0.3mp Usb Video Camera Module W/ 2.8mm Lens Ov7725 Free Driver Vga Webcam Board

US $42.71

Shen zhen, Guangdong, China
Jul 5th

Open on mobile:
QR code

Other USB Camera IP Camera Analog Cameras Connectors/Cables VR Camera & VR 3D glasses Cell Phones & Accessories Heated Products Car Mobile DVR Store category Other USB Camera IP Camera Analog Cameras Connectors/Cables VR Camera & VR 3D glasses Cell Phones & Accessories Heated Products Car Mobile DVR CCTV DVR Sign Up Now ! You may also like 0.3MP USB Video Camera Module w/ 2.8mm Lens OV7725 Free Driver VGA Webcam PCB Board Product Description VGA USB Camera module Support IR Cut IR LED and OTG Main Specifications: Model ELP-USB30W04T-L36 Sensor OV7725 Lens Size 1/4 inch Pixel Size 6.0um X 6.0um image area 3984 µm x 2952 µm Max. Resolution 640(H)X480(V) Compression format MJPEG / YUV2YUYV Resolution & frame 640X480 MJPEG@ 30fps YUY2@ 30fps/ / 352X288 MJPEG@ 30fps YUY2@ 30fps 320X240 MJPEG@30fps YUY2@ 30fps/ 160X120 MJPEG@ 30fps YUY2@ 30fps Adjustable frame 5 fps10 fps15 fps20 fps25 fps30 fps USB Protocol USB2.0 HS/FS USB1.1/USB1.0 S/N Ratio 50dB Dynamic Range 60dB Sensitivity 3.8V/lux-sec@550nm Mini illumination 0. 2lux Shutter Type Electronic rolling shutter / Frame exposure Connecting Port type USB2.0 High Speed Free Drive Protocol USB Video ClassUVC AEC Support AEB Support AGC Support Adjustable parameters Brightness, Contrast, Saturation, Hue, Sharpness, Gamma, White balance, Backlight Contrast, Exposure Lens Parameter Standard 3.6mm, optional 2.1/2.5/2.8/6mm IR CUT Connector Support 2P-1.25mm socket LED board test connector Support 2P-1.25mm socket LED board power connector Support 2P-2.0mm socket Power supply USB BUS POWER 4P-2.0mm socket Power supply DC5V Operating Voltage 110mA~130mA Working current -1070 Working temperature -2085 Board size /Weight 38X8mmCompatible 32X32mm/ about 30g Cable Standard 1M / optional 2M,3M,5M Operating system request WinXP/Vista/Win7/Win8 Linux with UVCabove linux-2.6.26 MAC-OS X 10.4.8 or later Wince with UVC Android 4.0 or above with UVC Application: Car and ship control, electronic equipment, oil field equipment, industrial equipment, remote site monitoring, environmental monitoring, etc. used for all kinds of machine as below: machinery equipment, all-in-one machine, POS equipment, STB, smart box TV BOX, advisement player, LED display, automatic vending machine, safety box, notebook, video door phone, MID, Tablet external, evaluator, Medical Equipment, on-the-spot law enforcement, door bell and button system, cat-eye system, simple security system, teaching system, Interactive system, automobile data recorder. Project video capture, credit card machine, attendance machine, Voting system, High speed video shooting Device, exam system, Driving learning system, Industrial camera, biological microscope, box inside surveillance, micro HD surveillance, endoscope, Medical auxiliary equipment, etc. Size: Effect show: Payment Delivery details Terms of sales About us Contact us Payment 1.We accept Paypal only. 2.Payment must be received within 7 working days. Or unpaid case will be opened automatically. Delivery details 1.We ship goods to customer's confirmed paypal address. Please be sure your paypal address is correct before bidding. 2.Items will be shipped out within 48 hours once payment cleared. By registered air mail with tracking number. Orders placed on weekends or holidays will be processed on Monday or next working day. 3.International buyers please note: Import duties,taxes and charges are not included in the item price or shipping charges. These fees are buyers responsibility. So, Please check with your country's customs office to determine what these additional costs will be prior to bidding. 4.Delivery time: For USA buyers we'll ship by e-packet takes arround 7-12 working days. Other countries we'll ship by Registered Air Mail. Arround delivery time as bellow for your referrence. Australia, Canada 10-18 working days UK, France, Austria, Germany, Spain and other Europe countries: 10-25 working days Greece, Malta 15-40 working days Russian Federation, Italy, Brazil, Africa countries: 20-40 days due to customs restriction The estimated arrival time above just for your refference, Not guaranteed. We don't responsible for any customs duties. Terms of sales 1.If the goods dead on arrival, Please take photoes for us confirmation and reach us first time for exchangeor refund. 2.Buyers have purchased a wrong item or don't like the item received, Please return within 7 days and reach us first before returning. 3.Ailipu Technology Co., Ltd warrants our product to be free from manufacturer’s maintenance for 2 years. The warranty will not be covered under the following conditions : a) Out-of-warranty products. b) The product is modified without Ailipu Technology Co.,Ltd approval. c) Obvious attack of appearance whatever it is. d) The product is subjected to unusual physical or electrical stress, including physical damage, burnt components and broken connectors. 4. The customer is responsible for returning the defective product at his own expense. About us Ailipu Technology Co.,Ltd have 10 years history, is a professional manufacturer of surveillance system. We produce traditional analog CCTV camera, standalone DVR recorder for cctv camera,but also produce popular megapixel network IP cameras, NVR recorder for IP cameras too.Besides, Ailipu Technology Co., Ltd already developing its own special USB Cameras for industrial vision. Recently, Ailipu company present new USB cameras module range from 30W Pixel, 1megapixel, 2megapixe, 3megapixel, 5 megapixel to 5megapixel autofocus, which already used in all kinds of industrial system. We can also OEM or customize products specially by customers' requirements. Contact us If you have any questions,Please contact with us via eBay message! Our Service Officer will reply in 24 hours!(Excluding Weekends and Public Holidays) Working time: Our Duty Time China Time USA (pacific time) Start End Start End Monday AM 9:00 PM 18:00 Sunday PM 17:00 AM 2:00 Tuesday AM 9:00 PM 18:00 Monday PM 17:00 AM 2:00 Wednesday AM 9:00 PM 18:00 Tuesday PM 17:00 AM 2:00 Thursday AM 9:00 PM 18:00 Wednesday PM 17:00 AM 2:00 Friday AM 9:00 PM 18:00 Thursday PM 17:00 AM 2:00 Saturday Out of Duty Friday Saturday Sunday Out of Duty Saturday Sunday During the duty time ,we can give you a quick respond. If we are out of work ,please kindly be patient and considerable to give us a little more time ,not just leave the neutral or negative feedback without communication ,thank you for your cooperation ! Payment Shipping Return policy About us

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Type	vga usb camera module
Compatible Product	digital camera
Brand	elp
Smart Home Protocol	usb2.0 camera
Sensor	OV7725
Connectivity	usb2.0
Lens Size	1/4 inch
Smart Home Compatibility	Webcam
Max. Resolution	640(H)X480(V)
Compatible Brand	Web Camera
Compression format	MJPEG / YUV2YUYV
Audio/Video Outputs	plug and play camera
MPN	Does Not Apply
Features	manual focus
Model	ELP-USB30W04MT-L28
Connection Split/Duplication	usb2.0 webcam module
UPC	Does not apply
