Tomco Trewmac Te1000 Rf Impedance Analyser Vector Antenna Analyzer Lcr Meter

US $1300

Goldendale, Washington, United States
Nov 15th

Open on mobile:
QR code

Here is a Tomco TE1000 RF Impedance Analyzer. This unit is fully functional and works great. Use this standalone or with the included software to graph data. Comes with standard accessories, N-type adapter, RS232 to USB Converter and cable, Universal power supply, Certificate of Calibration and test data(note: cal was due in 2008), CD ROM with user manual and software(note: the Trewmac site has new software available for download), and case. Pictures show the unit measuring an open, short and precision 50ohm load at 13.56MHz. Open, Short and HP Precision Load Not included. The internal battery no longer holds a charge but can be easily replaced if desired. Guaranteed fully functional I will ship on your Fedex Account at no additional charge TE1000 info from the Trewmac website: It is a precision, portable impedance analyzer which enables the user to make highly accurate impedance measurements through VHF range (0.5-150MHz). The TE1000 has full vector measurement capability, and accurately resolves the resistive, capacitive and inductive components of a load. The user can display impedance in polar form, rectangular form, series R-L-C equivalent or parallel R-L-C equivalent circuit. On board algorithms generate a range of related parameters including VSWR, complex reflection coefficient, and return loss against a user defined characteristic impedance Zo (normally 50 Ohms). The TE1000 uses an RS232 interface and is supplied with a third part serial to USB converter for connection to a PC. It shares the same software as the new TE3000 series providing swept frequency capability and facilities for complex data analysis, data logging and graphical display. Any application capable of comm port control can send commands and receive data from the TE1000 making it perfect for automated and remote data collection. The Trewmac Systems TE-1000 Vector Impedance Analyzer is supplied in a lightweight, rugged aluminium case with all the accessories included to operate the unit to its full potential. The unit itself can be powered by the mains adapter or by the internal battery making it ideally suited for both bench top and portable use. Typical applications include RF design and development, antenna testing and tuning, impedance matching, component testing, cable fault finding, filter design and testing, and cutting cables to precise electrical lengths. Summary of Features 0.5-150MHz with 0.25-250kHz resolution 1-10000 Ohms -90 to +90 Degrees Fixed output power Easy and accurate 'in circuit' measurements. Sensitive component characterisation N type adaptor for coaxial connection Factory calibrated with full calibration report RLC meter function Display formats include Impedance, Reflection Coefficient, VSWR, Return Loss, Equivalent Series or Parallel RLC. User defined Zo Battery and mains powered Suppled in a rugged aluminium carry case with software and accessories Software includes: VF, Zo, Distance to fault, Impulse response, and spectral analysis functions. Multi trace plotting, Smith charts, markers and annotations. Common Applications RF engineering design and development AM, MW, HF, shortwave antenna and transmitter tests FM and TV transmitter and antenna tests Transmission line impedance matching Production line component tests TDR and FDR Cable fault finding RF filter and balun design and test NMR and MRI testing Cutting cables to precise electrical lengths
