0-5v/10v 4-20ma Load Cell Sensor Amplifier Transmitter Strain Gauge Transducer

US $27.99

??, ???, China
Jun 9th

Open on mobile:
QR code

rw-st01a 0-5V 0-10V 4-20mA Load Cell sensor Amplifier Transmitter strain gauge transducer 1.0~5V(10V)&4~20mA can output at the same time;0~5V&0~10V is adjustable by switch(view the pictures). 2. The built-in precision amplifier circuit, high precision, low temperature drift, long-term stability; 3. Current and voltage output offer at the same time, choose through the terminal blocks; 4. A wide range of power-supply modes 5. Input overvoltage and overcurrent protection, output short circuit protection; 6. Load capacity is strong, use with junction box, it can connect with more than one sensor; 7. Apply to weighing, pull pressure, torque, etc. Various kinds of strain bridge type sensor 8.The shell and cable connector waterproof design, tightness is good, applicable to various kinds of severe environment; 9.Load capacity:87?(can connect with 4pcs of 350? load cell sensor in parallel) parameter Input signal Full bridge strain gauge/Load cell Note Bridge resistor <2K? Sensitivity 1.5~2.1mV/V Excitation voltage 5V DC Excitation current <100mA#12V supply <50mA#24V supply Power supply 12~26V DC vs. 0~5V output & 4~20mA output 18~26V DC vs. 0~10V & 4~20mA output Linear 0.3% Temperature coefficient 50ppm#10~30 degree, 100ppm full work temperature range Operating temperature 0~50 degree Weight 90g Dimension 115mmx80mmx35mm(bolt center: 97mm) Wiring Terminal No. 1 2 3 4 5 6 7 8 9 10 Define ToLoad cell Power supply & Output EXC+ SIG+ SIG- EXC- Shield 12~26V DC Iout Vout Common. Shield Main application: use to change the output mV weak signal of strain pressure transducer(such as weighing, pull pressure, torque sensor and so on) into universal standard analog signals as 4~20mA or 0~5V(10V) Shipping Item will be shipped out within 2 business days after receipt of your payment, we ship the item through hongkong Air mail or China Post. We Ship to Worldwide, but Italy, Nigeria, Brazil will take long delivery time . Before buying, Please make sure your address is correct. Or not, please correct it before payment Ship to worldwide from Hong Kong within 12-24 hours after payment completed received, and will give you the tracking number asap. sometimes we will send it by flat post air mail if just one low price order.Hope you understand. we advise shipping by DHL or EMS,and we have gave a discount for you,you can received it in 4-9 business days. it takes about 15-30days usually if shipping by CHina/Hong Kong post air mail Payment We ONLY accept payment by Paypal. All payments must be received within 7 working days after auction has ended. Non-paying bidders will be reported to ebay. Feedback If you have any questions or comments about our products or policies, please contact us by emails with your purchased item number. You also can contact us by leaving us an eBay message,we will be responded within 24hours. Customer satisfactory is most important to us. If you have a problem or question regarding your transaction please contact us before leaving any type of feedback. Negative feedback does not solve anything. We are always willing to work things out, thank you! Return Policy Refunds are only offered for defective products reported within 7 days upon receipt Buyers need to return the defective item for the replacement at his own cost. Item must be returned by registered airmail to our requested address. We do our best to serve each and every customer the best we can. if you need more items,we can provide you a wholesales price,you can contact us by message or email.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Country/Region of Manufacture	China
Model	rw-st01a
Brand	SMOWO
