Included Items Item Description Shipping Info Payment Info * Trimble R8 Model 4 GNSS Receiver P/N: 83745-66 w/ Options... [ID- X1682] - CMR Inputs - CMR Outputs - RTCM Inputs - RTCM Outputs - Data Collector - Binary Outputs - Data Logging - Bluetooth - L2CS - UHF Transmit - Cellular - L5 - Enable GLONASS - Enable Webserver - Login Required - Enable COMPASS (BeiDou) - Enable Galileo - 450 - 470 MHz Radio P/N: 64235-66 - Serviced By A Trimble Authorized Service Center * Li-Ion Battery Charger w/ AC Adapter * Antenna * QTY. 2 Battery Packs * RS232 PC Interface Cable * User Manual On CD-ROM * Hard Carrying Case (G) Condition: Refurbished Warranty: 90 Day Exchange Trimble R8 Model 4 GPS GLONASS Galileo & BeiDou 450-470 MHz Base Or Rover w/ Options... - CMR Inputs - CMR Outputs - RTCM Inputs - RTCM Outputs - Data Collector - Binary Outputs - Data Logging - Bluetooth - L2CS - UHF Transmit - Cellular - L5 - Enable GLONASS - Enable Webserver - Login Required - Enable COMPASS (BeiDou) - Enable Galileo - 450 - 470 MHz Radio P/N: 64235-66 - Serviced By A Trimble Authorized Service Center Trimble R8 Model 4 GNSS Receiver The receiver incorporates a GNSS antenna, receiver, internal radio with a transmit option or an internal GSM module, and a battery in a rugged light-weight unit that is ideally suited as an all-on-the-pole RTK rover. Three LEDs allow you to monitor the satellite tracking, radio reception, data logging status, and power. Bluetooth wireless technology provides cable-free communications between receiver and controller. The circuitry in the Trimble R8 Model 4 GNSS receiver provides up to 440 channels for satellite tracking, and supports logging raw GNSS observables to the internal receiver memory or to a handheld controller for post processed applications. The receiver is available as a standalone rover, base station, or as part of the GNSS Total Station® system, offering maximum versatility in the system configuration to meet your specific requirements. The receivers provide the following features: Future-proof Trimble 360 technology (Trimble R8 Model 4), which includes advanced Trimble Maxwell 6 Custom Survey GNSS chips with 440 channels and allows the receiver to track the following: GPS: L1 C/A, L1C, L2C, L2E, L5 GLONASS: L1 C/A, L1P, L2 C/A, L2P, L3 Galileo: E1, E5A, E5B BeiDou (COMPASS): B1, B2 SBAS: QZSS, WAAS, EGNOS, GAGAS Centimeter-accuracy, real-time positioning with RTK/OTF data, up to 20 Hz position updates (R8 Model 4) or up to 10 Hz (R6 Model 4 and R4 Model 3) Submeter-accuracy, real-time positioning using pseudorange corrections Automatic OTF (on-the-fly) initialization while moving Single Lithium-ion rechargeable battery Cable-free Bluetooth communications with Trimble controllers Two RS-232 serial ports for: Trimble Format (CMR, CMR+™ and CMRx) input and output RTCM SC-104 input and output (RTCM 2.1, 2.3, 3.0, 3.1) 23 NMEA outputs GSOF, RT17, and RT27 outputs Supports BINEX and smoothed carrier One TNC radio antenna connector Internal memory for data storage Specifications: Feature Specification Size 19.0 cm (7.5") wide x 10.4 cm (4.1") deep including connectors Weight: with internal battery, radio, and standard antenna 1.52 kg (3.35 lbs) Operating times on internal 2.6 Ah battery (varies with temperature) 450 MHZ receive only - 5 hours 450 MHz receive/transmit: 2.5 hours (varies with wireless data rate) GSM: 4.7 hours Power input 11–28 V DC with over-voltage protection on port 1 (7-pin lemo) Operating temperature –40 °C to +65 °C (–40 °F to +149 °F) Storage temperature –40 °C to +75 °C (–40 °F to +167 °F) Humidity 100% condensing, unit fully sealed Casing Water/dustproof IP67 dustproof, protected from temporary immersion to depth of 1 m (3.28 ft) Positioning specifications Feature Specification Positioning performance Code differential GNSS positioning Horizontal: 0.25 m + 1ppm RMS Vertical: 0.50 m + 1ppm RMS SBAS differential positioning accuracy: typically <5 m 3DRMS Static GNSS surveying High-precision static Horizontal 3 mm + 0.1 ppm RMS Vertical 3.5 mm + 0.4 ppm RMS Static and FastStatic Horizontal 3 mm + 0.5 ppm RMS Vertical 5 mm + 0.5 ppm RMS Kinematic surveying Postprocessed Kinematic (PPK) GNSS surveying Horizontal 8 mm + 1 ppm RMS Vertical 15 mm + 1 ppm RMS Real-Time Kinematic Surveying Horizontal 8 mm + 1 ppm RMS Vertical 15 mm + 1 ppm RMS Network RTK Horizontal 8 mm + 0.5 ppm RMS Vertical 15 mm + 0.5 ppm RMS Initialization time typically < 8 seconds Initialization reliability typically > 99.9% Technical specifications Tracking: Trimble R8 Model 4 GNSS receiver Advanced Trimble Maxwell 6 Custom Survey GNSS chips with 440 channels. Satellites simultaneously tracked: GPS: L1 C/A, L1C, L2C, L2E, L5 GLONASS: L1 C/A, L1P, L2 C/A, L2P, L3 Galileo: E1, E5A, E5B BeiDou (COMPASS): B1, B2 SBAS: QZSS, WAAS, EGNOS, GAGAN Signal processing Advanced Trimble Maxwell 6 Custom Survey GNSS chip Very low-noise GNSS carrier phase measurements with <1 mm precision in a 1 Hz bandwidth Multipath suppression Start-up Cold start: < 60 seconds from power on Warm start: < 30 seconds with recent ephemeris Initialization Automatic while moving or static Initialization time Typically < 8 seconds Initialization reliability Typically >99.9% Communications Two RS-232 serial ports (Port 1, Port 2) Baud Rates up to 115,200 bps RTS/CTS flow control negotiation supported on port 2 Bluetooth communications through Trimble controller with Bluetooth support Configuration Through user-definable application files or GPS Configurator Output formats NMEA-0183: AVR; BPQ; DP; DTM; GBS; GGA; GGK; GLL; GNS; GRS; GSA; GST; GSV; HDT; LLQ; PJK; PJT; RMC, ROT; VGK; VHD; VTG; ZDA GSOF (Trimble Binary Streamed Output) RT17 and RT27 outputs, BINEX and smoothed carrier We will attempt to ship your item(s) within 24 hours after payment has been received. Many countries impose their own customs, duties, tariffs, taxes, etc. on items being shipped from a foreign country. We do not cover those cost's and we recommend that you contact your countries customs agency for that information. We accept credit card payment transactions via the online checkout system! The checkout process is designed so that it communicates with the merchant to confirm that payment has been made and cleared. Other methods of payment are outlined through the online checkout process. Winning bidders must contact us within 3 days after auction close if special payment arrangements are needed. Your payment is expected within 5 days after the auction close. Unpaid auctions will be forfeited after 5 days of the auction close and the Item(s) will be relisted for sale. Items will be shipped within 24 hours (1 Business Day) upon receipt of payment from the winning bidder. (Certain orders may take longer for processing due to comprehensive final service inspections) A Shipment Tracking number(s) will be provided to inform Buyers of their expected ETA (Estimated Time of Arrival). Tracking number(s) will be provided the same day as order shipment. Thank you Reach your goals with Kyozou eBay Sales Management
