0.56” Red Led Digital Voltage Timing Delay Relay Control Panel Meter

US $15.99

  • KOWLOON, Hong Kong
  • Jan 29th
Open on mobile:
QR code
0.56” red LED digital voltage timing delay relay control panel meter This product is mainly composed of Intelligent DC voltmeter and DC relay control module, not only to achieve a precise measurement of the DC voltage, also according to the limits set voltage, various delays, timing and timing loop combine functions. This product use of three bright LED digital display, slot-type installation. Simple and flexible to control a variety of systems, It is widely used in the battery charge and discharge control (inverters, UPS, backup power and a variety of DC electric equipment). The car battery control, electric vehicles, power supply control, motor control, solar power systems and over-voltage protection. Products designed in strict accordance with the relevant national standards and electrical safety rules.   Performance parameters: 1. Display: 3 digits 0.56” red LED 2. Operating power: DC10-15V 3. Voltage measuring range: DC 0.0~99.9V 4. Measurement rate: >= 500mS / times 5. Measurement accuracy: ± 1 class 6. Timing range: 0~999 seconds or 0~999 minutes (optionally) 7. Standby current: 15mA, 10mA (relay disconnect), 45mA (relay pull) 8. Operating temperature: -10 ~ 65 °C 9. Power-off data save function 10. The upper and lower limit of voltage flashing alarm function 11. The relay default status: pull or disconnect (optionally) 12. Dimensions: 48 x 29 x 35 mm 13. Cutout: 46 x 27 mm 14. The relay parameters:  -Coil rated working voltage: 12V  -A set of conversion (normally open and normally closed) -Contact load: 10A/250VAC or 10A/30VDC -Contact resistance:
