Wavetek 716-11 16 Channel Brickwall Filter Wavetek 716

US $1,999.99

DALLAS, TX, United States
Jan 29th

Open on mobile:
QR code

You are bidding on a used Wavetek 716-11 Multi-Channel Brickwall Filter with 16 Channel Input Output Ports, 1Hz to 100Khz, 115 dB Octave Rolloff. The unit does not come with any cables or power sensors. The unit is working and in good cosmetic condition. It is guaranteed against DOA. Unit has these filter cards ion iy total of 8 cards 7 each P/N 004-0730 1 each P/N 004-0710 Features****** Multi-Channel Brickwall® Filter 1 Hz to 100 kHz Frequency Range 115 dB/Octave Rolloff Pre- and Post-Filter Gain 716 System consists of mainframe and up to 16 independent-channel filter cards. Filter Card Options 001 and 002 Functions - Low pass (001) or high pass (002); rolloffs of 115 dB/octave. Cutoff Frequency - Local Control Range: 1 Hz to 99 kHz Remote Control Range: 1 Hz to 100 kHz Programming and Resolution - Multiplier Frequency Resolution x 1 1 to 99 Hz 1 Hz x 10 100 to 990 Hz 10 Hz x 100 1 k to 9.9 kHz 100 Hz x 1 k 10 k to 99 kHz 1 kHz Gain - Pre-Filter Gain: 0, + 10, + 20, + 30, + 40 dB. One 5-position switch. Post-Filter Gain: 0, + 10, + 20 dB. One 3-position switch. Input Characteristics - Impedance: 1 M ohm, 50 pF, nominal Full-Scale Signal: 10 V at 0 dB gain Absolute Maximum Input: 100 V Filter Characteristics - Passband Ripple: 0.8 dB, p-p max (low pass and high pass), 1.4 dB, p-p max for high pass with f > 40 kHz Stopband Attenuation: 80 dB min for f > 2 fc (low pass), f < 0.5 fc (high pass). Amplifier Rolloff: -3 dB at approx. 400 kHz Output Characteristics - Impedance: 50 ohm, nominal Full-Scale Signal: ± 10 V into 5 k ohms DC Offset: Adjustable to 0 V ± 50 mV Phase Match Between Channels - Low Pass: ± 3° max DC to 0.8 fc, ± 4° max 0.8 fc to fc. High Pass: ± 3° max 1.3 fc, to 130 kHz, ± 4° max fc to 1.3 fc. Amplitude Match Between Channels - Low Pass: ± 0.3 dB max DC to 0.8 fc, ± 0.5 dB max 0.8 fc to fc. High Pass: ±0.3 dB max to 1.3 fc to 130 kHz, ± 0.5 dB max fc to 1.3 fc Model 716-11 Mainframe Memory - 16 selectable groups; each group has storage for 16 channel settings. Display - 7-segment displays for Group Number, Channel Number, pre-Filter Gain, Post-Filter Gain, Cutoff Frequency. Remote Programming/Sensing - IEEE 488-1978 (GPIB) digital interface Input/Output Connectors - Rear BNC's All Products are guaranteed not DOA, otherwise unless stated in auction. There is a 8.25% sales tax for Texas purchasers. There is a $10.00 will call charge for local pickup. Shipping is to lower 48 states only. For all other shipping locations please email me to get shipping and handling fees first, prior to bidding. All International bidders must have confirmed shipping addresses and all items shipped must be insured. All items are sold according to their auction listing. We provide no returns on "as is" auctions unless item not received as described. All returns must be authorized by an Universal Technology Co. authorized agent. All valid returns will be be given a unique RMA number and sender must provide the following: name, contact number, and item number of unit returning. Please email me for any other inquiries. BEST OFFER: Universal Technology is committed to provide excellent customer service and offer products at an affordable price. Please submit your best offer if your not satisfied with our price and if it is reasonable we will work with you. We strive to sell our merchandise and not store it on our shelves in our warehouse. All reasonable offers will be considered.
