(1 PC) DM9601J/883C NSC retriggerable one shot, US $8.00 – Picture 0

(1 PC) DM9601J/883C NSC retriggerable one shot, US $8.00 – Picture 1

(1 PC) DM9601J/883C NSC retriggerable one shot, US $8.00 – Picture 2

(1 Pc) Dm9601j/883c Nsc Retriggerable One Shot

US $8.00

Granbury, Texas, United States
Jan 29th

Open on mobile:
QR code

THIS LISTING IS FOR (1 PC) OF DM9601J/883C BY NATIONAL SEMICONDUCTOR retriggerable one shots 9601/DM9601 Retriggerable One Shot General Description These retriggerable one shots provide the designer with four inputs; two active high and two active low. This permits a choice of either leading-edge or trailing-edge triggering, independent of input transition times. When input conditons for triggering are met, a new cycle starts and the external capacitor is rapidly discharged and then allowed to charge again. The retriggerable feature allows for output pulse widths to be expanded. In fact a continuous true output can be maintained by having an input cycle time which is shorter than the output cycle time. Retriggering may be inhibited by tying the Q output to an active low input. Features Y High speed operation?input repetition rate l 10 MHz Y Flexibility of operation?optional retriggering/lock-out capability Y Output pulse width range?50 ns to % Y Leading or trailing edge triggering Y Complementary outputs/inputs Y Input clamping diodes Y DTL/TTL compatible logic levels Y Alternate Military/Aerospace device (9601) is available. Absolute Maximum Ratings (Note) If Military/Aerospace specified devices are required, please contact the National Semiconductor Sales Office/Distributors for availability and specifications. Supply Voltage 7V Input Voltage 5.5V Operating Free Air Temperature Range Military b55§C to a125§C Commercial 0§ to a70§C Storage Temperature Range b65§C to a150§C

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	National Semiconductor
Country/Region of Manufacture	United States
MPN	DM9601J/883
