UL Listed 3 Phase Smart Meter Read With Your Computer w USB or Over Internet #25 EKM-Omnimeter II v.3 UL- UL Listed Universal kWh Meter This is the newest addition to our meter product line, our Universal OmniMeter II v.3 UL accurately meters all electrical systems commonly used in the world--120V, 2-wire, single-phase through 240v, 3-phase 4-wire, 50Hz or 60Hz. Meter up to 5000A! Many building codes and large installations require a UL listing. These meters went through a rigorous testing process and are now approved and listed by Underwriters Laboratories. They carry the UL mark and the cUL mark (tested to the same standards as CSA, for Canada) Supports current transformers (CTs) from 100A through 5000A. CT current rating is selectable internally in the meter so readout is always correct, no conversion factor or multiplier. External current transformer (CT) type meter for ease of installation. 1 to 3 CTs per meter required (depends on the electrical system being metered). CTs are not included with this listing. You will need: • 1 CT for 120 volt 2-wire (or 230v 2-wire foreign) systems • 2 CTs for 120/240v 3-wire systems • 2 CTs for 3-phase 3-wire systems • 3 CTs for 3-phase 4-wire systems. We have small CTs available on eBay but for a larger offering please see the CT Selection on our website. (CTs sold separately- See our other listings) Reads kWh, Reverse kWh (for solar), Voltage on each line, Current on each line, Power (watts) on each line, Power Factor on each line, Maximum Demand, CT Ratio, 6 months of monthly reads stored on-board the meter with 4 TOU rates, 4 Times of day, 4 Seasons, Weekends and Holidays!! All readable and log-able via RS-485 and user friendly PC, Mac and Linux software. • Exceptional revenue grade accuracy: Class 0.5 (+/-0.5% over all but the very lowest end of the current range). • Built-in data storage and RS-485 Serial Communication for reading kWh usage remotely! • FREE PC, Mac, and Linux software to read the meter data remotely • Connect to your computer via 2-wire RS-485 --Easy to connect 2-wire, daisy-chained network! • Up to 256 meters can connect on over 4000 feet of wire to one EKM Push, USB Converter, or any of our other RS-485 communication devices. • Low-cost USB, Serial, and Ethernet converters available! • Connect up to 256 meters to one $85-$100 internet-connected device for world-wide access! • Each meter ships to you with it's own unique 12 digit network address • State of the art, solid-state, digital energy meter • LCD Display (required for revenue grade metering) • Compact, easy-to-install design • Monitor all critical circuits in your home or business • Pulse output--800 pulses per kWh • DIN-Rail mount • Not available anywhere else!! This is a completely unique product • Watertight and Interior Enclosures available • 10 year warranty -- We will fix or replace these meters if there is a reliability issue within 10 years Download the UL EKM-Omnimeter Spec Sheet here ____________________________________________________ This is a brand new kWh meter design manufactured by EKM Metering. It is the most advanced electronic KWH meter available on the market. Our Universal EKM-OmniMeter can meter any system that is commonly used in the world. It can accurately meter 50 or 60Hz, 120V through 240V, 1-phase or 3-phase, it is accurate to 0.5% and can meter up to 5000 amps. Installation is easy with external current transformers (CTs). However, installation should only be performed by a qualified electrician. This model requires 1 to 3 CTs, depending on you electrical system. Spec sheet/instruction manual included. Dimensions are approx. 4"w x 4"h x 2.5"d. These meters have a non-resettable, 7 digit LCD readout with tenths, and read directly in kWh, no conversion factors as with some other electronic meters. These also have built-in data storage which is readable via a 2-wire RS-485 serial connection to your PC (connections A, B and G in the photo). In addition, they have a built-in pulse output, 800 pulses per kWh. They are perfect for remote and automatic meter reading (AMR) applications for sub-billing or measurement and verification (M&V). Use these meters to measure and keep track of kilowatt hours and energy usage of sub-panels or individual pieces of equipment. We can supply these in large quantities with very attractive discounts if needed. Please Note--Some of the photos in this listing are for illustration purposes, and may show something NOT included with the listed item. This listing is for the Meter Only. CTs, DIN-rail, and converters are sold separately. VISIT EKM METERING'S WEBSITE FOR MORE INFORMATION ____________________________________________________ EKM Push: The EKM Push system represents an entirely new paradigm in meter data management. We have designed the EKM Push system to be easy to install, have no network configuration, be infinitely scalable, with minute interval meter data available instantly on the web for FREE. Access data from the cloud through our open energy API (see our Developer Portal), third-party apps, websites, or our EKM Dash software. We highly recommend this system for connecting your meters to the internet or if you are using our meters in a large distributed installation. All you need to do is install your meter, connect it to the Push, and connect the push to the internet -- thats it, your meter data is instantly available on the web in your EKM Push account. Real-Time Push Widget: ____________________________________________________ RS-485 Data: These meters communicate over RS-485. This is a very powerful industrial standard of communication which allows up to 256 meters to be connected on up to 4000 feet of wire to one communication converter. We have EKM Push gateways, USB to RS-485, Serial (RS-232) to RS-485, and Ethernet to RS-485 Converters available. You must use one of these converters to read your meters with your computer or over the internet. We have these converters available on eBay or on our website. We supply a FREE version of our EKM Dash software that will allow you to read an unlimited number of meters within your building or over the internet. We also have a $30 version of the Dash available, which will let you log your meter reads to a spreadsheet and schedule monthly email reports, setup alerts and triggers, and view your data in real-time line graphs or historical bar charts. There are no monthly or annual fees for this software. Our EKM Dash software is compatible with PC, Mac OSX, and Linux. (EKM Dash software is available HERE) ____________________________________________________ About EKM Metering: EKM Metering Inc. designs and sells electric meters, water meters, and gas meters, as well as communication systems that provide free and unrestricted access to meter data. Our vision is to provide submetering solutions to fill the niche between traditional “dumb” meters, which are costly to install and need to be individually and locally read, and very expensive metering services or metering systems that require a high level of expertise to install and configure. Driving this vision is a desire to do something that will not only be of benefit to ourselves and to our customers—the basis of good business—but will be of benefit to the planet as well. Our own experience has convinced us that metering and monitoring of our energy consumption leads to immediate, significant reduction of energy use of up to 50% in some cases. What we offer are compact, state-of-the-art submeters, matched with user-friendly software and an inexpensive hardware interface. These are integrated in an easy-to-install but powerful system capable of remote, automatic reading and reporting to a local or remote computer or by e-mail. We offer submeters and submetering systems to meet the needs of homeowners, business owners, tenants and property owners, car charging station networks, solar/wind generation, farms, schools, and hospitals. We serve customers with as few as one meter or up to many thousands of metering points. ____________________________________________________ 100% Satisfaction Guaranteed!! Return within 30 days if you are not completely satisfied. Two year warranty from the manufacturer. For more information click here. What over 1000 satisfied eBay'ers are saying about the meters that we offer--100% Buyer Satisfaction!!! "Cool meter, good price and he got it here in a hurry. Thanks" "Great communication,dependable and honest, 2nd time buying, great meter" "Shipped fast-already installed-performing exactly as advertised. Great product!" "Awesome item. Works great!" "great value as described snap to install" "Very Quick delivery and works perfectly, easily installed, billing tenants now" "Great Product for the money, Just what I need, easy to install" "Easy to use just perfect thanks" "the greatest!!! fast shipping great meter. thanks" "High quality meter. Very fast shipping. Fast & friendly communication! A++++++++" "Good Seller, Fast Shipment. Very happy with product." "Awesome product. Great communication. Thanks" "excellent product & fast delivery!" "Fast delivery! Meter exactly as pictured. Seems to work great." "The product is first rate and the seller is even better.A+A+A+A+A+A+A+A+" "fast,helpful,friendly" "Great way to meter electricity for business use of home! Many thanks!!" "Works great. Just what I needed. Thanks." "Prompt shipment, well packed. Item exactly as described." "great product! as promised!" "Excellent transaction. Very fast shipping. The meter is great" "Excellent transaction. Meter exactly as advertised. Thanks" "WOW! What an Ebayer!! Stands by his product and services. BUY from this guy!!" "Was sent so fast it made my head spin. Perfect meter for billing rental customer" "very fast and helpful." "Super fast shipping Meter is exactly what I was looking for" "Meter arrived fast and safe, thanks" "thanks, great deal" "fast ship, product as described, A+++++++++++++++++++++++++++" "Very good customer service. HIghly recommended" "Smooth transaction. Quick ship. Excellent communication. KWH meter works fine$$$" "Love these meters!!" _gsrx_vers_779 (GS 7.0.4 (779))
