Verticle/horizontal Mill Power Table Feed -- How I Built Mine

US $8.00

  • Allegan, Michigan, United States
  • Jan 30th
Open on mobile:
QR code
THIS  ITEM IS A PDF FILE THAT COMES ON CD AND TELLS YOU --HOW I BUILT MINE--.    I have a small vertical mill and wanted a power table feed but I couldn't find one to fit. I decided to build my own. I used a mig welder wire feed drive and designed my own electronic drive circuit for that. this could easily be driven from a 24v battery charger (from 120v) but I used 24 vdc from battery as I live from solar and battery power. my unit has FOR/REV , speed adjustment , rapid traverse , and table travel limit option.  this pdf shows the mechanical design and the electronic circuit I built to control it. if you chose to build one like it , there is electronic type soldering involved.    This pdf file will show you how I built mine.   SORRY BUT I DO NOT SHIP OUTSIDE THE US. I AM WORKING ON A DOWNLOADABLE OPTION FOR SALES OUTSIDE THE US. CONTACT ME.     If you are interested in other pdf files on free diesel fuel , free heat, or other off the grid designed items , check out my store .  if you are interested in ALL of my -how I built mine- pdfs , then check out my HANDYMAN SPECIAL where you get -all- of my pdfs for one price -and an option for yearly updates as new files come or other are updated.     if you have questions please don't be shy. thank you   mike
