Western Multiplex Lynx / Sc2 Spread Spectrum 2.4ghz Digitial Radio T1

US $820

Boise, Idaho, United States
May 11th

Open on mobile:
QR code

This is a pair of Lynx /SC2 2.4 ghz spread spectrum radios. Could be used as one end of a link with redundancy of two radios. Or split them and have a full link. These are untested and sold as is. They came from a local utility when they upgraded to new equipment. Frequency 2410/2453 both units are the same. pread Spectrum T1 Digital Microwave Radios No operating license required (in most countries) One to eight independent DS-1 (1.544 Mbps) channels Point-to-point communications from less than 1 mile to more than 50 miles Wide operational temperature Built-in loopback, far-end monitoring and orderwire Open network management One to Eight Channels Up to eight independent, non-compressed, full-duplex T1 channels are provided (depending on model). This capability provides an alternative to leased lines or traditional licensed radio for fast and easy connection of T1 capacity requirements. Spread spectrum technology allows a license-free approach to accomplish medium-capacity spur connections quickly, without FCC licensing or coordination. Full-Featured Built-in orderwire provides an easy means for private telephone connections between radio sites. Open network management yields flexibility for operators with central equipment monitoring facilities. The one-piece indoor design, loopback functions, flexible power connections and external adjustments result in a system that is easy to install and maintain. Also, wide temperature operation allows users to install LYNX.sc in outdoor cabinets or shelters without additional air conditioning or heating. Applications LYNX.sc digital microwave radios are easily connected to voice, data or video sources. Outstanding system gain provides wireless point-to-point link distances greater than 50 miles, line-of-sight. Hub and repeater configurations are also easily implemented. Typical applications include cellular/PCS base station interconnect, rural telephone and remote data connections. - See more at: http://www.airlinx.com/products.cfm/product/1-162-60.htm#sthash.qMQDfoqJ.dpuf System (All Models) Antenna Connector N-type female Full Output Power (2.4 GHz) >\= +27 dBm, +30 dBm, maximum RF Attenuation Range (2.4 GHz) 16 dB, minimum Full Output Power (5.8 GHz) >/= +20 dBm, +23 dBm typical RF Attenuation Range (5.8 GHz) 20 dB, minimum Max. Receive Level 0 dBm, error free; +10 dBm, no damage Coding Direct sequence Number of Codes 4 (selectable) Processing Gain 10 dB, minimum Transmission Delay (radio only) 250 us, maximum (10-mile path) 300 us, maximum (30-mile path) 400 us, maximum Regulatory Compliance FCC Part 15.247 (Class B) IC RSS210/139 Digital Line Interface (All Models) Digital Interface DSX-1* to 4 x DSX-1* Connectors DB9, RJ-45 (RJ-48c) Bantam Jacks** Tx & Rx monitor Line Code B8ZS or AMI, selectable Line Build Out 0 to 660 feet, selectable Blue Code AIS (Alarm Indication Signal) Far-end Loopback Local or remote control (internal/external signal source) Specifications All Models System Antenna Connector N-type female Full Output Power, 2.4 GHz _+27 dBm, +30 dBm maximum RF Attenuation Range, 2.4 GHz 16 dB, minimum Full Output Power, 5.8 GHz _+20 dBm, +23 dBm typical RF Attenuation Range, 5.8 GHz 20 dB, minimum Maximum Receive Level 0 dBm, error free; +10 dBm, no damage Coding Direct sequence Number of Codes 4 (selectable) Processing Gain 10 dB, minimum Transmission Delay (radio only) 250 µs, maximum (10 mile path) 300 µs, maximum (30 mile path) 400 µs, maximum Regulatory Compliance FCC Part 15.247, Class B & IC RSS210/139 Digital Line Interface Digital Interface DSX-1* Connectors DB9, RJ-45 (RJ-48c) Bantam Jacks** Tx & Rx monitor Line Code B8ZS or AMI, selectable Line Build Out 0 to 660 feet, selectable Blue Code AIS (Alarm Indication Signal) Far-end Loopback Local or remote control (internal/external signal source) Auxiliary Connections Orderwire Handset 2-wire, RJ-11 VF Orderwire Bridge 600 ohm balanced, 4-wire, 0 dBm, DB25 Diagnostics Port RS-232/RS-422 (craft/TBOS), DB9 Aux Data Port RS-232/RS-422, (Clear Service Channel) Alarm Port 2 Form C, 6 TTL, DB25 Protect Port RS-232, RJ-45 Test Points output power, near & far-end RSL Power/Environment DC Power ±20 to ±63 Volts, <45 Watts Optional AC Adapter 100 - 250 Volts, 50 - 60 Hz Power Connector 6-pin barrier strip, plug-in Operational Temperature -30 to +65°C Humidity 0 to 95% non-condensing Altitude 15,000 feet, maximum Physical Size (WxHxD)*** 17.2 x 3.5 x 14.5 inches (2RU) Weight 11 pounds *Meets CCITT G.823, AT&T Pub 62411, Bellcore TR-TSY-000499. ** Not provided on Model 31800 & 31145. ***19-inch EIA rack mount, 2-unit height (mounting brackets supplied). Ordering Information System 31250-xxx 2.4 GHz T1 31650-xxx 2.4 GHz 2 x T1 31000-xxx 5.8 GHz T1 31600-xxx 5.8 GHz 2 x T1 31800-xxx 5.8 GHz 4 x T1 31145-10xxx 5.8 GHz 8 x T1 201-9350 OpenLYNX™ GUI Channel xxxxx-A1x A1 channel xxxxx-A2x A2 channel xxxxx-B1x B1 channel † xxxxx-B2x B2 channel † xxxxx-C1x C1 channel †† xxxxx-C2x C2 channel †† AC adapter xxxxx-xx0 without AC Adapter xxxxx-xx1 with AC Adapter †Models 31250, 31000, 31600 and 31145 only. ††Model 31000 only. Specifications subject to change without notice. - See more at: http://www.airlinx.com/products.cfm/product/1-162-60.htm#sthash.qMQDfoqJ.dpuf pread Spectrum T1 Digital Microwave Radios No operating license required (in most countries) One to eight independent DS-1 (1.544 Mbps) channels Point-to-point communications from less than 1 mile to more than 50 miles Wide operational temperature Built-in loopback, far-end monitoring and orderwire Open network management One to Eight Channels Up to eight independent, non-compressed, full-duplex T1 channels are provided (depending on model). This capability provides an alternative to leased lines or traditional licensed radio for fast and easy connection of T1 capacity requirements. Spread spectrum technology allows a license-free approach to accomplish medium-capacity spur connections quickly, without FCC licensing or coordination. Full-Featured Built-in orderwire provides an easy means for private telephone connections between radio sites. Open network management yields flexibility for operators with central equipment monitoring facilities. The one-piece indoor design, loopback functions, flexible power connections and external adjustments result in a system that is easy to install and maintain. Also, wide temperature operation allows users to install LYNX.sc in outdoor cabinets or shelters without additional air conditioning or heating. Applications LYNX.sc digital microwave radios are easily connected to voice, data or video sources. Outstanding system gain provides wireless point-to-point link distances greater than 50 miles, line-of-sight. Hub and repeater configurations are also easily implemented. Typical applications include cellular/PCS base station interconnect, rural telephone and remote data connections. - See more at: http://www.airlinx.com/products.cfm/product/1-162-60.htm#sthash.qMQDfoqJ.dpuf Auxiliary Connections (All Models) Orderwire Handset 2-wire, RJ-11 VF Orderwire Bridge 600 ohm balanced, 4-wire, 0 dBm, DB25 Diagnostics Port RS-232/RS-422 (craft/TBOS), DB9 Aux Data Port (Clear Service Channel) RS-232/RS-422, </= 9600 baud, DB9 Alarm Port 2 Form C, 6 TTL, DB25 Protect Port RS-232, RJ-45 Test Points Output power, Near & far-end RSL Power/Environment (All Models) DC Power +/-20 to +/-63 Volts, <45 Watts Optional AC Adapter 100 - 250 Volts, 50 - 60 Hz Power Connector 6-pin barrier strip, plug in Operational Temp -30 to +65oC Humidity 0 to 95% non-condensing Altitude 15,000 feet, maximum Physical (All Models) Size (WxHxD)*** 17.2 x 3.5 x 14.5 inches (2RU) Weight 11 pounds

“This is a pair of radios and the protection switch. It is as removed from service. SOLD AS IS.”

Brand	Western Multiplex
Band	2.4 GHZ
Model	Lynx / SC2
Country/Region of Manufacture	Unknown
MPN	31250-A2
