1-500mhz Rf Broadband Signal Amplifier Module 45db Linear Variable Gain Ad8367

US $24.88

Guangzhou , China
Jun 9th

Open on mobile:
QR code

1-500MHz RF Broadband Signal Amplifier Module 45dB linear Variable Gain AD8367 Feature: Name: AD8367 variable gain amplifier Power: + 5V Size: 45mm X 28mm Features: layout of regular, MINI, layout design layout is reasonable, generous timber, for students to learn and participate in competitions. Features: Wide range of analog variable gain: -2.5 dB to 42.5dB Cut-off frequency of 500MHz 3dB Gain and debuffs mode Linear decibel scale is 20 mV / dB's Resistance Grounded reference input Nominal ZIN = 200Ω On-chip, the square-law detector Single-supply operation: 2.7 V to 5.5 V The AD8367 is linear in dB gain control from low use of high-performance variable gain amplifier within 45 db up to several hundred megahertz range, and gain flatness response precision using ADI's X-AMP® architecture, the recent series of powerful the concept of variable gain proprietary application, which far exceeds the competition can use technology to achieve. This input is applied to a 9, 200Ω resistor ladder network. Each stage has a loss of 5 dB, 45 dB of total attenuation given. At maximum gain, the first tap selection; in decreased earnings, leading to move smoothly and continuously toward higher attenuation values. Even at high frequencies, after 42.5 db attenuator is substantially fixed gain feedback amplifier having an operational amplifier 100 GHz, and a gain-bandwidth product is very linear. Output third-order intercept of 20 db at 100 MHz (when +27 dBm, at 200Ω), at 1 V PP with VS = 5 V output level measurement. package: 1pc module We only accept Paypal in Ebay. If you want to pay via other method please contact us. Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility. Please check with your country's customs office to determine what these additional costs will be prior to biding Item will be shipped within 24 hours on payment received from Hong Kong using Airmail. Delivery time depends on destination and other factors, it may takes up to 30 business days. Optionally, Express Shipments with tracking service via EMS/DHL/UPS with a quoted delivery time of 5 to 7 business days is also available Here is the estimated time for your reference only: The delivery time may vary due to public holidays, countries, and customs etc. Thanks for your understanding You feedback is very important to us, please let us know before leaving any negative feedback or open any disputes on Paypal, please give me an opportunity to resolve any problems and we will try our best to satisfy your requirement. If the item is defective, please let me know as soon as possible after receive the items. The item will be returned its original condition, in order to get it refunded and replaced (please inquire us the returning address before you ship it back.) . Buyer is responsible for shipping costs when shipping products. On Sep-08-15 at 00:12:04 PDT, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	MPN	Does not apply
Brand	Unbranded/Generic
UPC	Does not apply
