TYCO 644662 MTA-156 IDC connectors 22 AWG - 50 pcs, US $218 – Picture 0
TYCO 644662 MTA-156 IDC connectors 22 AWG - 50 pcs, US $218 – Picture 0

Tyco 644662 Mta-156 Idc Connectors 22 Awg - 50 Pcs

US $218

  • Tampa, Florida, United States
  • Jan 29th
Open on mobile:
QR code
MTA-156 connectors accept discrete and ribbon cable wire sizes ranging from 22 AWG with maximum insulation outside diameter.095 [2.41] for single wire and .070 [1.78] for mass termination of wires. This model features Closed End with Locking Ramp and with Tabs. Tin plated solid, fused stranded or stranded (7 and 19 strands) wire with PVC insulation can be used on 22 AWG [0.8 – 0.9 mm2] MTA-156 connectors Only one wire to be terminated into an IDC contact slot. Mass termination of wire provides the lowest applied cost because it drastically reduces the labor content of virtually any cable or harness assembly required. The wire-to-post connector housing material is flame retardant thermoplastic, either UL94V-2 or UL94V-0 rated. Performance Data Gold Plated contacts Voltage Rating—600 vac Current Rating—7 amp max. for MTA-156 Connector Low-Level Resistance—3.0 mohm max. initial Dielectric Withstanding Voltage—2200 vac/1 min. Insulation Resistance—5000 Mohm min. initial Operating Temperature— -55 C to +105 C Dimensional drawing is available in pdf format from here: IDC22AWG.pdf This is the closest drawing we found but it doesn't show the polarizing keys on each side of the connector (see the picture) Digi-Key and Mouser list these connectors for more than $3 each Here, if you lucky in auction, you can get it for a fraction of that. This auction is for 2 bags of 25pcs each - TOTAL of 50 PCS
Condition New other (see details) :
A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections.
Seller Notes “old stock”
