1 Inch 5c Expanding Collet (arbor) American Made

US $34.95

Tilton, New Hampshire, United States
Jan 30th

Open on mobile:
QR code

5C Expanding Collet Designed for Precision trouble free CNC Machining and Manual Machines This is our own precision high quality design. PROUDLY Manufactured here in THE UNITED STATES of AMERICA .0002 TIR can be achieved with precision machining techniques. Pat. pend. Our Precision collets are the best you can purchase. When properly installed they will not become un-seated Causing loss of T.I.R. Even with a Draw Tube travel of up to .500 inch. Our design prevents over travel of the Draw Screw even if the operator forgets to place a part On the collet correctly. See our cut-away picture for details. You will never buy another collet design once you use ours. You are bidding on: 1ea. 1 Inch 5C Expanding Collet (Arbor) with Hex Key Wrenches: diameter Length Minimum Machinable dia. 1.0 x 1.0 .430 HAND - E 5-C EXPANDING COLLET INSTRUCTIONS 1.) INSERT THE HAND-E EXPANDING COLLET INTO THE SPINDLE OF MACHINE. 2.) CENTER DRAW SCREW MUST BE BACKED OFF AT LEAST FOUR TURNS. 3.) WITH THE DRAW TUBE IN THE CLOSED POSITION TIGHTEN DRAW TUBE BY HAND UNTIL PRESSURE IS FELT. THEN TIGHTEN FOUR ADDITIONAL TURNS TO---PRELOAD -COLLET FOR ACCURACY. 4.) WITH ALLEN WRENCH TIGHTEN DRAW SCREW UNTIL ARBOR EXPANDS APPROXIMATELY .002. MACHINE ARBOR TO SIZE REQUIRED. RELEASE COLLET CLOSER, PLACE PART ON ARBOR AND EXPAND COLLET WITH CNC HYDRAULIC’S, AIR OR LEVER ON MACHINE. ADJUST DRAW SCREW FOR DESIRED EXPANDING FORCE. MACHINE PART AS REQUIRED. .0002 T.I.R. CAN BE ACHIEVED WITH PRECISION MACHINING TECHNIQUES. ANY QUESTIONS ON THE OPERATION OF HAND-E 5C EXPANDING COLLETS WILL BE ANSWERED BY CALLING 1-603-387-6551 TECHNICAL DEPARTMENT. INCLUDES: Item(s) described above and exactly as what's pictured in the main photo. NOTES: SHIPPING: We will normally ship USPS (Flat Rate Ground) Other US and Territorial Shipments must contact us for shipping costs. Item will ship from stock. We add $ 1.00 to each shipment for handling and packaging costs. We will combine shipping costs on multiple orders when packaging permits, at Flat Rate costs. FOREIGN SHIPMENT and PAYMENT: Shipping costs must be agreed upon in advance. (contact the seller) We will ship to Countries other than US once payment has been received in US Funds and has cleared our bank. We will also combine shipping costs on multiple orders. International Buyers – Please Note: * Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer’s responsibility. * Please check with your country’s customs office to determine what these additional costs will be prior to bidding/buying.” * “These charges are normally collected by the delivering freight (shipping) company or when you pick the item up – do not confuse them for additional shipping charges.” * “We do not mark merchandise values below value or mark items as ‘gifts’ - US and International government regulations prohibit such behavior.” RETURNS: Item may be returned for a full refund, less any shipping and handling charges , if in original unused condition ,within 14 days and you have notified us in advance of shipping and have received a return authorization.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Manufacturer	Breakheart Tool Co.
Model	5C-1.0D-1.0L
Country/Region of Manufacture	United States
MPN	5C-1.0D-1.0L
Brand	Breakhert Tool Company
Workholding Part Type	1 inch 5C Expanding Machinable Arbor
