1/2" Hanwha Ml12, Fanuc 0t, 1998,5 Od. 3 Id-bw, Sub Spindle, Fedek Mag Loader

US $24,500.00

  • Longmont, Colorado, United States
  • Jan 30th
Open on mobile:
QR code
Machine # 315037 Click the link below to view a video demonstration of this machine http://www.youtube.com/watch?v=agdoWJwzgwo   General Specifications per Manufacturer:   Control:                                           Fanuc 0TC Normal workpiece diameter:          12mm Maximum Head Stock Stroke:       140mm Maximum Front Dicharge:             70mm Speed Range (Rpm):                       200-12,000 Power Rating:                                 1.5/2.2Kw Maximum Drilling Diameter:         7mm Maximum Tapping Diameter:         M6 Number of OD Tools:                     5 Number of ID Tools:                       3  Sub-Spindle: Nominal Workpiece Diameter:       12mm Speed Range (Rpm):                       200-6,000 Power Rating:                                 0.4Kw Number of BW Tools:                    3 Dimensions (LxWxH):                   5' x 3.5' x 5' Weight:                                           3000 lbs   Equipped With (to be Confirmed by Buyer):  MTA/Fedek Mini-Swiss-12 Magazine Bar Loader, 12' (S/N 120153)  Chip Cart  Fixed Guide Bushing  Rotary Guide Bushing  Ops, Prog, Maint & Control Manuals w/machine   Machine:   62" x 36" x 63" 3,000 lbs Barfeed:  182" x 29" x 52" 1,500 lbs Chip Pan:  38" x 20" x 24" 100 lbs Chip Cart: 49" x 20" x 41" 100 lbs   Also available: New and Used Bar Feed equipment, Hi-pressure coolant systems, mist collection systems, tooling packages, as well as, assistance with rigging & trucking. For More information, shipping quote, details contact Steve @ 303-651-6545 or steve@automatics.com
Condition:
Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...
Brand Hanwha
Model ML12
