[us Free]square 2.2kw Quanlity Air Cooled Spindle Er20 Runout-off 0.01mm Cnc

US $342.00

Losangeles, United States
Jun 9th

Open on mobile:
QR code

Package include: 1 x 2.2Kw Square Air-cooled spindle motor(ER20220V,24000rpm,4 bearing,400Hz) 2.2KW ER20 Square Air-cooled Spindle motor Engraving milling Grind Specification: Material: Stainless Steel Size: Power: 2.2Kw Voltage: 220VAC Current: 6A Frequency: 0-400Hz Speed: 10-24000rpm Cooling: Air-cooled Runout off: Less than 0.01mm Bearing Lubrication: Grease Collet size: ER20 Bearings: 4 Ceramic bearing Net Weight: 4.9kg Main application: Wood, Aluminum, Stone, metal, glass, PVC industry Wiring:The spindle’s 1 connect Inverter’s U,spindle’s 2 connect Inverter’s V,spindle’s 3 connect Inverter’s W,spindle’s GND connect Ground,Spindle’s 4 and 5 connect thermistor,no need connector,the inverter’s R S T any 2 pins connect 220VAC 1. Structural features 1) High speed electric main bearing all adopt the Ceramic bearing, axis sets of loading, Improve spindle in the high-speed rotation supporting stiffness and precision grinding. 2) Before driving, rotation of the shaft by hand.Spindle high speed rotation caused by temperature rise, use of cooling liquid circulating system to eliminate. 2. Instructions for use 1) In use, must first connect the cooling water pipe, make spindle connect cooling water and then start. 2) Before driving, turned by hand spindle. If sensory block is not flexible, you should troubleshoot, and then check the direction of rotation of the spindle from the spindle end to see if the match should rotate counterclockwise power wiring should be changed to make it consistent. 3) Before driving, cooling water for grinding workpiece can’t be in the front end of the spindle cover, to prevent the front bearing cover slot inlet burning motor and bearing. the motor must not enter the water, after turned on of the motor, when you live in grinding the workpiece to open the grinding of workpieces coolant. First off the workpiece coolant shutdown, and then close the spindle motor. 3. Maintenance and Service 1) Motorized spindle by medium frequency power supply rated voltage, frequency should be consistent with electric spindle technology parameters, motorized spindle rotational speed can change the frequency to adjust, also directly proportional voltage change. 2) When the spindle is temporarily not in use, should use compressed air to blow the coolant water,to avoid rusting, plug the hole. Spindle surface should be coated with anti rust oil. The shaft end protecting device, placed in dry place. 3) If replacement the spindle of bearings, best professional and technical personnel from the replacement. Use special tools, stator coil does not to be removed. Shipping Please open the package and check if there are some damages before sign, if there are some damages , please do not sign and contact us immediately We ship to worldwidebut If your country's custom is strict, please contact us before you bid to check detail and confirmed. Payment We accept Paypal only. Payment must be made within 48hours of the auction end time . Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer responsibility. Contact us Welcome worldwide customer inquire and questions,we will try to do our best to feedback customer's email within 1-2 business days,if not pls check the mail box again . Customer's satisfaction is very important to us. eBay Cross Border Trade powered by MerchantRun GlobalLink

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	RATTM MOTOR
Power	2.2KW
Model	GDZ-80x73-2.2
Current	6A
MPN	Does not apply
Phase	3
Country/Region of Manufacture	China
Frequency	400Hz
Operating Speed	10-24000rpm
Collet	ER20
Drive	Motor
Voltage	220V
Application	Engraving
Bearing	Ceramic bearing
Cooling	Air cooled
is_customized	Yes
Runout off	<=0.01mm
UPC	Does not apply
