Utc,ge,lenel,casi Rusco 8rp Board 110100501 Acces Control Module

US $700

Seattle, Washington, United States
May 25th

Open on mobile:
QR code

This new in sealed box never used just getting rid of some over stock. Compare to $1200.00 this should go fast. Product Data Sheet 110100501 8RP, Reader Processor, Micro/5 Overview The Micro/5 8RP is an eight-port reader option board suitable for use with F/2F and supervised F/2F readers. The 8RP is compatible with all GE Micro/5 microcontrollers and access control system software. Micro/5 Configuration Flexibilty You can free up three Micro/5 card slots by configuring one 8RP in place of four 2RPs saving card slots which can be used for 20 DI and 16 DO/DOR options. Micro/5-PX 16 Reader Support Up to two 8RPs can be configured into a Micro/5-PX or Micro/5-PXN microcontroller, substantially reducing the cost per door for access control. Long Reader to Microcontroller Cable Lenghts The 8RP has built-in pull-up resistors - making the microcontroller-to-12 VDC reader cable lengths of more than 150 m possible. In specific configurations, select GE readers support cable lengths of up to 1,500 m. Reader Supervision Reader tamper, cable problem and reader failure detection are provided by a ''heartbeat'' signal which is passed between the supervised reader and the 8RP. When a problem is detected, an alarm is generated at both the reader and the host system. Product Content The Micro/5 8RP includes the eight-port reader processor, and screw terminal pluggable field wiring connectors. Standard Features Allows up to 16 readers per microcontroller E Supports F2F proximity readers E Supports supervised F2F proximity readers E Can be used with Wiegand Interface Unit to support Wiegand readers E Built-in pull-up resistors E Up to 8 DO, one per reader E 110100501 8RP, Reader Processor, Micro/5 Specifications DO rating 0.10 A at 12 VDC Readers supported Only F2F and SF2F readers Wiegand readers require a WIU-2 or WIU-4 Notes The 8RP has one door DO point for each of the eight supported readers. The door DO is used to drive the reader LED and the external door relay. A door relay, door-strike protection diode, IN4002, IN4003 or IN4004, is required for DC-powered door strikes while an MOV is required for AC-powered door strikes. Diodes and MOVs are supplied items. Micro/5-PX and Micro/5-PXN: 16 reader-one 8RP is powered from the Micro/5 Power/Communication board while other is powered from the Micro/5 backplane. Both Secure Perfect and Picture Perfect support 2x 8RP's per Micro/5. Ordering Information Part No. Description 8RP, Reader Processor, Micro/5 110100501 As a company of innovation, UTC Fire & Security reserves the right to change product specifications without notice. For the latest product specifications, visit UTC Fire & Security online or contact your sales representative. IPS-HQ-110100501-2012-05-4 12:01:01
