Up for your consideration / auction is an Vintage used Nemic-Lambda Power supply SR660-5 AC-DC. Please read this description and review and examine all the pictures before placing any bids on this item. I have had this power supply in my possession since 12-31-2000. I bought this for a project that I never did get around to doing. It has been inside of dry storage of an warehouse for the past 11 years, I have not used it. It is made in Japan from the front lettering of silk screen printing that was done at the factory. This power supply is in very nice condition. It has been very lightly used, with only some scratch marks on the bottom from being moved around in it's storage days. There are a few scratches on the top left edge of the case from being handled and that is all of the marks on the other sides of this case that I could find. There is also some glue residue that is embedded into the paint on the middle left side of this top cover. The front panel is in magnificent shape with all the screw on terminals present and the Phillip-head screws are all in great shape with no rounding out of the heads of the screws. The two connection terminals are also in good shape and the tightening down nuts and washer are present and not rounded off. The flat surfaces of the nuts do show some ware but can easily be used or replaced as you desire. The power on indicator is present and looks to be in good shape. The V.ADJ adjustment screw is present and is not rounded out. The PJ1 connector numbered from 1 to 11 is present and looks to be in great shape with no marks on it, all the pin connections are present and straight and seem to be in great shape. The only thing I could find wrong is that a tab around the Left Connection block labeled AGC has a small corner of it missing. All the sides of the casing seems to be in great shape with no marks, except as noted above. The rear of the case has a fan installed in it and it looks to have been used lightly as there there is only a slight amount of dust deposited on the fins of the fan and inside of the intake cone of it. The connector going to the backside of the fan is in good shape showing no exposed wires and the connector is present and is properly plugged into it's connector. All the ventilation holes on the front side and top are all clear and clean and are not damaged in any way. There are no burn marks or peeling paint anywhere on this power supply. There are several sets of tapped screw in mounting holes on the side and bottom of this power supply, made of course to mount it inside of a rack or other mounting device. I tested the voltage out of this power supply and it seems to be working. I am unable to fully test the current output of this power supply, as I do not have a correct way to load test it. Since I can not fully test this power supply I will be listing this as partially working, or for parts only. Specifications of this Power supply SR660-5: 1 Nominal output Voltage V 5 2 Maximum Output Current (*9) 132 3 Maximum Output Power W 660 4 Efficiency (Typ) % (*1) 76 5 Input Voltage Range (*2) 85 ~132VAC / 170 ~ 265VAC(47~440Hz) selectable or 230 ~ 330VDC Input Voltage Range shown on Front Panel : 100 - 120~ 20A / 200 -240V~10A (50-60Hz) 6 Input Current (Typ) A (*1) 100V:8.0A 100VAC : 16.0A 200V:4.0A 200VAC : 8.0A 7 Inrush Current(Typ) (*3) 30A @ 100Vac, 60A @ 200VAC (260VDC) 8 Output Voltage Range (Typ) % -20~+10 9 Maximum Ripple & Noise mV 100 10 Maximum Line Regulation (*4) mV 20 11 Maximum Load Regulation (*5) mV 20 12 Over Current Protection (*6) A 145.0 ~ 171.0 13 Over Voltage Protection (*7) V 6.0 ~ 7.0 14 Hold-Up Time (Typ) (*8) ms 20ms 15 Remote Sensing Possible 16 Remote ON/OFF Control Possible 17 Parallel Operation Possible 18 Series Operation Possible 19 Operating Temperature (*9) -20 ~ +71 Degrees Centigrade 20 Operating Humidity 30-95%RH (No dewdrop) 21 Storage Temperature -40 ~ +85 Degrees Centigrade 22 Storage Humidity 10 ~ 95%RH (No dewdrop) 23 Cooling Forced air by blower fan (Blower fan is mounted within supply) 24 Temperature Coefficient Less than 0.03% / Degrees Centigrade 25 Withstand Voltage (*10) Input - Chassis : 2.5kVAC 1 min, Input - Output : 3.7kVAC 1 min. Output - Chassis : 500VAC 1 min. 26 Isolation Resistance More than 100Meg Ohm @ 25 degree C and 70%RH Output - Chassis : 500VDC 27 Vibration At no operating, 10 ~ 55Hz Amplitude (sweep for 1min) 0.824mm constant (Maximum 5G) X,Y,Z 1hour each 28 Shock Less than 20G 29 Safety Standard UL 1950 Approved by UL CSA950 Approved by C-UL EN60950 Approved by TUV (Approved model: sr660-5) 30 Conducted Emission Built to meet VCCI-Class A, FCC-Class A, VDE-Class A 31 Weight kg 4.0 32 Size (WxHxD) mm 189 x 96.5 x 215 33 Monitoring Signal FAN ALM, PF (Open Collector output) ==Notes== *1 At 100V/200VAC and maximum output power. *2 For cases where conformance to various safety specs (UL,CSA. etc) are required, input voltage range will be 100 - 120 / 200 - 240VAC (50 /60 Hz) *3 First in-rush current. *4 From 85 ~ 132VAC or 170 ~ 265VAC, constant load. *5 From No load ~ Full load, constant input voltage. *6 Constant current limiting with automatic recovery. (The unit automatically shuts down the output when it is left for 30 seconds under the state that OCP is operating and the output voltage is less then PF detected level. The output recovers when the input voltage is turned on after being turned off. ) *7 Inverter shut-down method, manual reset. (OVP circuit will shut-down output). *8 At 100V/200VAC, nominal output voltage & maximum output current. *9 Ratings - For 5V model -Load(%) is percent of maximum output power or maximum output current, whichever is greater. *10 Leakage current range used : Input-Chassis greater than 20mA Input-Output greater than 20mA (AGC -FG open) Output-Chassis greater than 100mA I am available to answer questions in the early morning AMs from Monday through Friday. I do ship items, once they have been fully paid for, in the the very early afternoons on Mondays through Fridays. I do not ship items on weekends or holidays as the USPS is closed on those days. The power supply will be double boxed and shipped as if I was receiving it, an will be very well packaged. Insurance and Signature Confirmation is included in the shipping price of this power supply.
