1 X Transistor Tester Diode Resistor Inductor Resistance Detector Meter Lcr-t4

US $28.49

Shenzhen, China
Aug 5th

Open on mobile:
QR code

1 x Transistor Tester Diode Resistor Inductor Resistance Detector Meter LCR-T4 Feature: 1. Can set the number of measurements before the power is automatically turned off, with onekey operation, automatically turn off the power. 2. Use ATmega 8, ATmega 168 or ATmega 328 microcontrollers. 2x16 character LCD display shows the result. 3. Automatic detection of PNP and NPN bipolar transistors, N and P channel MOSFETs, JFETs, diodes, double diodes, thyristor thyristors. Automatically detect the pin layout. 4. Support automatic power off. ATmega168 or ATmega328 with 1.05k version software uses sleep mode to reduce power consumption when there is no measurement. 5. Built-in self-check function and optional 50Hz signal check the clock frequency accuracy and wait for calling (ATmega168 and ATmega328). 6. Only one measurement is needed to find out the connection of the full bridge. The test time is about two seconds, only capacitance and inductance measurements will take a long time. 7. Support the measurement and symbol display of two resistances, up to four digits and unit display. Specification: Item Type: Transistor Tester Material: Aluminum alloy Model: LCR-T4 Note: 1. All functions are only used for microcontrollers with more program memory, such as ATmega168. The resolution of resistance measurement is 0.1 ohms, and the highest measurement value is 50M ohms. 2. LED is detected as a diode, and the forward voltage drop is much higher than normal. The double light-emitting diode is detected as a double diode. It is possible to show signs of the correct direction for two diodes. 3. If the test current exceeds the holding current, SCR and triac can be detected. However, some semiconductor thyristors and triacs have higher trigger crrents than the tester can provide. The available test current is only about 6mA! 4. Optional equipment calibration port output internal resistance and zero-offset self-test capability measurement (ATmega168 and ATmega328). A 100nF to 20uF capacitor is required to connect between pin 1 and pin 3 to compensate the offset voltage of the analog comparator. This can reduce the measurement error of capacitors above 40uF. The internal correction voltage reference voltage with the same capacitor was found to adjust the gain of the internal reference measurement ADC. 5. Resistance below 2100 ohms will measure inductance, if your ATMEGA has at least 16K flash memory. The range will exceed 20H from 0:01mH, but the accuracy is not good. The measurement results only show a single component connection. 6. Capacitors with values below 25pf are usually not detected, but they can be connected in parallel with a diode or at least a 25pf capacitor in parallel. In this case, you must subtract the part of the parallel capacitance value. 7. Measure the reverse capacitance of a single diode. Bipolar transistors can also be measured. Both ends of the displayed resistance symbol are the connected tester probe numbers (1-3). So the potentiometer can also be measured. If the potentiometer is adjusted to one end of it, the tester cannot distinguish the middle and both ends of the pin. 8. If more than 3 diode parts are tested, the number of established diodes will display another failure message. This will only happen if the diode is connected to all three probes and at least one is a type diode. In this case, you should only connect two probes and start the measurement again, one after the other. 9. Zener diodes can be detected if the reverse breakdown voltage is lower than 4.5V. This will appear as two diodes and can only be determined by voltage. The symbol of the probe surrounding the diode is the same, in this case, you can identify the true anode of the diode by the threshold voltage near 700mV! 10. can be detected and measured with a capacitor. The highest four digits and unit display. The value can be from 25pf (8MHz clock, 50pF at 1MHz clock) to 100mF. The resolution can reach 1 pF (at 8MHz clock). 11. It can be used to measure the equivalent series resistance (ESR) capacitance value of capacitors above 2UF. The resolution is 0.01 ohms and two-digit values are displayed. This function requires at least 16K flash ATMEGA (ATmega168 or ATmega328). Package List: 1 x Transistor Tester Note: We accept PayPal . We ship item to your PayPal verified address. Payment must be received within 3 days from the date of purchase. All the items will be dispatched within one business day by Airmail after the payment is clear. Most times you will receive your order within 10-30 business days after we transfer your package to the delivery company. We cannot guarantee the delivery timeframe if the post office has any unexpected delays due to holiday, weather, customs, or other conditions. Some countries like Russia, Brazil, or some European countries may take up to 50 days or longer for delivery. We appreciate your patience if you haven't received items in 30 days(Russian customers may need more patience by reason of the local delivery system and/or customs). If you are concerned in any way, please feel free to contact us via ebay message instead of leaving negative/neutral feedback or opening a dispute. We will make every effort to fix any problem(resend or refund any missing item). Customs duty is obligation and liability of citizens in your country, so buyer should be responsible for any tax and custom duty incurred. Generally, the delay or failure delivery is sometimes caused by the policy of different customs. 1. Our listing price includes the value of goods,packaging cost,and export taxes,not including international duties. 2. duties,taxes,and charges are not included in the item price or shipping fee. 3. The duties are buyers' responsibility.Please check with your country's customs office determine what these additional costs will be prior to your purchase. 4. All disputes arising from the duties will be submitted to ebay for solution. 1. Any questions, pls. contact us via ebay message or email us.We will reply your message within 48 hours. If you do not receive our reply within 48 hours, pls. post a message again because sometimes our message system may block some emails. 2. If you are satisfied with our service, pls. kindly leave us a positive feedback and give us the Detailed Seller Rating with all "5 " in very area 3. Our aim is to provide Level Customer Service, your recognition will encourage us greatly and serve you better. We strive to keep all our customers satisfy. We will do our up most to exceed your expectations in customer service, communication and dispatching of your orders.
