Welch Allyn 97810-mc 3.5v Panoptic Ophthalmoscope Macroview Otoscope Diagnostic

US $954.05

Norwalk, California, United States
Jan 30th

Open on mobile:
QR code

Welch Allyn 3.5V Diagnostic Set 97810-MC Includes PanOptic Ophthalmoscope 11820 MacroView Otoscope/Throat Illuminator 23820 Convertible NiCad Handle 71000-A Nasal Illuminator 26535 Hard Case he PanOptic Ophthalmoscope With Blue Filter And Lens Direct observation of the structures of the fundus through a PanOptic Ophthalmoscope may show disease of the eye itself or may reveal abnormalities indicative of disease elsewhere in the body.Transparency of the cornea, lens and vitreous In this sense, the eye serves as a window through which many valuable clinical evaluations may be made. Among the most important of these are vascular changes due to diabetes or hypertension and swelling of the optic nerve head due to papilledema or optic neuritis. When a preliminary diagnosis of an imminently dangerous eye condition, such as acute (angle-closure) glaucoma or retinal detachment, is made by the examiner, prompt referral to an eye specialist may prevent irreversible damage.humor permits the practitioner to directly view arteries, veins, and the optic nerve of the retina.Or when distressing but less urgent conditions, such as visual impairment due to cataract or vitreous floaters, are recognized, the patient can be reassured and referred PanOptic Ophthalmoscope Advantages Makes it easy to enter small, undilated pupils Provides a 5X larger view of the fundus than ever before achieved with a standard ophthalmoscope in an undilated eye Enables a 25A° field-of-view vs. the standard 5A° field-of-view Increases magnification by 26% over a standard scope Greater working distance between practitioner and patient improves comfort for all Affordable new head is compatible with all existing Welch Allyn 3.5V battery handles and wall transformers The revolutionary PanOptic provides easy entry into the eye, together with a wider field of view to more easily observe conditions such as hypertension, diabetic retinopathy, and papilledema. PanOptic Field of View vs. Standard Ophthalmoscopes PanOptic Ophthalmoscope Features Patented New Axial PointSource Optics: Make it easy to enter small undilated pupils Provides a dramatically wider, more panoramic view of the funds Enables a 25 Field-of-view vs. the standard 5 fieid-of-view increases magnification by 26% over a standard scope Patient Eyecup Functions Establishes and maintains proper viewing distance Provides stabilizations for the view Pivoting point for leverage in panning around the retina Occludes ambient light Helps with orientation Dynamic Focusing Wheel (faces practicioner) Adjusts the focus in a continuous, smooth action for more precise control and optimum view focusing range of -20 to +20 diopters Aperture Dial 3 Spot sizes: Micro, small and large Slit aperture Red free filter Cobalt blue filter w/add-on magnifying lense for comeal examinations (surrogate for woods light/black light) Built-In Soft Grip Handle Ergonomic Design Maximum Comfort, balance and access to controls Product Specifications The Panoptic Scope will operate with any Welch Allyn 3.5v power source. The scope is also available as part of our 767 series Integrated Diagnostic System. Dimensions and Weight (head only) 5.12"L x 1.40"W x 3.75"H 0.5 lbs with eyecup 13.0 cm L x 3.6 cm W x 9.5 cm H 230g with eyecup MacroView Otoscope with Throat Illuminator The Welch Allyn MacroView otoscope features a patented optical system that provides the practitioner with an increased field of view and magnification to get a large, clear image of the tympanic membrane. Welch AllynaЂ™s traditional diagnostic otoscopes feature a wide-angle magnified viewing lens. Fiber optics and halogen light produce optimum illumination The Welch Allyn otoscope uses both fiber optic technology and Halogen HPX illumination. Fiberoptic light transmission provides a 360A? ring of light without visual obstruction or specular reflection. This distal light results in glare-free viewing and an easier examination. Focusing capability The Welch Allyn MacroView otoscope has the capability to zoom in or out on the area in view, resulting in a clearer image to aid in diagnosis. A focusing wheel, conveniently located on each side of the otoscope and the back eyepiece, is available to the practitioner for adjusting the focal length. The adjustable focal length can compensate for both the practitioneraЂ™s vision and the length of the patientaЂ™s ear canal, thus creating the clearest view of the tympanic membrane possible. Pneumatic otoscopy capability When examining tympanic membrane mobility, the ability to perform pneumatic otoscopy is extremely valuable. The Welch Allyn otoscope incorporates a closed system and an airtight seal. Specula attachment and removal The Welch Allyn MacroView otoscope features a unique specula attachment and removal design, the TipGrip, which provides the practitioner with a secure attachment between the specula and the otoscope during the exam. After the examination is complete, the tip can be released from the otoscope by turning the TipGrip counterclockwise or by simply twisting off the tip with one hand, as is the technique with traditional otoscope models. SPECULUM OPTIONS In order to obtain the maximum field of view, the examiner should always select the largest size speculum which fits comfortably into the patientaЂ™s ear canal. The following guidelines may be helpful: Patient Size Adults 4 mm or 5 mm Children 3 mm or 4 mm Infants 2.5 mm or 3 mm The examiner can choose from several types of specula and specula accessories: The first type of speculum is reusable and made of lightweight, durable polypropylene. Reusable specula are available in four sizes: 2.5 mm, 3 mm, 4 mm and 5 mm. The second type of speculum is the Universal KleenSpec, a disposable, economical and convenient tip. KleenSpec tips are made of nontoxic plastic and are available in two sizes: 2.75 mm (pediatric) and 4.25 mm (adult). The third type of speculum, available for traditional Welch Allyn otoscopes, is SofSpec.,A® a reusable specula with a rigid plastic base and a special soft material at the distal end. SofSpec fits snugly into the external ear canal. These specula are available in three sizes: 3 mm, 5 mm, and 7 mm and may be cleaned or sterilized by conventional methods. For improved seal and comfort during pneumatic otoscopy, the SofSeal can be placed on the end of either a disposable or reusable ear speculum. Available in two sizes, the various combinations of the SofSeal and ear specula allow you to optimize the fit for each individual patientaЂ™s ear canal. To perform instrumentation under visualization, the slotted instrumentation tip (compatible with 23810 and 23820 MacroView) is recommended. Nasal Illuminator Halogen HPX illumination and reusable tip for easy nasal examinations. Halogen HPX lamp provides light output for true tissue color and consistent, long-lasting illumination Fiber optics project cool distal light Simply detach the head to use as a throat illuminator/penlight Nickel-Cadmium Rechargeable Handles A choice of convenient rechargeable power sources that fit all our 3.5 V instrument heads. Rechargeable nickel-cadmium battery included Smooth, nonabrasive knurled finish ensures a no-slip grip Chrome-plated brass construction for durability and reliable long life Rechargeable and can also be converted for use with standard C-cell batteries (model 71000-C only) Recharges in the Welch Allyn desk charger and numerous stand consoles and well chargers (model 71670) Guarantee Welch Allyn nickel-cadmium batteries are guaranteed by Welch Allyn for two years from date of manufacture (when used in Welch Allyn instruments only). Defective batteries are replaced on a pro rata basis should failure occur prior to expiration date on battery. The Welch Allyn products listed on this document are guaranteed by Welch Allyn against all manufacturing defects. Welch Allyn will repair or replace, free of charge, any parts of its own manufacture proven to be defective through cause other than misuse, neglect, damage in shipment, or normal wear. Welch Allyn warrants that the products will perform to original specifications during the two years from the date of manufacture. This warranty does not apply to the use of the 72200 or 72300 battery in other products. Before using this product, please read the warnings and instructions. Maintenance Like any other piece of electro-medical equipment, perform periodic electrical inspections by qualified personnel. Welch Allyn recommends that this equipment is inspected at least every six months, more often if used under adverse conditions. Instructions for Recycling Nickel-Cadmium Batteries Welch Allyn now employs the services of an agency which can disassemble and recycle all components of nickel-cadmium batteries so that nothing gets landfilled or incinerated. Should you wish to dispose of your expended Welch Allyn rechargeable battery via recycling (in the U.S. and Canada only), please send to: Welch Allyn Welch Allyn Canada RECYCLE BATTERY RECYCLE BATTERY 4341 State Street Road 160 Matheson Blvd. East Skaneateles Falls, NY Mississauga, Ontario 13153-0220 CANADA L4Z 1V4 For locations outside the U.S. and Canada, consult your local recycling authority for correct disposal of batteries. Service: For customers in North America, please return instruments requiring service to a Welch Allyn Technical Service Department listed below or to an authorized Welch Allyn Technical Service Department. Technical Service Department Welch Allyn, Inc. 4341 State Street Road Skaneateles Falls, NY 13153-0220 Telephone: 1-800-535-6663 Fax: 315-685-4653 (Technical Services) In Canada: Telephone: 1-800-561-8797 Fax: 1-905-890-0008 Handles POSSIBLE EXPLOSION HAZARD. Equipment not suitable for use in the presence of a flammable anesthetic. Do not disassemble or modify the battery pack. There are no serviceable parts inside. Do not charge battery pack in any environment where the temperature may exceed 40A°C (104A°F) or fall below 0A°C (32A°F). For longest service, remove the handle and AC Charging Module from outlet when charging is complete. Do not leave AC Charging Module connected to power outlet without a handle attached. Do not sterilize the 710 Series Power Handle FOR BEST PERFORMANCE: Do not expose battery pack to storage temperatures above 50A°C (122A°F) or below -20A°C (-4A°F). Do not discharge battery pack if the ambient temperature is above 60A°C (140A°F) or below -20A°C (-4A°F). Nickel Cadmium Handle The 710 is a universal handle which accepts all Welch Allyn 3.5v instrument heads. Its adjustable rheostat control allows optimal intensity and battery life. The chrome-plated brass handles and metal head connection provide durable, long life construction and the smooth, non-abrasive knurled finish insures a no-slip grip. The 710 series also have a built in charger for easy, overnight charging of the long-lasting rechargeable nickel Cadmium batteries. As an accessory, the converter ring is available in the 71000-C handle, which enables insertion of off-the-shelf C-cell batteries in place of the rechargeable batteries for continued operation without the need to wait for recharging. Specifications: Dimensions: 5.5aЂ? Long x 1.50aЂ? Diameter (max) Weight: 10 oz. (including battery) Input Voltage: 120V 60Hz 0.17A Before using, follow these instructions: 1. fully charge battery (16 hours) 2. run battery completely down 3. fully recharge (16 hours) 4. run battery completely down 5. fully recharge (16 hours) 6. ready for use Special Notes aЂ? Slight heating of handles is normal during recharge cycle. aЂ? Batteries cannot overheat or overcharge. aЂ? Batteries will not leak. aЂ? Batteries will discharge gradually over a period of about 60 days when stored at room temperature (70A°F). Storage at higher temperatures accelerates the discharge rate. aЂ? For rechargeable handles that accommodate "CaЂ? or "AAaЂ? size batteries aЂ” remove batteries from handle if instrument is not in use for an extended period of time. Cleaning Procedure for Handle The cleaning of all Welch Allyn power handles is easily accomplished by wiping the external surface with a damp cloth soaked with a mild detergent and water solution, or solution of 70% isopropyl alcohol and water, or a solution of 10% clorox and water. Do not immerse. Soak the cloth in the solution and wrung out to prevent excess water from entering the assembly. Battery Charger Instructions 1. Plug into a 110-130 V, 50-60 Hz A.C. receptacle for No. 71040. (90-110 V for 71030, 220-250 V for 71032, 71034, and 71036). 2. Connect the charging plug to charger socket on instrument or charging stand. 3. Support the instrument during charging. Do not suspend the instrument by its charging cord. 4. Batteries do not overcharge. A completely discharged battery is fully charged overnight. 5. Use the charger with either 2.5 V or 3.5 V rechargeable instruments. 6. Do not use diagnostic instruments while charging. Hard Case Brand: Welch Allyn MPN: WA-97810-MC

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Welch Allyn
MPN	WA-97810-MC
