1 Piece Cd4013 Cd4013be Cmos Dual D-type Flip Flop Dip14 Us Seller. Fast Ship

US $180

Beverly Hills, California, United States
Jun 20th

Open on mobile:
QR code

1 piece TI CD4013 CMOS Dual D-Type Flip Flop Quantity 5 DIP14 Description CD4013B consists of two identical, independent data-type flip-flops. Each flip-flop has independent data, set, reset, and clock inputs and Q and Q\ outputs. These devices can be used for shift register applications, and , by connecting Q\ output to the data input, for counter and toggle applications. The logic level present at the D input is transferred to the Q output during the positive-going transition of the clock pulse. Setting or resetting is independent of the clock and is accomplished by a high level on the set or rest line, respectively. DATASHEET Features Set-Reset capability Static flip-flop operation — retains state indefinitely with clock level either "high" or "low" Medium-speed operation — 16MHz (typ.) clock toggle rate at 10 V Standardized, symmetrical output characteristics 100% tested for quiescent current at 20 V Maximum input current of 1 µA at 18 V over full package-temperature range; 100 nA at 18 V and 25°C Noise margin (full package-temperature range) = 1 V at VDD = 5 V 2 V at VDD = 10 V 2.5 V at VDD = 15 V 5-V, 10-V, and 15-V parametric ratings Meets all requirements of JEDEC Tentative Standard No. 13B, "Standard Specifications for Description of ’B’ Series CMOS Devices" Applications: Registers, counters, control circuits TERMS OF SALE We welcome FPO/APO/Military Orders. APO/FPO ships at domestic rates. New Bidders, International bidders welcome - we are flexible on customs declarations. Any questions eoi at lunaticlabs.biz WINDHAGBATS
