Usb2.0 Fullspeed16 Channels La1016 Logic Analyzer 100m

US $398.99

default, default, Hong Kong
Mar 26th

Open on mobile:
QR code

DXL360S Digital Protractor Incli USB2.0 fullspeed16 channels LA1016 Logic Analyzer 100M Product Description SWLA1016 USB 2.0 full-speed 16 channels Logic Analyzer 100MHz Sample rate and 33MHz Measuring Bandwidth Signal Sampling Rate: 100MHz (max) Hardware Filtering: 2 levels Real-time Displaying Rate: 100MHz (max) Dynamic Data Recording: Supported Measuring Bandwidth: 33MHz Storage Depth per Channel: 32Kbits Input Impedance: 500Kohm Input Signal Voltage Range: 0 ~ 5V Triggering Voltage Type: TTL/CMOS USB Version: USB2.0 Full Speed Trigger Position Setting: Supported (Allows any triggering position for better observations) Trigger Condition Levels: 16 levels Logic Pen: Supported Supported Operating System: Windows XP, Windows 2000, Windows Vista (Coming soon) Software Interface Advantages: Brand-new trigger measurement method and brand-new analyzer method makes the measure process even more quick and simple LA1016 can set edge, level, bus trigger methods and so on, very easy to use; Dynamic data recording enables you get the depth and accuracy of data at the same time; The innovation data analyzer functions make your life more easier while analyzing UART,SPI,I2C data; The brand-new multi- documents structure may enable you to observe and to compare other data during measurement Multi-method Data Export functions make the re-analyzer measure data possible and easy Nimble measure frequency setting break the traditional 1, 2, 5 encode methods, make the measurement more precision. USB 2.0 full speed interface, plug and play; Small size like a normal business card, portable Dynamic algorithm update always make your job on the leading edge Specification: Signal Sampling Rate 100MHz(max) Real-time Displaying Rate 100MHz(max) Measuring Bandwidth 33MHz Storage Depth per Channel 32Kbits Input Impedance 500Kohm Input Signal Voltage Range 0~5V Triggering Voltage Type TTL/CMOS USB version USB2.0 full speed Hardware filtering 2 levels Trigger Position Setting Supported(Allows any triggering position for better observations) Trigger Condition Levels 16 levels Logic pen supported Supported Trigger Methods: Edge Trigger Supported Data Trigger Supported Bus Trigger Supported Data sequencing Supported Trigger Data width Trigger Supported Delay Trigger Supported Data show up times Trigger Supported Data>,<Comparison Supported Visible Trigger Supported Features: Smart warning Dynamic Measure Signal Group Multi-measure display Creating waveform pictures Waveform search Auto updating Multi interfaces styles CSV data export Add-on Toolbar BIN data export Dada Bus Analyzer: UART bus Analyzer I2C Bus Analyzer Meiler data buses Analyzer A/D Transfer Analyzer SSI bus Analyzer SPI Bus Analyzer Manc Hester code Analyzer 1-Wire Bus Analyzer Protocol Analyzer SD/MMC card SPI mode Analyzer CF card True IDE mode Analyzer MODBUS protocol Analyzer 8051 Assembly LA/LAP Family Logic Analyzer Selection Guide Types LA1000 Series LA2000 Series LA5000 Series Basic Types Enhanced Types Big Memory Types Enhanced Types Big Memory Types Basic Types LA1016 LA1024 LA1032 LA1232 LA1432 LA1532 LA1732 LA1832 LA2232 LA2432 LA2532 LA2832 LA2932 LA5034 Input Channels 16 24 32 32 32 32 32 34 Max. Timing Sampling Rate 100M 100M 100M 200M 200M 500M Max. State Sampling Rate - 30M 30M 80M 80M - Memory Size 512Kbits 768Kbits 1Mbits 4Mbits 16Mbits 32Mbits 256Mbits 512Mbits 4Mbits 16Mbits 32Mbits 512Mbits 1Gbits 64Kbits Storage Depth / Channel 32K 128K 512K 1M 8M 16M 128K 512K 1M 16M 32M 2K Triggering Position Beginning, Center, Ending, User Defined Beginning, Center, Ending, User Defined Beginning, Center, Ending, User Defined Beginning, Center, Ending, User Defined Beginning, Center, Ending, User Defined Beginning, Center, Ending, User Defined Supported Signal Type TTL/CMOS TTL/CMOS Single-End Single-End Single-End Single-End Single-End Single-End Trigger Level TTL/CMOS TTL/CMOS 0~4.6V -4V~+4V -4V~+4V -4V~+4V -4V~+4V -5V~+5V Triggering Modes Fast, visible Fast, visible, Advanced, Plug-in Fast,visible,Advanced,Plug-in Fast,visible,Advanced,Plug-in Fast,visible,Advanced,Plug-in Fast,visible,Advanced,Plug-in Fast,visible,Advanced,Plug-in Analysis Functions Bus, Protocol Bus, Protocol,Code Bus, Protocol,Code Bus, Protocol,Code Bus, Protocol,Code Bus, Protocol,Code Probes Type Passive Passive Passive Passive Passive Passive Data Recording Mode Timing Timing-StateTiming, Timing,State,Timing-State Timing,State,Timing-State Timing,State,Timing-State Timing,State,Timing-State Timing,Timing-State On Aug-12-14 at 02:32:15 PDT, seller added the following information: Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
