1.8" Tft Spi Lcd Display Module Serial 128x160 With Pcb Sd Socket 1.8 Inch

US $64

Shenzhen, China
Jan 29th

Open on mobile:
QR code

Product Name: 1.8" Serial 128X160 TFT SPI LCD Module Display + PCB Adapter with SD Socket new More Items In Our Store,Click Here! SKU: 1845 Parsts No. : Package: Brand: 1 JP1:3.3 V / 5 V power supply switch Use 3.3 V power supply is needed to make JP1 short circuit Use 5 v power supply must break, or LCD will be broken immediately Below is a FG combied of several products of ours, made by our customers, would share with you all:) The Cheap-Thermocam is a low-cost thermographic image scanner. With it you can analyse your house, electrical devices, etc. and identify for example thermal lacks. Current FLIR cameras on the market cost a few thousand dollars. My idea was it to reduce costs by using one single non-contact temperature sensor to create a thermographic image. This is done by moving the infrared sensor over the target area with two servo motors like a scanner. The popular arduino is used to control that procedure. It takes about 3 minutes per image to measure the temperature on 3072 points. The Thermocam can measure temperatures from -70° to 380° with an accuracy of 0.5°.All data is stored on a SD card. The device has a display that leads you through the creation process. Afterwards, the thermal images are shown on it. On the computer, you can combine the thermal pictures with any optical image from a smartphone/camera. You can also adjust many settings there. The final image will be outputed as a JPG file with a resolution of 640x480 pixel. The Cheap-Thermocam is a portable and easy to use thermographic scanner. Two servos are controlled by an arduino mikrocontroller. They move the infrared sensor over the target area. The resolution of the thermographic image is 64x48 pixel (= 3072 single measured points) and is interpolated to an output picture of 640x480 pixel. You can power the device with a standard usb wall adaptor or an usb storage battery to make it portable. The display leads you throught the image creation procedure. It can be controlled over a rotary encoder on the side. It takes about 3 minutes to create a full image, as the sensor has to be shifted over the whole area like a scanner does. Afterwards, the temperature values are stored on a SD-card and the thermal image is shown on the display. On the computer, a software written in Java leads you through the process of creating the final thermal image. You select the temperature file from your storage card as well as a photo taken from the area with your usual photo camera or a smartphone. The user can select between two different colour schemes, add points where the temperature is displayed on the image and modify the colour assigment with sliders. The final image can be saved as a jpg image together or without the optical image. Other TFT LCD Display Series Character Display LCD Modules IIC LCD Display Series Nokia LCD Display Series Dots Matrix LCD Display Modules MCU Chips 1. ATMEl AVR MCU 2 PIC MCU 3. STM32 MCU 4. C8051F 5. MSP430 MCU 6. 51 STC MCU Maybe you request 10pcs NEW 40Pin 1*40 2.54mm 20mm Long Header Pin Male Breakable Pin Header 65pcs Breadboard tie line Wire Breadboad + MB-102 Solderless breadBoard PCB Test 2x Mega 2560 ATmega2560-16AU Board (Arduino-compatible)+Free USB Cable Funduino 1PCS Board MB102 Breadboard Power Supply Module 3.3V/5V For Arduino good NEW 4.3" TFT LCD Module Display (with SD card slot) + Touch Panel + PCB adapter $ 2.43 + free shipping $ 6.25 + free shipping $ 33.72 + free shipping $ 2.69 +free shipping $ 39.85 + free shipping 1) We accept PayPal payment ONLY. inkFrog Analytics
