Very Nice Knight Electronics Ml-2010 Mini Lab Trainer With Locking Case Ml2010

US $249.95

Sunnyvale, California, United States
Jan 29th

Open on mobile:
QR code

Very Nice Knight Electronics ML-2010 Mini Lab Trainer with Locking Case ML2010 Very Nice Knight Electronics ML-2010 Mini Lab Trainer with Locking Case ML2010 The ML2010 is a complete prototyping station and has been designed to consolidate all of your test equipment needs into one compact package. This miniature laboratory used in conjunction with an oscilloscope and multimeter puts everything you need at your fingertips for building and testing all types of digital and analog circuits. Specifications: POWER INPUT: 120 VOLT AC 50/60 HZ FUSED (2A 250V, 5x20mm GLASS, FAST ACTING) LIGHTED POWER ON INDICATOR DC POWER SOURCES: +5 VOLTS ±3% @ 1 AMP -5 VOLTS ±3% @ 1 AMP +12 VOLTS ±3% @ 1 AMP -12 VOLTS ±3% @ 1 AMP 0 TO >+18 VOLTS VARIABLE @ 1 AMP 0 TO >-18 VOLTS VARIABLE @ 1 AMP (ISOLATED GROUND FOR VARIABLE SUPPLIES) 0.1% LINE REGULATION 0.1% LOAD REGULATION SHORT CIRCUIT AND THERMAL OVERLOAD PROTECTED AC POWER SOURCE: 15 VOLTS CENTER TAPPED @ 500 MILLIAMPS PULSE GENERATOR: CONTINOUSLY VARIABLE IN FIVE DECADE RANGES: PULSE WIDTH: = 100nSEC TO =10mSEC PULSE REPETITION: = 1uSEC TO = 100mSEC OVERLAP INDICATOR CAPABLE OF 100% DUTY CYCLE PULSE POSITION AND WIDTH MODULATION INPUTS TTL COMPATIBLE GATE AND TRIGGER INPUTS RISE AND FALL TIMES LESS THAN 10nSEC SWEEP RAMP GENERATOR: ADJUSTABLE PERIOD - = 1mSEC TO = 1SEC ADJUSTABLE 0 TO 3.7 VOLT OUTPUT AMPLITUDE NEGATIVE LINEAR RAMP OUTPUT FOR LINEAR SWEEP SEPARATE TTL COMPATIBLE SYNC OUTPUT FUNCTION GENERATOR: SINE, SQUARE, OR TRIANGLE WAVE OUTPUT 0 TO 18 VPP OUTPUT AMPLITUDE ~500 OHM OUTPUT IMPEDANCE SHORT CIRCUIT PROTECTED DC OFFSET ADJUSTABLE FROM 0 TO %10 VOLTS SEPRATE TTL/HC COMPATIBLE CLOCK OUTPUT (20mA OUTPUT AT 0.33VDC (LOW) OR 4.3VDC (HIGH) RISE/FALL TIME LESS THAN 20nSEC CONTINUOUSLY VARIABLE FREQUENCY FROM 1HZ TO 1MHZ IN SIX DECADE RANGES (NOTE: DUE TO LIMITATIONS OF THE FUNCTION GENERATOR CHIP WAVEFORM VARIATIONS, OR ROLL OFF, MAY BE EXPERIENCED AT THE MAXIMUM RANGE.) DISTORTION: SINE WAVE = 2% TO = 100KHZ TRIANGLE WAVE = 2% TO = 100KHZ RISE & FALL: SQUARE WAVE <= 20nSEC FREQUENCY MODULATION INPUT AMPLITUDE MODULATION INPUT BURST INPUT SWEEP INPUT CAPABLE OF 1000:1 SWEEP (START FREQUENCY DETERMINED BY SWEEP RAMP AMPLITUDE STOP FREQUENCY DETERMINED BY GENERATOR FREQUENCY SETTING) SPEAKER: 2- 1/4 "e; 8O 0.25W POTENTIOMETERS: UNDEDICATED 1KO AND 100KO LINEAR TAPER 20% 0.125W INDICATORS: EIGHT BUFFERED LED CMOS/TTL COMPATABLE) SWITCHES: EIGHT LEVEL - 0V OR +5V UNBUFFERED TOGGLE SWITCHES TWO UNDEDICATED SPDT TOGGLE SWITCHES [ON - NONE - ON] TWO UNDEDICATED SPDT MOMEMTARY [ON - NONE - (ON)] PULSERS: TWO TTL LEVEL DEBOUNCED PULSERS WITH COMPLEMENTARY OUTPUTS INTERFACE: DB25 MALE -; DB9 MALE - DB25 FEMALE DB25 FEMALE - DB9 FEMALE - DB25 FEMALE (DB25 TO DB25 PINNED 1 TO 1 WITH DB9 COMMON TO FIRST 9) THREE BNC TO TIE-POINT BLOCK Details: Manufacturer: Knight Electronics Model: ML-2010 Includes Operations Manual and power cable Condition: Excellent cosmetic condition with little or no sign of previous use (See photos for more detail). Tested: Unit was removed from a working environment Warranty: 14-Day Right-of-Return SKU: 398312 Please review our Help page for all of our Terms and Conditions before bidding or purchasing. By bidding or purchasing our merchandise, you are agreeing to these terms and conditions. Questions? Send us a message SALE TERMS AND CONDITIONS: Only the pictured items are included in the listing, if it is not pictured or mentioned in the description it is not included. Place a bid only if you intend to purchase the item. If payment is not received within 3 days, the item(s) will be relisted at our discretion. PAYMENT INFORMATION: Payments are expected in a timely manner. Please contact us in the event that payment cannot be made within three days. Payment arrangements can be made. We accept: PayPal, All Major Credit Cards, and Bank Wire Transfers in USD (There is a $25 wire transfer fee). A 8.75% Sales tax applies to CALIFORNIA residents unless a resale tax form is provided for our records. We cannot process the order until we receive sales tax or a copy of your CA BOE-230. If you would like to pay using a credit card, please call us at (408) 743-5609. Click Here for Payment and Purchase Policies ** Resellers Click Here ** WARRANTY: *Please see listing above for the warranty that applies to this item. AS-IS, No Warranty: When an item is stated as being AS-IS, the condition of the item is either unknown or has known issues (as stated in the description) and does NOT carry any warranty and NO returns will be accepted for this item. 14-Day Right-of-Return: You have fourteen (14) days to contact us for a replacement or refund. We can not warranty compatibility with your equipment, or warranty items that have been modified or altered. We maintain the right to use our descretion when choosing between a replacement or refund. 30-day Warranty: When an item carries a 30-day warranty, you have 30-days to contact us for a replacement or refund for a defective product. We can not warranty compatibility with your equipment, or warranty items that have been modified or altered. RETURNS: NOTE: Original shipping charges are Non-Refundable. Customer is responsible for all return shipping charges. Defective/DOA: We accept returns for Defective/DOA items within 14 days of receipt by the customer. If you receive an item that is damaged or defective, please contact us as soon as possible, and we will, at our discretion, refund or replace the item. The customer is responsible for all return shipping charges. Right-of-Return: If you purchase an item, and decide within 14 days, that you no longer wish to keep it, we will accept it back for a refund, less a 15% restocking fee. This includes items that end up not being compatible or are simply the wrong part. You are responsible to determine compatibility before you purchase. For Right-of-Returns, items are expected to be in the same condition they were in when they left our warehouse. The customer is responsible for all return shipping charges. Free Shipping Returns: If you purchase an item with free shipping, and it is returned for a refund, the original shipping cost that we incurred will be deducted from the total refund. Return Shipping: The customer is responsible for all return shipping charges. SHIPPING: PLEASE NOTE: All shipping rates are calculated based on an estimation of the items packed weight. We will always make our best effort to adjust this rate once we know where the item is being shipped, and your invoice will reflect this. If for any reason you feel that the rates are higher than they should be, please feel free to contact us, and we would be more than happy to re-assess the charges. Additionally, if you purchase several items, eBay's combined shipping calculator rarely produces an accurate estimation of combined shipping weight, so please contact us and we will make any necessary corrections. SHIPPING DETAILS: All items will be securely packaged or palletized. Most items will be shipped within 1 business day. For items that require freight shipping, please allow up to two days for an invoice. All tracking information will be forwarded to the email address associated with your PayPal or eBay account. DOMESTIC SHIPPING: A contact name, phone number and company name are required for shipping purposes; items may not ship unless this is provided. In the event that the bidder/buyer would like to handle the shipping arrangements, please provide us with your FEDEX or UPS account number. Please Note: There will be a $4 pick-up fee charged for FedEx shipping. INTERNATIONAL SHIPPING: Please allow a 24 hour response time due to time difference. A contact name, phone number and company name are required for shipping purposes; items may not ship unless this is provided. In the event that you have questions about shipping logistics please contact us at (408)743-5609 before purchasing. International orders may be subject to Duties, Taxes or other Import Fees. The bidder/buyer is solely responsible for these fees, documents and transportation if held at a customs office in the destination country. FREIGHT: We will handle all of the preparations for freight shipments, ie: palletizing, shrink wrapping, etc. If you purchase an item that requires freight shipping, please allow two days to receive an updated invoice. Please let us know if there will be a loading dock or forklift at the delivery address. If you have any questions, please feel free to message or call us directly at (408)743-5609. FEEDBACK: It is our Mission to assure that all of our customers are 100% satisfied with their purchases. Should there ever be a problem, we ask that you contact us immediately, so that we can correct the problem as soon as possible. THANK YOU! Copyright © 2013 WeirdStuff.com Powered by SixBit's eCommerce Solution

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	Knight Electronics
Model	ML-2010
