0-6000mm Tft Lcd Digital Ultrasonic Flaw Detector Defectoscope Mitech Mfd350b

US $2,690.00

HK, Hong Kong
Jan 30th

Open on mobile:
QR code

gainexpress Advance Portable Digital Ultrasonic Flaw Detector, economical & practical model. It combines powerful flaw detection measurement capabilities, extensive data storage & ability to transfer detailed inspection date to PC through high-speed USB port. It incorporates detection of its measuring range, testing of thin materials, narrow band filter to improve signal to noise in high gain application, wave pulser to optimize penetration on thick or highly attenuating materials. Controls all testing process by mini-processor. It has low power design & can charge with two models such as on-line charging and off-line charging. This can work continuously for about 8 hours with large capacity and digital multi-color TFT LCD, original imported stable IC, small size, light weight and stable performance. The instrument can be widely used in locating sizing hidden cracks, voids disbands, and similar discontinuities in welds, forging, billets, axles, shafts, tanks and pressure vessels, turbines and structural components. Memory : store, recall and delete 100 channel files stores calibration set-ups & 1000 wave files store A-Scan patterns 2 fully independent gates offer a range of measurement options for signal height or distance using peak triggering Alarms: Threshold positive/negative Semi-Automatic 2 point calibration: Automated calibration of transducer zero offset &/or material velocity Flaw Locating: Live display Sound-path, Projection, Depth, Amplitude Flaw sizing: Automatic flaw sizing using AVG/AVG or DAC, speeds reporting of defect acceptance or rejection Digital Readout & Trig. Function: Thickness/Depth can be displayed in digital readout when using a normal probe & Peam path, Surface Distance & Depth are directly displayed when angle probe is in use Available DAC and AVG method of amplitude evaluation curved surface correction, crack height measure function & weld figure feature Magnify gate: spreading of the gate range over the entire screen width Video Recording & play Digital color TFT LCD display, high resolution (320 x 240 pixels)chooses background & wave color, 4 user- selectable brightness & analog look provide detailed information Auto-gain function Envelope: Simultaneous display of live A-scan at 60 Hz update rate Peak Hold: Compare frozen peak waveforms to live A-Scans to easily interpret test results A Scan Freeze:Display freeze holds waveform & sound path data B Scan display feature Real Time Clock Communication: High speed USB2.0 port. DataPro software helps manage & format stored inspection data for high-speed transfer to the PC. Data can be printed, copied & pasted into word processing files and spreadsheets. Live screen capture mode and database tracking Can be charged independent with off-line mode; Lithium-ion battery module make the instrument continuously working time to above 8 hours With high performance security-guarantee battery module, easy to assemble and disassemble With an English display, master-slave menu, shortcut key and digital swiftly knob; designed with leading technology and can be used conveniently Small and light weight can be hold by one hand and is durable to use Range : 0 to 6000mm, at steel velocity Material Velocity : 1000 to 9999m/s Display Delay : -20 to 3400 us Probe Delay/Zero Offset : 0 to 99.99us Sensitivity : 110 dB max in selectable resolution 0.1, 1.0, 2.0, 6.0dB and locked Test Modes : Pulse echo, dual element and thru-transmission Pulse Repetition Frequency :10 Hz-1000Hz Pulse Energy : Low, Medium and High spike pulse Damping : 100, 200, 400 ohms Bandwidth : 0.5 to 10 MHz Gate Monitors :2 independent gates controllable over entire sweep range Rectification : Positive, negative halfwave, fullwave, RF System Linearity : Horizontal: ±0.2% FSW, Vertical: 0.25% FSH, Amplifier Accuracy ±1dB Reject : 0-80% full screen height Units : Inch or mm Transducer Connections : either BNC or LEMO (please inform us on your preferred cable when placing order) Power Requirements : AC Mains 100-240 VAC, 50-60Hz Dimensions : 263 x 170 x 61mm Operating Temp : -10~50°C Storage Temp : -30~50°C 1x Portable Ultrasonic Flaw Detector w/ multi-color TFT LCD Display 1 x Straight Beam Transducer (4 MHz, ?10) 1 x Angle Beam Transducer (4 MHz, 8mm x 9mm, 60°) 1 x Interconnect Cable for the transducer -- choose 1 in either Q9-C5 or optional the C9- C5 (please inform us on your preferred cable when placing order) 1 x Rechargeable Li-Ion Battery Package, 8.8 amp hour (installed) 1 x Power Supply/Charger unit (available in US / UK / AU / EU plug) 2 x Supporting Pillars 1 x Operating Manual in English 1 x Sturdy and Protective Carrying Case (With rubber padding - Shock absorbent design) 1 x Data pro software for MFD instrument 1 x USB cable Guarantee Card Product Certificate Packing Card Check-out our other available items and new product releases!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Type	Ultrasonic Flaw Detector
Pulse Repetition Frequency	10 Hz-1000Hz
Brand	Mitech
Bandwidth	0.5 to 10 MHz
Model	MFD350B
Sensitivity	110 dB max
Range	0 to 6000mm, at steel velocity
Transducer Connections	either BNC or LEMO
Material Velocity	1000 to 9999m/s
Power Requirements	AC Mains 100-240 VAC, 50-60Hz
Display Delay	-20 to 3400 us
Dimensions	263 x 170 x 61mm
