*Tested* National Instruments NI PXI-1408 4-Ch IMAQ RS170 CCIR NTSC PAL w/Cables, US $430 – Picture 0
*Tested* National Instruments NI PXI-1408 4-Ch IMAQ RS170 CCIR NTSC PAL w/Cables, US $430 – Picture 0

*tested* National Instruments Ni Pxi-1408 4-ch Imaq Rs170 Ccir Ntsc Pal W/cables

US $430

  • Boise, Idaho, United States
  • Jun 1st
Open on mobile:
QR code
National Instruments (NI) PCI-1408 IMAQ monochrome, high-performance image acquisition module with support for RS-170, CCIR, NTSC, and PAL standard, passes NI self-test suite. Module has assembly part # 184460C-01, the IMAQ-A2504 cable has part # 183836B-01 (one-meter length), the IMAQ-1 cable has part # 183882A-01 (one-meter length).  All items are same as shown in photos. No other items are included. The last five photos show first a screen shot of the self test results of module (all pass), the final four photos are screen shots of acquired images from RS-170 source on each video input V0-V3; each channel was tested and acquired images properly (using V0 on module edge connector, and V1-V3 from connectors off of IMAQ-A2504 cable, using an IMAQ-1 to connect the RS-170 video source to each channel). From NI- The PCI-1408 and PXI-1408 devices are high-accuracy, monochrome, IMAQ boards for PCI, PXI, or CompactPCI chassis that support RS-170, CCIR, NTSC, and PAL video standards as well as some nonstandard cameras from any of four input sources. The boards feature an 8-bit flash analog-to-digital converter (ADC) that converts video signals to digital formats. The 1408 devices acquire frames in real time and transfer them directly to system memory. The PXI-1408 module, IMAQ-A2504 and IMAQ-1 cables will be well packaged and sent in box via USPS Priority Mail. insured. The tracking # will be entered into ebay and Paypal systems after shipment.
