Titan Tm-10 High Magnification Measuring Microscope

US $3,899.00

Temecula, California, United States
Mar 7th

Open on mobile:
QR code

Titan TM-10 High Magnification Measuring and Metallurgical Microscope Excellent condition, new stage glass & illumination bulb. Original owner, minimal use, very well maintained and protected in a glass-enclosed cabinet. The Titan TM-10 was designed to have all the features necessary for high magnification viewing. This includes rack and pinion focusing, 3 objective lenses revolving on a positive stop nose piece and depth measuring attachment with zeroing screw. The magnification capabilities with lenses provided are 50x, 100x, 200x, and 400x. And additional 40x lens can be purchased to increase magnification to 800x. Multiple variations of magnification can be achieved by combining variations of the included lenses. The precision Mitutoyo micrometers have ranges of 1 inch and 2 inch, inclusively, their minimum division accuracy is 0.0001 inches. The stage range envelope is 2 inches x 6 inches. The 6 inch X-range is achieved by utilizing gauge blocks together with the 2 inch micrometer range capability. Vertical focusing is achieved by using the included vertical coarse and fine adjustment screws. Optics stage has a vertical adjustment range of 6 inches and is secured by a safety ring on the lower end to protect the glass. An additional micrometer can be added to monitor/measure vertical adjustment. This is a high quality toolmakers microscope with incredible accuracy that can actually measure accurately to 50 millionths (.00005) of an inch. Included: Titan TM-10 Microscope 1X, 5X, 10X, 20X Objectives 10X Eyepiece Co-Axial Illuminator with new bulb Co-Axial and Sub-Stage Illuminator with selector switch Specifications: Eyepiece: Coated 10X Reticle: Same for 10X and 20X Eyepieces, 90 degree Cross Hairs and 4 Concentric Circles with 10 line divisions between circles. Image: Optically correct Travel: 2.00" x 6.00" X-Y Stage travel distance Overall Stage Size: 5.375" x 9.00" Vertical Travel: 6" adjustable vertical height coarse adjustment, Rack and pinion fine adjustment Bid with Confidence!!! Shipping Details: Seller will deliver for free within a 100 mile radius. If local pickup is not an option, seller is willing to ship within continental United States. Alaska or Hawaii bidders contact before bidding for shipping arrangements. If local pickup is not an option, seller is willing to ship, however buyer must take care of all shipping arrangements. Ground shipping recommended, appr. 50 lbs shipping weight, dimensions are appr. 16x16x16. Seller will securely package in either a box or wooden crate, buyers choice. Seller is not responsible for any damage to item incurred during shipping. Insuring shipment is recommended and at buyers expense. Item sold is the item pictured. Contact seller with any questions before bidding. Sale is final, no returns.

“Excellent condition with new stage glass and illumination bulb. Original owner, minimal use, very well maintained and protected.”
