Whipmix Combination Unit / Vacuum Mixing

US $660.00

Scottsdale, Arizona, United States
May 9th

Open on mobile:
QR code

Drive Chucks The Vacuum Power Mixer Plus is equipped with a low-speed (430 RPM) Drive Chuck for vacuum-mixing of plasters, stones, die materials, investments and alginates, with the Vac-U-Mixer (200 mL, 300 mL, 500 mL, 875 mL or 1200 mL size) and Flexible Vac-U-Mixer (350 g or 650 g). The Combination Unit is equipped with two separate Drive Chucks. (a) TheRearChuckturnsathighspeed(1,725RPM)for vacuum-mixing with the Vac-U-Mixer and investing with the Vac-U-Spat (200 mL or 300 mL sizes). (b) TheFrontChuckturnsatlowspeed(430RPM)forvacuum- mixing plasters, stones, die materials, investments in larger quantities, and alginates with the Vac-U-Mixer (200 mL, 300 mL, 500 mL, 875 mL or 1,200 mL sizes). Vacuum Pump The 1/4 HP motor drives the Vacuum Pump, located on the top of the unit, and the low-speed Drive Chuck through the gear housing on the lower end. The Vacuum Pump will produce a vacuum of 26" to 28" Hg (66 to 71 cm Hg) at sea level (deduct 1" for each 1,000 feet elevation above sea level) and therefore can be used as a high vacuum source for other equipment. Switching—Manual and Automatic The units are equipped with a Manual Switch on the front of the gear housing. There is an automatic switch built into the low-speed Drive Chuck. The mixing bowl with a slotted Drive Nut is inserted into the low-speed Drive Chuck by aligning the slotted Drive Nut with the cross pin inside the Drive Chuck. The motor will start automatically when the slotted Drive nut on the mixing bowl assembly is pushed upward into the Drive Chuck. The motor will stop upon disengaging and the vacuum will drop. For high-speed mixing or to establish a vacuum, turn on the Manual Switch. Vibrator The built-in Vibrator is sturdy and dependable — use it in a regular manner. All wear takes place on the #6103 Vibrator Rod rather than on the cam from which it operates. Therefore, replacement of the rod is required when loss of vibration is noted. To replace vibrator rod, release Vibrator Retainer #6109 (see diagram page 2). Swing arm up and remove worn rod. In some instances it may be necessary to grasp rod with pliers and pull out with a twisting motion. Insert new rod in hole.

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	whipmix
Model	combination unit
