Usb Eight Channel Relay Board (jqc-3fc/t73) For Automation - 12 V

US $280

Europe, Bulgaria
Jun 9th

Open on mobile:
QR code

Denkovi Assembly Electronics ltd. USB Eight Channel Relay Board (JQC-3FC/T73) for Automation - 12 V General description General description: This is USB controlled relay board with 8 relays JQC-3FC/T73. You may use it for simple ON/OFF switching electrical devices - home lights, DC motors, solenodis and others. It may help you building projects like robotics and home automation. Each such board requires one USB port. The more USB ports you have the more Relay boards you may connect. You may use it with our software - DRM Software (universal software for all our relay boards) or control with simple commands from command line promt. If you are developer and need software example, please contact with us. Characteristics: 8 SPDT relays JQC-3FC/T73 Relay specification - 7A / 250VAC,10A / 125VAC, 10A / 28VDC, 12A / 120VAC Power Supply - 12 VDC Current consumption - 300 mA FT245RL. Datasheet - here Leds: Relays, Power, USB Size - 106mm / 78mm / 16mm Supported by DRM software (Windows 32/64 and Linux 32) Supported by Denkovi Relay Command Line Tool (Windows 32/64 and Linux 32) - New Software examples: VB6, BCB6, Java, .NET 2010 Express, LabVIEW Please contact with us for download. PCB parameters: FR4 / 1.5mm / two layers / metalized holes / HAL / white stamp / solder mask Extra PCB openings for better voltage isolation Doubled high current tracks Product code: DAE-CB/Ro8/12V-JQC-USB The auction includes 1 x USB Eight Channel Relay Board, 12V DRM Software - Denkovi Relay Manager Software. CD is not included in the package but the software is available for download from this link USB 8 Relay Manager - Relay Manager and Timer from Denkovi for USB Eight Channel Relay Board. CD is not included in the package but the software is available for download from this link -USB8RelayManager.exe Denkovi JExtraPack - Three Java applications for USB Eight Channel Relay Board. CD is not included in the package but the software is available for download from this link -DenkoviJExtraPack.exe Information that may help you Each such board is shown as separate virtual com port (VCP) on your PC. The relay board outputs are controlled by FT245RL. It has 8 bit data output register. When data is sent to the register the outputs are set. Be sure "Synchronous Bit-Bang Mode" is selected! Also the baudrate must be set with high value - 921600 (to avoid the latency if any). FTDI provides Bit-Bang Mode documentation. See this. The board can not be controlled directly via COM port - it is need to have special applicatios downloadable in this acution. For software examples, please contact with us. Important: When the board is connected to the PC and/or the PC is restarted, the relays(1,3,5) will be toggled several times. This is because of the structure of the FTDI chip. (You can avoid this if you first connect the USB cable and then supply the relay board) There is no protection against reversed voltage! If the +12V and GND are reversed the board will be damaged! The item can not work without computer Supply characteristics Type DAE-CB/Ro8/12V-JQC-USB Recommend voltage VDC 12 Voltage limits Including ripple VDC 11...14.4 Nominal input current Voltage 12VDC mA 300 Power dissipated When all relays are ON W 3.6 Protection Against reverse polarity None Relay output characteristics Type DAE-CB/Ro8/12V-JQC-USB Relay type JQC-3F/T73 Relay outputs count 8 Contact type NO, NC Current consumption 12 VDC mA 30 Switching parameters 120 VAC 125 VAC / 28 VDC 250 VAC A A A 12 10 7 Phisical characteristics Type DAE-CB/Ro8/12V-JQC-USB Dimensions Width Height Length mm mm mm 106 16 78 Weight gr PCB FR4 Height Layers Metalized holes HAL White stamp Solder mask mm Yes 1.5 2 Yes Yes Yes Yes Mounting holes diameter inner side mm 3 Leds Relays (green) USB conected (red) Power (red) Yes Yes Yes USB port terminal Yes Schematics How to connect inductive loads Software Examples We can provide examples for the following platforms, please contact with us: Visual Basic 6 Borland C++ Builder 6 VB.NET Express 2010 C#.NET Express 2010 Labview 2011 Java example for Windows/Linux Python command line example for Linux Here it is an example for Labview which we created for our customers Control Relays from Command Line Denkovi Relays Command Line Tool The main goal of this project is to help you to use our USB relay boards easily and without any specific knowledge how do they work. This tool is actually shell for all our USB relay boards and it does not matter which is the relay board, the command is the same. Just type one command and the the tool will set, get relay status or even will take temperature value from the board sensor (if any). It can be integrated in other software and you don't need to know much about how the USB relay board protocol. With this tool it is like a "game" and it takes literaly minutes to create for example PHP script and control the USB relay board from smartphone browser. Typical applications for this software are: Create desktop icons to turn particular relays Create BAT/BASH files to make more complex logic (like timers for example) The commands can be executed from PHP script Control our USB relay boards from Android / iPhone mobile devices The USB relays can be controlled from each software/platform which can run external executable files or commands in command line promt Example commands: LIST COMMAND - lists all devices connected to computer. java -jar DenkoviRelayCommandLineTool.jar list STATUS COMMAND - display relay(s) status(es). java -jar DenkoviRelayCommandLineTool.jar DAE0006K 8 1 status java -jar DenkoviRelayCommandLineTool.jar DAE0006K 8 all status SET COMMAND - set relay(s) state(s). java -jar DenkoviRelayCommandLineTool.jar DAE0006K 8 5 1 java -jar DenkoviRelayCommandLineTool.jar DAE0006K 8 all 0 java -jar DenkoviRelayCommandLineTool.jar DAE0006K 8 turn 10101010 For more information - here For tool download - here Demo video how you can control the USB 8 Channel relay board from command line, browser and tablet the same time because of our command line tool. DRM Software DRM Software Denkovi Relay Manager (DRM) is multiplatform software for easy controlling all kinds of Denkovi relay boards (USB,SNMP,TCP/IP) CAUTION! Using of Denkovi Relay Manager (DRM) Software with devices which are not manufactured by Denkovi Assembly Electronics LTD is not allowed! The item is supported by DRM Software. DRM Software will hep you to save money for expensive software and time in programming. It allows you to switch ON/OFF your devices at particular date and time, turn ON/OFF the relays with pulses or control them via specific sequence. If you have ordered at least one of our relay boards from this list you may turn your PC in powerful automation tool. Multiplatform software: supported by Windows/Linux (ver. 2.0) Control up to 32 relay boards User-friendly intuitive interface Save/Load file Control mode: single and multiple setting of the relays Single pulse with adjustable delay from the control mode (ver. 2.0) Timer mode: create timer playlist for the relays Weekly mode: each relay may be turned ON/OFF on each day of the week Calendar mode: each relay may be turned ON/OFF on particular date at particular time Pulse mode: each relay may work in pulse mode by setting duration for ON and duration for OFF. Adjustable number of pulses (ver. 2.0) Each relay from each relay board can work independently in some of the five modes Each relay board and each relay can be named by the user Indicator panel Auto load function - the last working file is loaded when DRM is started Auto connect function - when the relay board is disconnected DRM will keep trying to find and when this is done, the relay board will be connected again Auto start function - DRM software starts when the OS starts (currently this is not available for Windows 8 and Linux) Auto set function - DRM will set the relays automatically when the relay board is connected Possibility of DRM to starts when PC boots and continues to work from the last saved point For more information about DRM Software, screen-shots, detailed description and download - here DRM Software image - control mode for USB Eight Channel Relay Board Demo video with DRM Software and USB Eight Channel Relay Board USB Relay Manager USB 8 Relay Manager USB 8 Relay Manager is application for controlling USB Eight Channel Relay Board CAUTION! Using of USB 8 Relay Manager with devices which are not manufactured by Denkovi Assembly Electronics LTD is not allowed! This is application that allows the USB 8 relay board to be controlled from your PC. There is two modes - Manual Mode and Timer mode. You may open many USB boards and select wich one to control. There are 8 indicators representing each relay channel led from the board. Manual Mode By selecting this mode you are able to select wich relays are turned ON and wich OFF with 8 buttons. Timer Mode With this mode it is realized way of automation controling. You may create your own algorithm, suitable for your project and run it. Delays and states may be given. You may adjust the timer resolution. You may save and load your own program. For more information about USB 8 Relay Manager, screenshots and detailed description - here Download the last version (install package) - USB8RelayManager.exe Download the last version (install archive) - USB8RelayManager.rar For bugs, suggestions or more information, please contact with us Denkovi JExtraPack Denkovi JExtraPack Denkovi JExtraPack is packet from 3 applications for our device - USB Eight Channel Relay Board CAUTION! Using of Denkovi JExtraPack with devices which are not manufactured by Denkovi Assembly Electronics LTD is not allowed! Denkovi JExtraPack contains 3 applications. Each of these applications are written in Java, so JVM is required. Each application can control up to 10 USB relay boards so you will need of course FTDI VCP drivers. We provide single installation file and everithing is included in it. Manager This is manager that allows simple and easily toggling the relays. It contains eight relay toggle buttons and two for all on/off. The application can handle up to 10 USB Relay Boards at a time. The main advantage is that you can select which board to control and toggle the exact relay. On the first image right to the text it is shown how sholuld look like the normal running application. Timer This is windows application for switching on/off up to 10 relay boards with your PC. You can give different states, sequences and delays for each relay and each connected board on your PC. You can save your algorithm in file and load it. Alarm This is windows application for switching on/off up to 10 relay boards with your PC. Each relay can be set on/off depending on the date and time. You add, change or delete states. You can save your schedule in file and load it. For more information about Denkovi JExtraPack, screenshots and detailed description - here Download the last version (install package) - DenkoviJExtraPack.exe Download the last version (install archive) - DenkoviJExtraPack.rar For bugs, suggestions or more information, please contact with us Demo video Control USB 8 Channel Relay Board from Android Tablet browser. The tablet access the PHP server machine to which is connected the relay board. Demo Video - DRM Software and 4 x USB Eight Channel Relay Boards Pictures Useful links FTDI web page - here FTDI drivers page - here FT245RL page - here FTDI official page with source code examples - here FT245RL documentation - here Programming guide for FT245RL - here FT245RL Bit Bang Mode - here DRM Software download - here USB 8 Relay Manager - USB8RelayManager.exe Denkovi JExtraPack - DenkoviJExtraPack.exe Command line software download - here Please read before buy Contact information Skype: borislav__denkov
