U600 Vert Out IC for TEKTRONIX 2445 2445A 2445B OSCILLOSCOPE p/n 165-2393-00, US $5.00 – Picture 0
U600 Vert Out IC for TEKTRONIX 2445 2445A 2445B OSCILLOSCOPE p/n 165-2393-00, US $5.00 – Picture 0

U600 Vert Out Ic For Tektronix 2445 2445a 2445b Oscilloscope P/n 165-2393-00

US $5.00

  • Antioch, California, United States
  • Jan 29th
Open on mobile:
QR code
$5 BIN gets you the Tek IC 165-2393-00 which is very similar to 155-0237-00 U600 vertical out IC used in 24__ scopes. These are used, but still good. Roughly speaking, 165-2393-00 will limit a 400MHz scope's bandwidth to about 360MHz, whereas a 155-0237-00 will let it work to around 450MHz. You will not notice any bandwidth difference between these 2 part #s on 150 or 200 Mhz 2400s. The typical symptom of a failed (or failing) U600 is inability to center anything on screen, even with beamfinder invoked. Replacing U600 will not cure problems that are confined to just 1 or 2 channels (rather than all 4). Photos are generic, the 1 you get may have a different date code, but will be genuine Tek rather than Maxtek (made for Tek). Tek used to charge $200+  when they last sold these and those last ones were inferior Maxtek. Tek 165-2393-00 is also used as the vertical output stage in Tek's TAS485. If you want the faster 155-0237-00 (for a 2465A or a 2465B), I can sell it to you for $50 more (due to scarcity).    Please keep in mind I have ANY and ALL the parts 2400s need... Just ask... Also, this is a very inexpensive way to get introduced. After any 1st purchase, ebay will give us each other's contact info, so you'll be able to save 10% on subsequent purchases (10% of an ebay sale goes to ebay). The only cheaper introduction is to buy 1 of my scope handle labels which has free shipping.       I ship worldwide. California buyers pay CA sales tax. Ebay & Paypal require I ship via trackable methods. USPS, internationally, has very poor tracking capabilities. Ebay's Global Shipping Program has decent tracking. You get a 14 day right of return for refund or exchange, provided you send it back in same condition it arrived, pack it as well as I did, and pay for all shipping.
Condition:
Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...
Type Analog
Make Tektronix
Channels 4
