USB 2.0 full-speed 32 channels Logic Analyzer 100MHz Sample rate and 30MHz Measuring Bandwidth Signal Sampling Rate: 100MHz (max) ■ Hardware Filtering: 2 levels Real-time Displaying Rate: 100MHz (max) ■ Dynamic Data Recording: Supported Measuring Bandwidth: 30MHz Storage Depth per Channel: 128Kbits Input Impedance: 1MΩ Input Signal Voltage Range: -30V ~ +30V Triggering Voltage Type: TTL/CMOS Triggering Voltage range: -4V ~ +4V USB Version: USB2.0 Full Speed Timing-state mode: Supported Trigger Position Setting: Supported (Allows any triggering position for better observations) Trigger Condition Levels: 256 levels Logic Pen: Supported Supported Operating System: Windows XP, Windows 2000, Windows Vista (Coming soon) Data>,<Comparison： Supported Visible Trigger： Supported Software Interface: To get the large picture: http://www.analogtechnologies.com/ebay/Kits/photo/photo/Logic_analyzer/Soft_interface.jpg Advantages: Brand-new trigger measurement method and brand-new analyzer method makes the measure process even more quick and simple LA1232 can set edge, level, bus trigger methods and so on, very easy to use; Dynamic data recording enables you get the depth and accuracy of data at the same time; The innovation data analyzer functions make your life more easier while analyzing UART、SPI、I2C data; The brand-new multi- documents structure may enable you to observe and to compare other data during measurement Multi-method Data Export functions make the re-analyzer measure data possible and easy Nimble measure frequency setting break the traditional 1, 2, 5 encode methods, make the measurement more precision. USB 2.0 full speed interface, plug and play; Small size like a normal business card, portable Dynamic algorithm update always make your job on the leading edge Specification: Signal Sampling Rate: 100MHz(max) Real-time Displaying Rate 100MHz(max) Measuring Bandwidth： 33MHz Storage Depth per Channel： 128Kbits Input Impedance： 1MΩ Input Signal Voltage Range： -30～+30V Triggering Voltage Type： TTL/CMOS USB version： USB2.0 full speed Trigger Position Setting： Supported（Allows any triggering position for better observations) Trigger Condition Levels： 256 levels Logic pen： supported Supported Operating system： Windows 2000，Windows XP Supported Trigger Methods: Edge Trigger： Supported Data Trigger： Supported Bus Trigger： Supported Data sequencing Trigger： Supported Data width Trigger: Supported Delay Trigger： Supported Data show up times Trigger： Supported Data>,<Comparison： Supported Visible Trigger： Supported Advanced Trigger： Supported Features: Smart warning Dynamic Measure Digital filtering Attaching markers Signal Group Multi-measure display Creating waveform pictures Waveform search Auto updating Multi interfaces styles CSV data export Add-on Toolbar BIN data export Dada Bus Analyzer: UART bus Analyzer I2C Bus Analyzer Meiler data buses Analyzer A/D Transfer Analyzer SSI bus Analyzer SPI Bus Analyzer Manc Hester code Analyzer 1-Wire Bus Analyzer Protocol Analyzer SD/MMC card SPI mode Analyzer CF card True IDE mode Analyzer MODBUS protocol Analyzer Code Analyzer: 8051 De-assembly Frequency Counter: Each POD Channel ZERO can be used as Frequency Counter (10Hz-50MHz) The whole package includes: LA1232 Logic Analyzer: 1 unit LA1232 measurement leads: 1 unit USB cable: 1 unit DC5V Power Supply English Driver and manual on CD: 1 unit Click here to download the Driver: http://www.analogtechnologies.com/Aidepro/ZLG/Logic_analyzer/la_v4.exe One-year Warranty from the manufacturer LA/LAP Family Logic Analyzer Selection Guide Types LA1000 Series LA2000 Series LA5000 Series Basic Types Enhanced Types Big Memory Types Enhanced Types Big Memory Types Basic Types LA1016 LA1024 LA1032 LA1232 LA1432 LA1532 LA1732 LA1832 LA2232 LA2432 LA2532 LA2832 LA2932 LA5034 Input Channels 16 24 32 32 32 32 32 34 Max. Timing Sampling Rate 100M 100M 100M 200M 200M 500M Max. State Sampling Rate － 30M 30M 80M 80M － Memory Size 512Kbits 768Kbits 1Mbits 4Mbits 16Mbits 32Mbits 256Mbits 512Mbits 4Mbits 16Mbits 32Mbits 512Mbits 1Gbits 64Kbits Storage Depth / Channel 32K 128K 512K 1M 8M 16M 128K 512K 1M 16M 32M 2K Triggering Position Beginning, Center, Ending, User Defined Beginning, Center, Ending, User Defined Beginning, Center, Ending, User Defined Beginning, Center, Ending, User Defined Beginning, Center, Ending, User Defined Beginning, Center, Ending, User Defined Supported Signal Type TTL/CMOS TTL/CMOS Single-End Single-End Single-End Single-End Single-End Single-End Trigger Level TTL/CMOS TTL/CMOS 0～4.6V -4V～+4V -4V～+4V -4V～+4V -4V～+4V -5V～+5V Triggering Modes Fast, visible Fast, visible, Advanced, Plug-in Fast,visible,Advanced,Plug-in Fast,visible,Advanced,Plug-in Fast,visible,Advanced,Plug-in Fast,visible,Advanced,Plug-in Fast,visible,Advanced,Plug-in Analysis Functions Bus, Protocol Bus, Protocol,Code Bus, Protocol,Code Bus, Protocol,Code Bus, Protocol,Code Bus, Protocol,Code Probes Type Passive Passive Passive Passive Passive Passive Data Recording Mode Timing Timing-StateTiming, Timing,State,Timing-State Timing,State,Timing-State Timing,State,Timing-State Timing,State,Timing-State Timing,Timing-State Shipping/Return Policy: 1) Normally your order will be shipped within 1-3 business days after your payment is clear, you will receive an e-mail that confirm your order has been shipped within 1-3 days after we receive the payment. 2) For domestic order, the delivery time is 3-5 days by USPS first class mail, the track number is available upon request, Fast shipping is always available by paying USPS express shipping cost. 3)International shipment: The delivery time to Europe is around 7-14 days via postal office air letter/parcel post, there is NO track number for this method, According to our experience, 1% packages will got lost by using this method. You are very welcomed to buy insurance in order to avoid this 1% risk. Or you can paying more for USPS express shipping with track number, it takes around 5-7 days to arrive, sometimes the packages may get delayed at your country's custom for several days. 4) Multiple item shipping is OK. Discount shipping prices are given for shipping multiple items in one package to one address: regular price for the 1st item and 30% off for additional items. This discount can only be applied to the item that has lower shipping cost compared with the shipping cost of the 1st item. 5) If you have not got your order within 21 days after your payment is clear, please DO e-mail us your paypal date and your item # and your shipping address, we will track your order, and get your back in 1-2 business days. 6) If you are not satisfied with your order, you can return in 14 days with full money refund (except shipping) as long as the products are in the original shape. 7) We are trying our best to improve our customer service, if you have any questions and concerns, please feel free to e-mail to: staff@smtzone.com. Thanks for interesting in our products and good luck. This web is © Copyright ATI 2005-2007, All Rights Reserved. Buy our other best products to get 30% discount on shipping, plus you can free upgrade to 5-7 days EMS shipping if you buy 4+ items, click the image to to buy it now: 12 3 45 678 On Sep-22-08 at 03:16:40 PDT, seller added the following information:Click here to download the manual: http://www.aidetek.com/New_products_info/Datasheet/Logic_Analyzer/Logic_En.pdf
