Us Free 3 Axis Cnc Kit 3 Nema23 270 Oz-in Stepper Motor + 3 Axis Cnc Board

US $163.00

New Jersey, United States
Jun 9th

Open on mobile:
QR code

Package include: 1 x 3 axis TB6560 Stepper Motor Driver board V type 1 x DB25 parallel cable 1 x Fan,4pcs M4 screw 3 x 23HS8430 stepper motor 1 x 250W 24V switching power supply English user manual for 3 axis driver board will send by email 3 axis CNC kit 3 NEMA23 270 oz-in stepper motor + 3 axis CNC board 1. 3 axis stepper motor driver board CNC stepper motor driver board TB6560,the new chip TB6560AHQ of TOSHIBA, the max ouput peak current can reach to 3.5A , this driver board can drive the 2-phase or 4-phase stepper motor whose current is less than 3A. Features: it can drive three axis,The 4th axis expansion, to facilitate your needs 4-axis machining when working Spindle relay output, easy to use software such as mach3 to control spindle start and stop. Semi-flow control functions, and effective to stop the motor when the current is reduced to a minimum. Interface with a fan, you can add fan under your choice. With 3 wire 0.8-3.5A (peak) rated output of two-phase adjustable-current bipolar stepper motor drive; Standard parallel port interface, support for MACH2, KCAM4 series software; With optical isolation and DCDC power supply isolation, the full protection of your computer parallel port and equipment; with limit switch,can connection 4 aixs limit switch Support four microstepping ——1,1/2,1/8,1/16 12—36V single switching power supply,microchips to use as a 5V power supply, stable and heat small Using RC +7414 automatic semi-flow,the current automatic reduce when stepper motor stop to down the heat 2. Stepper Motor Technical Specifications Part No.: 23HS8430 Frame Size: NEMA23 Step Angle: 1.8 degree Current: 3.0A/phase Resistance: 1.0 Ohm/phase Inductance: 3.5 mH/phase Holding torque: 180N.cm/18kg-cm 270oz-in Rotor inertia: 440g-cm2 Number of wire leads: 4 Weight: 1.05 kg Length: 76mm Shaft : single shaft,8mm diameter,21mm length with double 8mm flat length Note:if you need double shaft pls contact us,we can produce. RED: A+ GREEN: A- YELLOW: B+ BLUE: B- 3.Switching power supply 250W,Input:100-120VAC or 200-240VAC,50/60Hz,Output:24v/10A,single output switching power supply Shipping Please open the package and check if there are some damages before sign, if there are some damages , please do not sign and contact us immediately We ship to worldwide we can ship by DHL/UPS/EMS DHL/UPS 5-8 business days EMS 4-10 business days All items will be shipped within 1-3 business days upon receipt of payment Payment We accept Paypal only. Payment must be made within 48hours of the auction end time Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer responsibility. Problem&Feedback Please give us the opportunity to resolve any problem when you have,we concern your problem and we will try our best to resolve it. Pls email us before you want to leave any negative feedback Refund When you have the parcel,and not satisfied the goods or it is other problem like as broken,pls tell us the detail reason and provide the photos Any reason refund. Item must be in it's original condition and no physical damage. Buyer responsible for all shipping cost Contact us Welcome worldwide customer inquire and questions,we will try to do our best to feedback customer’s email within 1-2 business days,if not pls check the mail box again Customer’s satisfaction is very important to us. eBay Cross Border Trade powered by MerchantRun GlobalLink

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	RATTM MOTOR
Motor	270 oz-in stepper motor
Model	3 axis CNC kit
Driver	3A,3 axis
MPN	Does not apply
Power supply	250W,24V/10A
Country/Region of Manufacture	China
is_customized	Yes
UPC	Does not apply
