0.95inch Rgb Oled (b) Ssd1331 96x64 Resolution 65k Colors Vertical Pinheader

US $12.99

shenzhen, guangdong, China
Feb 28th

Open on mobile:
QR code

This auction is for 0.95inch RGB OLED (B) 0.95inch RGB OLED, SPI interface, straight/vertical pinheader Key Parameters Driver Chip SSD1331 Interface SPI Resolution 96x64 Display Size 0.95inch Colors 65K colorful Visible Angle >160° Operating Temp. (°C) -20~70 Storage Temp. (°C) -30~80 Operating Voltage 3.3V / 5V Interface PIN NO. SYMBOL DESCRIPTION 1 VCC Power positive (3.3~5V power input) 2 GND Ground 3 NC NC 4 DIN Data input 5 CLK Clock signal input 6 CS Chip selection, low active 7 D/C Command signal, low level for command, high level for data 8 RES Reset signal, low active Ordering Info The 0.95inch RGB OLED provides 2 options for the onboard pinheader: 0.95inch RGB OLED (A): curved/horizontal pinheader 0.95inch RGB OLED (B): straight/vertical pinheader Downloads Development resources: demo codes, schematic, datasheets, etc. Click here to download Photos Dimension Package Contains 0.95inch RGB OLED (B) x 1 Selection Guide Part Number Color Resolution Display Size (mmxmm) Interfaces Driver Dimension (mmxmm) Pinheader 0.95inch RGB OLED (A) 65K colorful 96x64 20.14x13.42 SPI(4-wire SPI) SSD1331 31.7x37.0 curved/horizontal 0.95inch RGB OLED (B) 65K colorful 96x64 20.14x13.42 SPI(4-wire SPI) SSD1331 31.7x37.0 straight/vertical 0.96inch OLED (A) 1/4 yellow section, 3/4 blue section 128x64 21.7x11.2 3-wire SPI, 4-wire SPI, I2C SSD1306 33.0x33.5 curved/horizontal 0.96inch OLED (B) 1/4 yellow section, 3/4 blue section 128x64 21.7x11.2 3-wire SPI, 4-wire SPI, I2C SSD1306 33.0x33.5 straight/vertical 1.3inch OLED (A) Blue 128x64 29.42x14.7 3-wire SPI, 4-wire SPI, I2C SH1106 40.5x37.5 curved/horizontal 1.3inch OLED (B) Blue 128x64 29.42x14.7 3-wire SPI, 4-wire SPI, I2C SH1106 40.5x37.5 straight/vertical Terms & Conditions Payment: · PayPal is the only method of payment that we accept. Shipping: · We ship items to Worldwide! · Please confirm your address in paypal, phone number is also very important. · All items will be shipped within 48 working hours on receipt of cleared payment. · We'll add a tracking number after sending the item so that you can track your parcel. Returns Policy: · We are happy to return any unused item in its original packaging within 14 days of delivery. · Buyers are responsible for the round(two-way) shipping cost. Feedback: · We'll leave POSITIVE FEEDBACK on receipt of cleared payment. · If you're satisfied with the item and our service, please leave POSITIVE FEEDBACK, it's important to us. · Once any problems occured, please contact us first. We'll try our best to work things out. FAQ: · More details(Click) If you have any question, please feel free to contact us. It's our pleasure to serve you! We appreciate your business!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Waveshare
Interface	SPI
Model	0.95inch RGB OLED (B)
Display Size	0.95inch
Country/Region of Manufacture	China
Colors	65K colorful
Resolution	96x64
Pinheader	straight/vertical
Driver Chip	SSD1331
