0-200khz Oscilloscope Analog Set 94x65mm Standard Probe Replacement Electronic

US $48.91

suzhou, China
Jul 1st

Open on mobile:
QR code

Product Description 0-200khz Oscilloscope Analog Set 94x65mm Standard Probe Replacement Electronic Features: *DSO-Shell (DSO150) Oscilloscope Full Assembled With P6020 BNC Standard Probe *100% brand new and high quality *Made of high quality material, durable and practical to use *Using ARM Cortex-M3 processor (STM32F103C8), built-in 2.4-inch color TFT display *Based on secondary development, this tool kit, for example, can be changed to a millivolt table, data logger *With instructions, easy to install and operate *Auto/Normal/Single Trigger mode for easy capture of instantaneous waveforms *Available rising or falling edge triggers *Waveforms that can be observed before triggering (negative delay) *The waveform display can be frozen at any time (hold function) *Waveform parameter digital display, including frequency, period, pulse Width, duty cycle, maximum/minimum/average weight./maximum peak/virtual value *Waveform storage function: no loss of waveform after power off *Short circuit, open circuit detection: help users find welding errors *TFT controller identification function *SMD has been soldered, more suitable for electronic beginners Specifications: *Maximum real-time sampling rate: 1 MSa/s *Analog bandwidth: 0 - 200khz *Sensitivity range: 5 - 20mv / div *Maximum input voltage: 50 Vpk (1X probe) *Input impedance: 1M ohm / 20pF *Accuracy: 12 digits *Record length: 1024 points *Coupling mode: DC / AC / GND *Time base range: 500s/Div - 10us / Div *Trigger mode: automatic, normal, one shot *Trigger position: buffer center *Power supply voltage: DC 9v (8 - 10v) *Current consumption: ~ 120ma @ 9v *Motherboard size: 94 x 65 mm / 3.7 x 2.56 inches(Approx.) *Analog board size: 65 x 47 mm / 2.56 x 1.85 inches(Approx.) *Screen size: 52 x 40 mm / 2 x 1.57 inches(Approx.) Package Contents: 1*Oscilloscope 1*Probe Note: 1.The real color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness. 2.Please allow slight manual measurement deviation for the data. Payment We accept payment via Paypal only. Payment must be completed within 5 days. If you have any problems about payment, please contact us via ebay message. Delivery details We only ship to confirmed Paypal addresses. Please comfirm that your paypal address is in line with your shipping address. Please kindly note that the combined shipping is not provided because the shipping fee is calculated by weight. Also, the each additional item means exactly the the same color and size. It takes about 7-15 working days to US; about 10-30 working days to other countries. Transit time may be a little delayed because of the bad weather and customs inspection. If you do not receive your item within 30 working days since payment finished, please contact us immediately for further assistance. Contact us We strive for 100% customer satisfaction! Positive Feedback is very important to us. If you have any questions, please feel free to contact us via "Ask seller a question" . We will reply your email within 24 working hours.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Unbranded
Trigger mode	automatic, normal, one shot
MPN	Does Not Apply
Trigger position	buffer center
Package Contents	1x Oscilloscope 1x Probe
Power supply voltage	DC 9v
Coupling mode	DC / AC / GND
UPC	Does not apply
