1.8kw Iso20 Automatic Tool Changer Atc Spindle Water Cooled Milling Motor 220v

US $1,450.00

Changzhou, China
Jun 8th

Open on mobile:
QR code

1.8KW ISO20 Automatic Tool Changer ATC Spindle Water Cooled Milling Motor 220V Package included: 1 x 1.8KW Water cooled Automatic Tool Changer Spindle Motor 220V,5.4A,24000rp,400Hz,80mm 1 x ISO20 ER20 tool holder 1 x English user manual 100% Brand New & High Quality!!! Product overview 1.This spindle is built-in type spindle motor, built-in three asynchronous motors,by the inverter control.As the spindle has a compact structure,high power, big torque, small vibration, low noise characteristics,so it can achieve high speed,high powe cutting,high precision and high stability operation. 2.The bearing of spindle use grease lubricated angular to contact bearings,can be achieved lifelong lubricating within the life cycle. 3.The spindle use forced coolling mode to coolling motor,front and rear bearings.Coolant flow through the reasonable arrangement cycle watercourse of the spindle body,thus can take the heat generated of the spindle rotation speed, to achieve thermal equilibrium,let spindle temperature within a certain constant value. External cooling device effect:maintaining a constant temperature of the coolant. 4.The spindle built-in PTC 140 temperature sensor (Technical parameters are visible in other sections of this specification),you can read it anytime if you need to protect the motor temperature. 5. The tool clamping methods:this spindle built-in automatic tool change device,shank form is ISO20. Automatic tool changer electric spindle outline drawing Automatic tool changer electric spindle parametric curve graph Automatic tool changer electric spindle technical parameters Spindle model: RTM80-20-24Z/1.8 220V Voltage: 220V Maximum speed: 24000rpm Rated frequency: 400Hz Electric current: 5.4A Motor Pole: 2 Pole Rated power: 1.8KW (S1) Peak power: 2.1KW (S6) Rated torque: 0.59Nm Peak torque: 0.84Nm Technical parameters No. project Standard 1 Spindle blowing dust/seal gas pressure (MPa) 0.2-0.25 2 Spindle gas seal gas flow (L/min) 65±10(When on Working) 3 Cooling water pressure (MPa) 0.25 4 Cooling water flow (L/min) 2.5 5 Cooling water temperature (degree) 24-28 6 Spindle static state pulse (µm) 3 7 Spindle vibration (mm/s) 0.8 8 < align="center">Spindle diameter (mm) Diameter 80 (0/-0.020) 9 Motor windings Pressure test (V/M) 1000V/1 minute withstanding Voltage test 10 Tool Interface ISO20 11 Inverter Specifications 2.2KW (220V) 12 Fitment For castings, aluminum, glass, etc., and other processing Spindle installation explanation 1.Circulating Cooling System Description The system must ensure that the cooling water temperature of supply spindle is between 24-28 degree. Usually setting the flow switch in return pipe of the cooling system,to ensure the supply of spindle cooling water. Cooling water requirements: we recommend using distilled water, while recommend Feinuokesi (Fenix) protective agent F1 (using the scale of 1: 200),coolant temperature is 26 degree ±2 degree,inlet, outlet pipe temperature can’t exceed 5 degree.It is allowed As long as other monitoring can ensure fuller spindle cooling. 2.Air sealing control In order to prevent water or impurities enters internal of the spindle,spindle will have gas sealing device,the gas seal machine must be started start with the machine at the same time. And the need to go through multi-stage filtration. 3.Compressed gas quality requirements The quality requirement of gas which is used in gas seals: Oil content: <0.01mg/m3; solid particle: <5µ m Pressure dew point: <7.5degree (0.7MPa) 4. Running-in program instructions Only all monitoring issued no failures operational signals,at the same time,all safety devices have been installed and working properly,then allow start spindle. Note: new or spindle which is not used for a long time must to be running slowly.First,start run spindle for half an hour as 25% of the maximum speed,then increase to 50% of the maximum speed,to run 15 minutes,finally, increase to maximum speed.It’s need to check the temperature of the spindle during the whole process, spindle will get hot, but not hot hand, if the spindle becomes hot, pls stop the operation and contact our customer service department. 5. Product backend interface instructions: Shipping Please open the package and check if there are some damages before sign,if there are some damages,please do not sign and contact us immediately. Payment Only accept paypal payment method. Payment must be made within 3 days. Problem&Feedback Please give us the opportunity to resolve any problem when you have,we concern your problem and we will try our best to resolve it. Pls contact us before you want to leave any negative feedback. Refund Any reason required for all refund. Item must be in it's original condition and no physical damage,buye responsible for all shipping cost. When you have the parcel,and not satisfied the goods or it is other problem like as broken,pls tell us the detail reason and provide the photos.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Pole	2 Pole
Cooling	Water cooled
Country/Region of Manufacture	China
Power	1.8KW
Speed	24000rpm
Nose	ISO20 ER20 Tool Holder
Frequency	400Hz
Balance Level	G1.0
Current	5.4A
Size	80x379mm
Model	RTM80-20-24Z/1.8 220V
MPN	Does Not Apply
Voltage	220V
Brand	RATTM MOTOR
UPC	Does not apply
