1-wire, 8 Channel Relay Board Jqc-3fc With Dallas Ds2408 Chipset - Din Box

US $330

Europe, Bulgaria
Jun 9th

Open on mobile:
QR code

Denkovi Assembly Electronics ltd. 1-Wire, 8 Channel Relay Board JQC-3FC with Dallas DS2408 chipset - DIN BOX General description Characteristics: 8 x SPDT relays: JQC-3FC/T73 (7A / 250VAC, 10A / 125VAC, 12A / 120VAC, 10A / 28VDC) 1-Wire interface 2 x screw terminal blocks for easy 1-wire network connection, each with GND and 1W Power supply: 12V DC / 300mA Chipset: DS2408 Led-s for relays and power on Large number of free software and source code Supported by One Wire Viewer and TMEX of MAXIM-DALLAS and Denkovi 1-Wire Command Line Tool Operating temperature range: from -30?C to +80?C PCB parameters : FR4 / 1.5mm / two layers / metallized holes / HAL / white stamp / solder mask / Extra PCB openings for better voltage isolation / Doubled PCB tracks for better voltage isolation Dimensions: 84mm x 99mm Box suitable for DIN rail mounting Product code (SKU): DAE-8RELAYS-JQC-1WIRE-BOX User manual: here Application examples Home Automation Industrial Automation Distributed systems The auction includes 1 x Denkovi 1-Wire Eight Channel Relay Module with DIN rail BOX Device Overview Typical Connections Many relay boards can be easily connected in one wire network to computer in the way shown bellow. It must be used some Computer<->One Wire converter. For example we have such converter in stock (not included in this auction) but any other computer-to-one-wire converter could do the job. Of course any microcontroller architecture supporting 1-wire network could be compaitable with the relay boad as well. Software One Wire Viewer There are many 1-Wire software available for this relay board. One such sofwtare is OneWireViewer. With this software, it can be just easily tested and simple turn on/off commands can be executed. Denkovi 1-Wire Command Line Tool We have created as well special command line utility for this 1-Wire relay board. The main goal of this project is to help you to use our 1-Wire relay boards easily and without any specific knowledge how do they work. It works on Windows/Linux. Typical applications for this software are: Create desktop icons to turn particular relays Create BAT/BASH files to make more complex logic (like timers for example) The commands can be executed from PHP script Control our 1-Wire relay boards from Android / iPhone mobile devices The 1-Wire relays can be controlled from each software/platform which can run external executable files or commands in command line promt For more information and download - here Images Useful links User manual - here One Wire drivers - here DS2408 documentation - here Denkovi 1-Wire command line tool - here We recommend also Please visit our ebay web store to find what else we can offer for you related with this item! USB<->1Wire converter Please read before buy

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	JQC-3FC/T73
Type	Relays
MPN	DAE-8RELAYS-JQC-1WIRE-BOX
Relays count	8
Country of Manufacture	Bulgaria
Power supply	12 VDC
UPC	NA
