Tf Card U Disk Mini Mp3 Decoder Player Wmv Audio Voice Module Dfplayer Gpd2846a

US $0.99

, , China
Sep 2nd

Open on mobile:
QR code

TF Card U Disk Mini MP3 Decoder Player WMV Audio Voice Module DFPlayer GPD2846A DFPlayer Mini MP3 Features: DFPlayer Mini is a compact and inexpensive MP3 module can be connected directly to the speaker. Module with battery power supply, speaker, keypad can be used alone, or through the serial port control, as the Arduino UNO or any microcontroller with a serial port module. The module itself perfectly integrated hardware decode MP3, WAV, WMA's. While the software supports TF card driver to support FAT16, FAT32 file system. Can be done by simple serial command plays the specified music, as well as how to play music and other functions, without tedious low-level, easy to use, stable and reliable. Technical Specifications 1, supports sampling rates (KHz): 8 / 11.025 / 12/16 / 22.05 / 24/32 / 44.1 / 48 2,24-bit DAC output, dynamic range support: 90dB, SNR support: 85dB 3, fully supports FAT16, FAT32 file system, maximum support 32G TF card, support U disk to 32G, 64M bytes of NORFLASH 4, a variety of control modes are available. IO control mode, serial mode, AD key control mode 5, the broadcast language spots feature, you can pause the background music being played. Advertising finished playing back background sound to continue playing 6, the audio data is sorted by folder, supports up to 100 folders, folders can assign every 255 Tracks 7,30 level adjustable volume, adjustable EQ 6 Application 1, car navigation voice broadcast 2, road transport inspectors, toll voice prompts 3, train station, bus station voice prompts security check 4, electric power, telecommunications, financial operating room voice prompts 5, the vehicle into or out of the channel to verify the voice prompts 6, border control channel voice prompts ** 7, multi-channel voice alarm or voice guidance equipment operation 8, electric sightseeing bus safety with voice notices 9, electrical and mechanical equipment failure alarm 10, fire alarm voice prompts 11, automatic broadcasting equipment, regular broadcast Package Included: 1 x TF Card U Disk Mini MP3 Player Audio Voice Module Arduino DFPlay Min Board TF Card MP3 Decoder Features: Working Voltage: 3.7V Lithium Battery 600MA or 5V USB Power Supply Chip:GPD2846A Chip Footprint:SOP16 PCB Size:34.23MM*22.33MM*1MM with 2W Mixed mono With Power supply ,it can play Automaticly With LED indicator Supports MP3 format playback Supports USB audio mode Supports 3 types FM radio chip : RDA5807, BK1080 and RTC6207E. Does not support infrared remote control. Does not support USB device mode Package Included: 1 x GPD2846A TF Card MP3 Decoder Board 2W Amplifier Module For Arduino Payment Shipping Refund Payment EBAY Managed Payment. But we only Accept your Ebay Address, please Make sure it's 100% right. Payment must be received in 5 business days of auction closing. Please leave note for your special request (e.g. Colors or Size) in PayPal when you pay the order. Any special request cannot be accepted after 24 hours of payment, because most of orders will be processed instantly and same day dispatched. Shipping 1. We only ship to the confirmed address provided by eBay. please make sure your ebay address is 100% matches the address you would like us to ship to. If not, please let us know before we sent you the package, or we will not be responsible for any loss. hope you could understand. 2. Orders will be processed instantly and dispatched within 1-3 business days except hoilday, so we do NOT accept any email/message note after you place orders. 3. All package need to wait 30 days,Please take care it.Less than 30 days,we can't take a refund. Refund If you can't receive the product within 2 months (60 days), please contact with us,we promise to payback 100% of your money. We ensure our products work normally before post.If the products is broken before arrival to you,all you should do is taking a photo to show us our broken product.We promise to payback 100% of your money. If the item is defect when you receive it or you are not satisfied with it, please return it within 14 days for a replacement or money back. But the items must be back in factory condition. Please contact us and double check the return address before you return it. If is item is defective in 12 months, you can return it to us. We will send you a new replacement after receiving the defective item. On Sep-02-21 at 06:33:10 PDT, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Unbranded
UPC	Does not apply
MPN	Does not apply
EAN	Does not apply
