1* E6c2-cwz6c 1000p/r Rotary Encoder Rotary Incremental Encoder

US $48.13

suzhou, China
Jul 11th

Open on mobile:
QR code

Product Description 1* E6C2-CWZ6C 1000P/R Rotary Encoder Rotary Incremental Encoder Product description: 1. High-quality incremental rotary encoder with a diameter of 50 mm. 2. ASIC internal equipment, high reliability, long life, high anti-interference performance. 3. The stainless steel spindle has higher stability and protection ability, and the metal shell is stronger and impact resistant. 4. Small size, light weight, compact structure and easy installation. 5. With load short-circuit protection, power supply reverse connection protection. Product specifications: Product name: Incremental rotary encoder Model: E6C2-CWZ6C Material: lead alloy (shell), aluminum (body) Input voltage: DC5~26V (open collector output type) Output mode: voltage output, collector output, complementary output, push-pull output, long-distance drive output, differential output, fork output Output phase: A, B, Z phase Outer diameter: 38 mm Thrust shaft diameter: 8 mm Standard length of wire: 2 m Resolution (pulse/rotation): 1000P/R Brown wire: DC5-26V (positive) Blue wire: 0V (negative) Black line: A (phase) White line: B (phase) Orange line: Z (phase) Shielded network cable: N.C (grounded) Phase difference between outputs: 90°±45° between A and B (1/4 T±1/8 T) Output configuration: NPN open collector output Output capacity: applied voltage: maximum 30 VDC; synchronous current: maximum 35 mA; residual voltage: maximum 0.4 V (for 35 mA synchronous current) Maximum response frequency (* 3): 100 kHz Output rise and fall time: 1s maximum. (Control output voltage: 5 V, load resistance: 1k, cable length: max. 2 m) Starting torque: maximum 0.9 mN.m Moment of inertia: maximum 1x10-6kg.m; (maximum 3x10-7kg.m, maximum 600 P/R) Radial shaft load: 50N Thrust shaft load: 30N Maximum authorized speed: 6,000 rpm Package list: 1 * Encoder 3 *screw 1 *Description Note: 1.The real color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness. 2.Please allow slight manual measurement deviation for the data. Payment We accept payment via Paypal only. Payment must be completed within 5 days. If you have any problems about payment, please contact us via ebay message. Delivery details We only ship to confirmed Paypal addresses. Please comfirm that your paypal address is in line with your shipping address. Please kindly note that the combined shipping is not provided because the shipping fee is calculated by weight. Also, the each additional item means exactly the the same color and size. It takes about 7-15 working days to US; about 10-30 working days to other countries. Transit time may be a little delayed because of the bad weather and customs inspection. If you do not receive your item within 30 working days since payment finished, please contact us immediately for further assistance. Contact us We strive for 100% customer satisfaction! Positive Feedback is very important to us. If you have any questions, please feel free to contact us via "Ask seller a question" . We will reply your email within 24 working hours.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	unbranded
Outer diameter	38 mm
MPN	Does Not Apply
Resolution (pulse/rotation)	1000P/R
Package Contents	1 * Encoder Set
Maximum authorized speed	6,000 rpm
Model	E6C2-CWZ6C
Radial shaft load	50N
Input voltage	DC5~26V
Thrust shaft load	30N
Output phase	A, B, Z phase
UPC	Does not apply
