1.8" 128*160 Spi Tft Lcd Display Module Serial Pcb Adapter Power Ic Sd Socket

US $6.98

United States
Feb 15th

Open on mobile:
QR code

1.8" 128*160 SPI TFT LCD Display Module Serial PCB Adapter Power IC SD Socket Product Description Description: It has PCB backplane with power IC, SD card socket It need 4 IO port at least to drive The module port is compatible with 1602 LCD and Nokia 5110 / 3310 LCD display port File: Normally, the chip is Samsung S6D02A1. And it's code link is http://pan.baidu.com/s/1bnkWQT5. You can contact customer service or writer email to wangzhanxiemeijuan@banggood.cn, so that we can send the file to you. Important Note: Using with Arduino, every IO port should be connected with resistance range 500 ~ 2Kω. Specification: Display size: 1.8inch Dot matrix: 128 x 160 Input voltage: 5V / 3.3V Driver IC: HX8353 / S6D02A1 / ST7735 Pin definition: 1-RST, 2-CE, 3-D/C, 4-DIN, 5-CLK, 6-UCC, 7-BL, 8-GND Size: 54 x 34mm(L x W) Package includes: 1 x 1.8inch SPI TFT LCD display module Important Notes: 1. This seller uses an automated feedback system. A positive feedback will be posted for the buyer at the time the seller receives a feedback from the buyer. If you do not receive feedback after leaving feedback, please contact the seller. 2. This seller strives to process and ship items within 24-48 hours after payment. Some unforeseen circumstances may arise where this is not possible. If tracking information has not been upload to the transaction after 48 hours please contact the seller as this may have simply been an over sight. 3. Pictures are for reference only. Due to computer monitor difference, actual products receive may vary. 4. International orders may be shipped from overseas warehouses for faster delivery or what ever may be the most economical for the seller. Overseas warehouses includes; Brazil, United Kingdom and China. Returns: If there is a problem, please work together with this seller to resolve the problem. Negative feedback doesn't go away and should only be left as a last resort! This seller strives for positive feedback, harmonious customer relations. 1. Item must be returned to the seller within 14 days of delivery. 2. Buyer is responsible for return shipping. 3. If the item is Dead on Arrival (DOA) The seller will pay the shipping charge for sending the buyer the replacement item. 4. This seller must first receive the item to verify returns claims before a refund or exchange will be completed. 5. Items returned for non-seller mistake reasons, ie; buyer changes mind of purchase, purchased wrong color, etc..., may be subject to restock fee. (Restocking fee includes all fees that the seller incurred to send buyer the product purchased including: original shipping fees, eBay fees and PayPal fees.) inkfrog terapeak inkFrog Analytics
