0.1hz-102.4hz Square Wave Signal Source Duty Cycle Oscillator Pulse Generator

US $2100

shenzhen, China
Nov 28th

Open on mobile:
QR code

New Arrivals Modules Home Gadgets Fishing Outdoor Product Picture Galler Power Modules Sensors Module Function Modules Development boards Wireless Modules DIY LED Boards LCD Modules Description 0.1Hz-1024Hz Square Wave Signal Source Frequency Duty Cycle 2.4V-24V Adjustable Product Introduction: 0.1Hz-102.4Hz 1.Frequency Range:0.1Hz-102.4Hz 2.Frequency Adjust Step Distance:0.1Hz 3.Duty Cycle Range:1%-99% 4.Duty Cycle Adjust Step Distance:1% 1Hz-1024Hz 1.Frequency Range:1Hz-1024Hz 2.Frequency Adjust Step Distance:1Hz 3.Duty Cycle Range:1%-99% 4.Duty Cycle Adjust Step Distance:1% 10Hz-10.24kHz 1.Frequency Range:10Hz-10.24kHz 2.Frequency Adjust Step Distance:10Hz 3.Duty Cycle Range:1%-99% (<7kHz);2%-98% (7kHz-10.24kHz) 4.Duty Cycle Adjust Step Distance:1% 0.2Hz-34kHz 1.Frequency Range:0.2Hz-34kHz 2.Frequency Adjust Step Distance:200Hz 3.Duty Cycle Range:2%-98% (<15kHz);3%-97% (15kHz-20kHz);4%-96% (20kHz-30kHz);5%-95% (>30kHz) 4.Duty Cycle Adjust Step Distance:1% 5.Power Voltage:2.4V-24V 6.No load Current:6mA 7.Output Port:2-channel complementary output(the same frequency,different phase position) 8.Each Channel Signal Max Output Current:20mA 9.Output Frequency Adjustment:to adjust output signal frequency Using Method: 1.Output 1:signal 1 output port,max current is 20mA 2.Output 2:signal 2 output port,max current is 20mA 3.Power Voltage Setting:when power voltage is 2.4V-5.5V, connects with 2 solder joint,output signal value is equals to power voltage;when power voltage is 7V-24V,two solder joints shouled be cut off(default off),output signal value is 5V Shipping Payment Return Gurantee About us 1. Items are only shipped after PAYMENT confirmed. 2. Please check out your Paypal ADDRESS carefully when processing order. 3. Please CONTACT us ASAP if you haven't received the package in 35 days. 4. If you don't receive the parcel in 45 days, please allow us 3-5 working days for checking undelivered parcels before we issue you refund. 1. We only accept Paypal payment if you buy on ebay. 2. Please make sure you notice the entire desciption and agree to the transaction before buying. 1. If for some reason you're not satisfied with our service or product quality, please contact us within 3 days after you get the package, you can return the products to us in 30 days and we will refund your money after we get the package!(Shipping cost is NOT refundable and you should responsible for the return shipping) 2. Although we test each item and they are packed professionally, few item(less than 0.1%) might be damaged during the shipping. You are welcome to contact us within 3 days after you receive your package about replacement. 3. Repair Some items might be broken caused by improper use, we are always happy to offer any helpful repair service. Of course, you can send the broken items back to us and we will help you resolve the situation and charge reasonable repair fees. 1.We Can promise to offer you the refund or replacement if you can not get packages on the normal delivery time. 2.If there is any problems with the item when you get it, please send us the ebay message for solution; Or you can return the item to us in 30 days. In our ebay shop, we mainly sell electronics, outdoor finishing accessoires, and all Funny Sorts. We can als offer wholesale service. inkfrog terapeak inkFrog Analytics On Nov-28-16 at 09:16:17 PST, seller added the following information:
