1 Pc Lm105h 4.5v To 40v Adjustable Voltage Regulator Can-8 Gold Pins - Usa Ship

US $9.95

Victorville, California, United States
Aug 5th

Open on mobile:
QR code

"New, Old Stock" VINTAGE 1974 National Semiconductor LM105H Adjustable Positive Voltage Regulator With Vintage GOLD PLATED Leads In an 8-Pin TO-5 / TO-99 Metal Can The LM105H is an Adjustable Positive Voltage Regulator similar to the LM100, except that an extra gain stage has been added for improved regulation. A redesign of the biasing circuitry removes any minimum load current requirement and at the same time reduces standby current drain, permitting Higher Voltage Operation. Features • Output voltage adjustable from 4.5V to 40V • Output currents in excess of 10A possible by adding external transistors • Load regulation better than 0.1%, full load with current Limiting. • DC line regulation guaranteed at 0.03%/V • Ripple rejection on 0.01%V • Full Military Operating Temperature Range of -55°C to +125°C Absolute Maximum Ratings Input Voltage: 50V Input-Output Differential Voltage: 40V Power Dissipation: 800 mW Operating Temperature Range: -55°C to +125°C Storage Temperature Range: -65°C to +150°C Lead Temperature (Soldering, 10 seconds) 300°C A Complete Data Sheet can be Downloaded In PDF Format from the following URL: http://www.semiconductors.com.pl/web/pliki/LM105_LM205_LM305_LM376.pdf * Product Pictured Is The Actual Product You Will Receive * This Listing is for 1 pc National Semiconductor LM105H Adjustable Positive Voltage Regulator With Vintage GOLD PLATED LeadsIn an 8-Pin TO-5 / TO-99 Metal Can And Super FAST, "FREE" U.S.P.S. "First Class" Shipping !Most Orders Are At The Post Office"SAME DAY",Or "NEXT MORNING" at the Very Latest !!!( Free Shipping Limited to United States Addresses Only) Thank You For Your Business !!!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	TO-5 / TO-99 8-Pin Metal Can
Year of Manufacture:	1974
Country/Region of Manufacture	United States
MPN	LM105H
Circuit Type:	Adjustable Positive Voltage Regulator
Brand	National Semiconductor ®
UPC	Does not apply
