0-200khz Oscilloscope 1 Set 1024 Bytes 12 Bits 2.4in Tft Acrylic Case Diy

US $36.52

suzhou, China
Jul 4th

Open on mobile:
QR code

This is a DSO138 0-200KHz Oscilloscope 1 Set that comes with 1024 Bytes and 12 Bits. It also has a 2.4-inch TFT Acrylic Case that you can easily DIY. This product features the ARM Cortex-M3 processor (STM32F103C8). It has a color TFT display that you can use as an ARM test development board for secondary development as a millivoltmeter, data logger, and more. The vertical sensitivity is 10 mV/Div-5V/Div (1-2-5 progressive method), input impedance 1M, maximum input voltage 50Vpp (1:1 probe), 400Vpp (10:1 probe), and coupling mode DC/AC/GND. The horizontal time base range is 10mus/Div-50s/Div (1-2-5 progressive method). The power supply voltage is DC 9V. The PCB size is 117 * 76mm / 4.6 * 3in, and the screen size is 52 * 40mm / 2 * 1.57in. The package includes 1 DSO138 2.4" TFT Welded Fully Welded Pocket Digital Oscilloscope, 1 Acrylic DIY shell (needs to be assembled), 1 Probe, and 1 User Manual (English). Please note that It has short circuit and open circuit detection which can help users find welding errors. It also has a TFT controller identification function. The product parameters include Model DSO138 Type Welded, maximum real-time sampling rate 1Msps, precision 12 bits, and analog bandwidth 0-200KHz. It comes with a 1Hz/3.3V square wave test signal source. It also has a digital display of waveform parameters like frequency, period, pulse width, duty cycle, MAX./MIN./AVG./Peak-Peak/virtual value. The DSO138 0-200KHz Oscilloscope 1 Set also has waveform storage function, meaning the waveform will not be lost after power off. Adjustable vertical displacement is possible with instructions. It has automatic, regular, and one-off modes which make it easy to capture waveforms. The product can be triggered by rising or falling edge and also has observable previous trigger waveform (negative delay). Using the HOLD function, the waveform display can be frozen at any time.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	MPN	Does Not Apply
Type	Welded
Brand	Unbranded
Maximum Real-Time Sampling Rate	1Msps
Oscilloscope Type	Digital Oscilloscope
Precision	12 bits
Package Contents	Oscilloscopekit
Sampling buffer depth	1024 bytes
Model	DSO138
Coupling mode	DC/AC/GND
UPC	Does not apply
