Tpi 293 Digital Clamp-on Meter, 700a Ac Range, True Rms Response

US $121.46

Boca Raton, Florida, United States
Feb 15th

Open on mobile:
QR code

AUTHORIZED DISTRIBUTOR TPI 293 Digital Clamp-On Meter, 700A AC range, True RMS response TPI 293 Digital Clamp-On Meter, 700A AC range, True RMS response True RMS responding 700A AC electrical / industrial digital clamp-on meter True RMS responding cULus 3111; CAT III 600V 3-year limited warranty 700A AC range 750V AC/DC range Frequency Resistance Audible continuity Diode Test 4000 count display with analog bargraph Applications: Heat anticipator current in thermostats Line voltage Control circuit voltage Heating element resistance Compressor winding resistance Contactor and relay coil resistance Motor and compressor start up current Continuity of wiring Frequency on control and line voltage Record/Min/Max voltage of controls and line voltages Bar graph to indicate rapid fluctuations Specifications: DC Voltage Max Range:750V, Max Resolution:0.01V, Basic Accuracy: 0.75% AC Voltage Max Range:750V, Max Resolution:0.01V, Basic Accuracy: 1% DC Amps N/A DC Microamps N/A AC Amps Max Range:700A, Max Resolution:0.01A, Basic Accuracy: 2% Resistance Max Range:40K?, Max Resolution:0.01K?, Basic Accuracy: 1% Frequency Max Range:10KHz, Max Resolution:0.1Hz, Basic Accuracy: 0.2% Capacitance N/A Temperature N/A Non-Contact Voltage (NCV) N/A Continuity Buzzer <50? Diode Test Yes True RMS Response Yes Peak Hold Yes Relative Mode No Min/Max Record No Data Hold Yes % Total Harmonic Distortion No Range Selection Auto / Manual Display Type 4000 count LCD Operating Temperature -4°F to 131°F Relative Humidity 80% non-condensing Storage Temperature -40°F to 140°F Battery Type 9V (MN1604) Battery Life 200hrs typical Auto Off / Sleep Mode Yes Dimensions (H x L x W) 1.5” x 7.25” x 2.5” Weight 11.1oz Agency Approval CE IEC 1010: CAT III, 600V cULus 3111-1

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	TEST PRODUCTS INTERNATIONAL
MPN	293
Model	TPI 293
Country/Region of Manufacture	Korea, Republic of
