United States
