1.5kw 4-axis Cnc Usb Engraving Machine Metal 3d Milling Carving Machine+remote

US $1,125.00

Basel, Switzerland
Aug 13th

Open on mobile:
QR code

Store category Sign Up Now ! You may also like WELCOME Product Description SKU:1500W-6040TUSB-1+1500W-6040TUSB-2+1500W-TS002USB Please Note: We only sell machine without software. If you need software, please buy on official website. 1. This 3D 6040T machine is suitable for industry, Technology Research, Advertising Design, Arts Creation, Teaching, Student Project and Hobby Purposes. 2. It can work with various materials(metallic & non-metallic), such as: wood, pmma or other plastic, MDF board, native wood, PVC, Acrylic, wood, composite board plywood. and soft metal .like aluminum, copper and silver to engrave them into 3D/2D works etc. 3. It can used for engraving: advertising signs, PCB, nameplates, badges, seals, bronzing plate, aluminum alloy, acrylic plates, ABS resin double color plate, PVC foaming board, indentation plates, signs, construction models, instrument panels, wooden products, etc. 4. The mini 3D router Frame is movable. The machine can connect with computer as other external device such as printer, scanner... 5.With the assist of the 3D ROUTER 6040T, your design idea will be real-time display. 3D Engraving Machine Parameters: X,Y,Z Working Area: 600(Y)*390X*120(Z)mm Outside dimension: 865*680*570mmL*W*H Table size: 770Y*490Xmm Lathe structure: 6061/6063 Aluminium alloy Max. Feeding height: ≤100mm Drive Unit X axis 1605 Ball Screws Y axis 1605 Ball Screws Z axis 1204 Ball Screws Sliding Unit X axis High intensity Chromeplate shaft Y axis High intensity Chromeplate shaft Z axis High intensity Chromeplate shaft Stepping motor: 57 two-phase 3A 150N.cm Spindle Motor: tips1,The spindle motor must connect with the VFD. 2,It cannot directly connect with the supply voltage (AC220V). 3,Please don’t change the data setting of the VFD if you are not professional technicians, or it might damage the spindle motor. Outside dimension: 65*158mm Material: 304 stainless seel, Copper coil, Pressure cast aluminum pipe water jacket VOLTS, current, power: AC220V~240V/50Hz, 5A,1.5KW VFD Spindle speed: 24000 rpm Max working frequency: 400Hz Principal axis collet: ER11collet, Standard configuration :6mm Nut Model: ER11-A Cooling: Water-cooling Speed mode: By adjusting the VFD output voltage and operating frequency From: 0-24000RPM Lubrication way: lubricated by high grease Repeat accuracy: 0.05mm Spindle precision: radial beat acuities 0.03mm Carving Instructions: G code / TAB files / nc file / NCC files Communication interface: through USB Port with computer environment: windows XP / win7 32BITS Maximum Idle speed:1500mm/min Working Speed: 50-1500mm / min (different materials differ) Control Box Parameters: Operating Voltage: AC220V Control unit : Toroidal transformer + PWM power supply module + TB6560 stepping motor drive Computer connection: USB port Command code: G code Protection: Emergency stop button Feature: 1, The NEW 1.5KW water-cooled VFD is available operating for long time,which can reinforced the processing abilty of the machine and can be used to process aluminum alloy and hard wood. 2, water cooling spindle works more stable and durable. 3, High quality accurate ball Screws drive make the engrving more precision.Anti-blackflash,high precision,long life circle. 4, Compatabilityfit for Emc2/Type3/ArtCAMParameter How to use 1. Assembling and locating the 3D machine on steady desk well. 2. Make sure that your computer has a USB port output. 3. Place the contral box in a ventilated dry place where there is no dust, no moisture 4. Connecting the control box with the 3D machine and you computer and make sure the plug will not come off. 5. Correctly connect the machine with the controller. Don't suspended the cable which connect the Spindle motor with axis(X,Y,Z,A).Otherwise, it will damage the driver of the controller. 6. Correctly instal the Spindle motor and the heat pump. The heat pump should be covered completely in the water, then turned on the electric current to check whether the water-cooling system working well. 7. Installing a 3D control Drive on your computer. 8. Fllowing our manual or guideline to set 9. Before turn on the machine, please check all the cable and water- cooling system to make sure they are working fine. 10.You can enjoy making you dream with using our 3D machine now. 1,MANUAL Controller Handrad: Industrial for 3D engraving machine controller was designed for system Spring can be stretched to 3 meters Waterproof design, very durable, anti-dirt, oil spray Power by USB port Dimensions: 22 x 8 x 3cm Please note: this item works with fit for ONLY The usb self-check light, you can type the " scroll" on the keyboard to activate it. Directional motion control: X+, X-, Y+, Y-, Z+, Z-, A+, A- Feed rate control: F+, F- Jog rate: J+, J- Spindle speed: speed up, slow down Programming: E-stop, cycle start, spindle on/off, Redo, single step, original point Package Include 1 * Remote controller 1 * Cable On Aug-13-21 at 01:53:32 PDT, seller added the following information: Payment Delivery details Terms of sales About us Contact us Payment We accept ebay payment Fees such as import duties, taxes are not included in the item price or shipping costs. These charges are the buyer's responsibility. Delivery details Shipping: The item will be shipped from our US warehouse to United States, which is more faster than from aboard. 2-9 working days to: USA Terms of sales We maintain high standards of excellence and strive for hundred percent customer satisfaction. Feedback is very important to us. We hope that you contact us immediately before you give neutral or negative feedback, so that we can address your concerns. It is impossible to address issues if we do not know about them! About us Your satisfaction is our ultimate goal. We work hard to earn your trust and future business. Our certified technicians have tested each item before shipping. The unit comes with 1 year limited warranty on all manufacturing defects. a) If you receive a defective item, you may return it or ask for a discount. Please contact us within 14 days after you receive the package. b) What you returned must be intact and in its original packaging as re? u. Customer is responsible for shipping costs of the returned item. c) We will cover the cost of shipping back t with the shipping rate indicated in the registration page. We will send you a new unit or refund the full payment you paid. Thank you. Contact us Business Hour Business Hour: Monday To Friday: 8:30 AM to 5:00 PM (Beijing China time) Due to time zones, our reply to your questions may not be immediately. But within above working time, we will reply your email within 24 hours. If it's non-workdays, please kindly be patient and wait till Monday. Please contact us with ebay message. Please feel free to contact us if you have any questions. : Monday To Friday: 8:30 AM to 5:00 PM (Beijing China time) Due to time zones, our reply to your questions may not be immediately. But within above working time, we will reply your email within 24 hours. If it's non-workdays, please kindly be patient and wait till Monday. Please contact us with ebay message. Please feel free to contact us if you have any questions.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	6040 CNC ROUTER ENGRAVING MACHINE
Nut Model	ER11-A
X,Y,Z Working Area	600(Y)390X120(Z)mm
Cooling	Water-cooling
Outside dimension	865680570mmLWH
Repeat accuracy	0.05mm
Table size	770Y*490Xmm
Computer connection	USB port
Lathe structure	6061/6063 Aluminium alloy
Control unit	Toroidal transformer + PWM power supply module + T
Max. Feeding height	100mm
Connetion port	USB
Drive unit	1605 Ball Screws
Spindle motor	1.5KW Water Cooled Spindle Motor
Sliding unit	High intensity Chromeplate shaft
MPN	Does Not Apply
Stepping motor	57 two-phase 3A 150N.cm
Brand	Unbranded/Generic
power	1.5KW VFD
Control	CNC
Spindle speed:	24000 rpm
Power Source	Electric
Max working frequency	400Hz
Machine Type	Engraving Machine
Principal axis collet:	ER11collet
Country/Region of Manufacture	China
