Usa Free Ship-3 Axis Nema 23 Stepper Motor 270oz-in,dual Shaft&tb6560 Board Cnc

US $150

Changzhou ,Jiangsu, China
Jan 29th

Open on mobile:
QR code

Great News! for USA buyers ,Ship from USA warehouse, after payment, within 3 days for receiving products! No taxes from customs, no damage, better service, please don't hesitate! This Item includes: 3 PCS Nema 23 Stepper Motors with 270oz-in holding torque,Dual Shaft ,57BYGH633B ,3A 1PC 350W,24VDC power Supply, 1 PC 3 Axis Control Board&1 PC Cable, 1 CD Disk & Mach3 Software offer for free , http://www.wantmotor.com 1, Stepper Motor Technical Specifications Part No.: 57BYGH633B Dual Shaft Frame Size: NEMA23 Step Angle: 1.8 degree Voltage: 3.0V Current: 3.0 A/phase Resistance: 1.0Ohm/phase Inductance: 1.6mH/phase Holding torque: 13.5Kg-cm 191oz-in , with unipolar (For Bipolar connecting, the holding torque is 270oz-in) Rotor inertia: 480 g-cm2 Detent torque: 0.68 kg-cm Number of wire leads: 6 Weight: 2.20lb (1.0 kg) Length: 78mm Please tell us if you need Double shaft or single shaft, we can manufacture both for you. If you need Double shaft, please tell us your requirements for length of front and rear shaft, as well as the diameter. So that we can offer you the quite good products, thanks! 2, 3 Axis Driver Board Products Features : 1:The maximum 3.5A drive current to a maximum 86 stepper motor drives, more powerful 2:1-16 sub-setting, higher accuracy, smoother operation 3:Overload over-current over-temperature protection, full protection of your computer and peripheral equipment 4:4 files current settings can be set according to the user the actual current requirement 5:Full closed-type optical isolation to protect the user's computer and equipment 6:Professional design, two-stage signal processing, super anti-jamming 7: Bipolar constant current chopper drive motor low-speed non-creeping phenomenon, noise, non-resonant region? 8: 2-way output control, scalable fifth axis or 2-way control of external equipment. 9: Four input control, you can set limit, emergency stop, which is divided into pairs of knives. Please note the following before the test items 1, To determine the size of the supply voltage and current 2, Determine the stepper motor power and current (model) 3, Determine the stepper motor wiring 4, Power Please take 12 ~ 36V 8A (stepper motor in accordance with the work of current matching) The above switching power supply, I received a map indicating the power input interface? 12V power output for a 12V cooling fan to pick up where? The definition of 1-PIN 25 of Parallel Interface is described as follows: PIN9 PIN14 PIN7 PIN1 PIN2 PIN3 PIN8 PIN6 PIN4 PIN5 PIN16 PIN17 spindle motor X Empower X Dir X Step Y Empower Y Dir Y Step Z Empower Z Dir Z Step Expand output 1 Expand output2 The definition of 1-PIN15 of Manual Interface is described as follow(Click the image to upper right for the P1 left P15) P1 P2 P3 P4 P5 P6 P7 P8 P9 P10 P11 P12 P13 P14 P15 X Step X Empowe spind X Dir Y Empowe Z Dir Z Step Z Empowe Y Limit Z Limit Y Dir Y Step STOP GND 5v/VDD Limit Switch Description Input 1 Input 2 Input 3 Input 4 Corresponding parallel P10 Corresponding parallel P11 Corresponding parallel P12 Corresponding parallel P13 Output Interface Definition: P1 P2 P3 P4 P5 P6 P7 P8 P9 P10 P11 P12 P13 P14 P15 P16 P17 VDD GND XA+ XA- XB+ XB- YA+ YA- YB+ YB- ZA+ ZA- ZB+ ZB- MO/V+ GND MO - 3, Power Supply 350W / 24VDC We ship worldwide! Our Products are mainly used in robotization, Spinning Automatization, Printing, Packing, Medica Machine, Make-up Equipment, Communication, Household Appliance, Water Pump, Milling Machine, Engraver Machine, CNC Routers.. etc automatic equipment of various trades. We product all kinds of motors & driver. And we can manufacture products according to our customer's design. Currently we are looking for qualified stocking distributors with competitive price and good discount in United States & Canada for mutually beneficial long-term relationship. We try our best to support our distributors and business partners to develop more market percentage. Please join us, let’s create the glorious future together! You can add my MSN: saron1@live.cn or Skpye: happy_saron Wantai Electrical Appliance Co., Ltd http://www.wantmotor.com Phone: 0086-13401312691 MSN: saron1@live.cn Skype: happy_saron E-mail: saron1@live.cn

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Wantai Motor
Country of Manufacture	China
Model	57BYGH633B
