Voltage To Pwm 0-5v 0-10v To Pwm 0-100% Linear Conversion Transmitter Module

US $5100

Guangzhou , China
Jan 29th

Open on mobile:
QR code

Voltage to PWM 0-5v 0-10v to PWM 0-100% Linear Conversion Transmitter Module Voltage to PWM 0-5v 0-10v to PWM 0-100% Linear Conversion Transmitter Module Description: This is a linear transformation module, processing by the internal chip, the input voltage signal is converted to 0~100%PWM output signal. There are two output voltage and two frequency ranges to choose. Module parameters 1, the working voltage : 9V ~ 17V 2, the input voltage range : 0.00V ~ 5.00V / 0.00V ~ 10.00V 3, the output frequency range: 1KHz / 8KHz 4, the output duty cycle range: 0 to 100% 5, the input mode: J1 pads on the circuit board: Open (0 ~ 5V); shorted (0 ~ 10V) default is open. 6, output: J2 pads on the circuit board: open (1KHz); short (10KHz), the default is open. 7, drive mode: open-collector NPN drive, the maximum current 200MA, external voltage range of 1 ~ 30V. 8, Applications: Remote data acquisition and control equipment; 9, Size: (L) 26mm * (W) 23mm * (height) 10mm 10, the module interfaces: 12V: positive power supply interfaces (9V ~ 17V). G: Power to the ground interface. IN: positive signal input interface. G: negative signal input interface. OUT: Signal output interfaces (1KHz/8KHz). G: Power to the ground interface. Input voltage selection: J1 pad Open: Input (0.00V ~ 5.00V) output corresponding to 0 to 100% duty cycle pulse signal. Short: Input (0.00V ~ 10.00V) output corresponding to 0 to 100% duty cycle pulse signal. Output frequency selection: J2 pad Open: 1KHz pulse output signal. Short: 8KHz pulse signal output Package list: 1 X RF power meter 0-500Mhz -80 ~10 dBm We only accept Paypal in Ebay. If you want to pay via other method please contact us. Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility. Please check with your country's customs office to determine what these additional costs will be prior to biding. Item will be shipped within 24 hours on payment received from Hong Kong using Airmail. Delivery time depends on destination and other factors, it may takes up to 30 business days. Optionally, Express Shipments with tracking service via EMS/DHL/UPS with a quoted delivery time of 5 to 7 business days is also available Here is the estimated time for your reference only: The delivery time may vary due to public holidays, countries, and customs etc. Thanks for your understanding! If the item is defective, please let me know as soon as possible after receive the items. The item will be returned its original condition, in order to get it refunded and replaced (please inquire us the returning address before you ship it back.) . Buyer is responsible for shipping costs when shipping products. You feedback is very important to us, please let us know before leaving any negative feedback or open any disputes on Paypal, please give me an opportunity to resolve any problems and we will try our best to satisfy your requirement. On Sep-21-14 at 09:26:48 PDT, seller added the following information:
